Product name
Sensor
Resolution
Polling rate
SURPASSION RX Gaming Mouse
PixArt PMW3330 Optical gaming sensor
50-7200 DPI
125 / 250 / 500 / 1000Hz
Switching 50M OMRON gaming switches
Profile LED
backlight 2 zone backlight
Maximum tracking speed
Maximum acceleration
Lithium battery
Cable length
Weight
150 IPS
30 G
560mAh
1.8m
98g
Dimension 120(L) X 65(W) X 38(H) mm
The above specifications may vary by country or region
● 7200 DPI Optical Gaming Sensor with DPI fine-tuning
● 1000Hz Wireless Technology
● Works Both Wired and Wireless
● 11-Color Backlight with 13 Modes
● LCD Screen with 2 Buttons for DPI, Polling Rate, LOD,
and Angle Snapping fine-tuning
● 600mAh Lithium Battery
● Battery Life Up to 20 Hours at 1000 Hz Polling Rate
● Battery Indicator in the LCD Screen
● OMRON switches with 50 million presses
● Ergonomic Shape With Independent Button Pressing
Surface and Finger Grooves
ENGLISH
With Surpassion RX, we have done what many thought to be impossible:
we have merged a wired gaming mouseʼs accuracy and reliability with the freedom of a wireless gaming mouse.
See and believe!
● Sensor Óptico de 7200 DPI con Ajuste de PPP/DPI de
Alta Precisión
●
Tecnología Inalámbrica de con Ratio de Refresco de 1000Hz
● Funciona tanto Conectado como en Modo Inalámbrico
● Retroiluminación de 11 Colores y 13 Modos
● Pantalla LCD con 2 Botones para configuración de
DPI, Ratio de Refresco, Distancia de Alzamiento y
Ajuste de Ángulos
● Batería de Litio 600mAh
●
Batería de hasta 20 Horas, Ratio de Refresco de 1000 Hz
● Indicador de Batería en la Pantalla LCD
● Interruptores OMRON con 50 Millones de Pulsaciones
Garantizadas
● Forma Ergonómica con Áreas Independientes de
Presión y Ranuras Dactilares
ESPAÑOL
● Sensor de Jogos Ótico 7200 DPI com sintonia fina DPI
● Tecnologia sem fio com taxa de Polling de 1000Hz
● Opera com fio e sem fio
● Luz de fundo 11 cores com 13 modos
● Tela LCD com 2 botões para DPI, taxa de Polling, LOD
e sintonia fina de posicionamento em ângulo
● Bateria de lítio 600mAh
● Vida da bateria até 20 horas na taxa de Polling de
1000Hz
● Indicador de bateria na tela LCD
● Interruptores OMRON com 50 milhões de acionamentos
● Forma ergonômica com superfície de pressão de
botões independentes e ranhuras para os dedos
PORTUGUÊS
● Optyczny sensor gamingowy 7200 DPI z precyzyjną
regulacją DPI
● Technologia bezprzewodowa z częstotliwością
próbkowania 1000 Hz
● Działa w układzie przewodowym i bezprzewodowym
● 11-kolorowe podświetlenie z 13 trybami
● Ekran LCD z 2 przyciskami do precyzyjnej regulacji DPI,
częstotliwości próbkowania, LOD i predykcji
● Bateria litowa 600 mAh
● Żywotność baterii do 20 godzin przy częstotliwości
próbkowania 1000 Hz
● Wskaźnik baterii na ekranie LCD
● Przełączniki OMRON na 50 mln naciśnięć
● Ergonomiczny kształt, niezależna powierzchnia
naciskowa i profile na palce
POLISH
中 文
● 电竞级7200 DPI光学感应器，可微调DPI数值
● 1000Hz无线传输技术
● 支持有线与无线双模功能
● 内建11种背光颜色与13种背光模式
● 可透过LCD屏幕与按钮，立即调整DPI、回报率、
工作高度、与直线修正等功能
● 配有600mAh锂电池
● 1000 Hz回报率下的电池寿命长达20小时
● LCD屏幕显示电池电量
● 保证5千万点击次数的 Omron 欧姆龙按键
● 符合人体工学的按键设计
한국어
●
DPI 미세 조정 기능을 가진 7200 DPI 광 게이밍 센서
●
1000Hz 폴링 속도의 무선 기술
●
유선 및 무선 모두 작동
●
13 가지 모드의 11가지 컬러를 가진 Backlight
●
DPI, 폴링 속도, LOD, 각도스냅핑(Angle anapping)등
미세 보정을 위한 2 개의 버튼이 있는 LCD 스크린
●
600mAh 리튬 배터리
●
1000 Hz 폴링 속도에서 배터리 수명 최대 20 시간
●
LCD 화면의 배터리 표시기능
●
5 천만번 클릭의 옴론 스위치
●
표면 및 Finger Grooves를 독립적인 버튼으로 누를 수
있는 인체 공학적인 디자인
日本語
● 7200 DPIの光学センサーを誇るゲーミングマウスで、
DPIを調整可能です
● ポーリングレートは1,000Hzで、
ワイヤレステクノロジーを採用しています
● ワイヤレスモードと有線モードの両方で動作します
● 11色 13種類のLEDバックライトカラーと モードを搭載しています
● 液晶スクリーンを搭載し、DPI、ポーリングレート、
LODと直線補正は2つのボタンによって調整可能です
● 600mAhのリチウム電池を装備しています
● 1,000 Hzのポーリングレートで最大20時間のバッテリ寿命です
● 液晶スクリーンの画面にバッテリー残量が表示されます
● 5千万回のクリックに耐えるオムロン製スイッチを
採用しています
● 人間工学に基づいたボタンデザインを採用しています
● Capteur de jeu optique 7200 DPI avec réglage fin
●
Technologie sans fil avec taux dʼinterrogation de 1000 Hz
● Fonctionne en mode filaire et sans fil
● Rétroéclairage à 11 couleurs avec 13 modes
● Écran LCD avec 2 boutons pour réglage fin des
paramètres DPI, taux dʼinterrogation, distance de
soulèvement (LOD) et correction dʼangle
● Batterie lithium 600 mAh
● Autonomie de la batterie pouvant atteindre 20 heures
au taux dʼinterrogation de 1000 Hz
● Indicateur de batterie sur lʼécran LCD
● Interrupteurs OMRON avec 50 millions de frappes
● Forme ergonomique avec surface indépendante de
pression sur les boutons et rainures pour les doigts
FRANÇAIS
● Sensore ottico da gioco 7200 DPI con regolazione DPI
● Tecnologia wireless con polling rate di 1000 Hz
● Funziona con rete cablata e wireless
● Illuminazione a 11 colori con 13 modalità
● Schermo LCD con 2 tasti per regolazione di DPI,
Polling Rate, LOD e Angle Snapping
● Batteria al litio da 600 mAh
● Autonomia della batteria fino a 20 ore con Polling Rate
a 1000 Hz
● Indicatore batteria sullo schermo LCD
● Interruttori OMRON con capacità di 50 milioni di
pressioni
● Forma ergonomica con tasto superficie di pressione
del tasto indipendente e scanalature per le dita
ITALIANO
● 7200 DPI optikai játékérzékelő finom DPI hangolással
● Vezeték nélküli tehnológia 1000 Hz lekérdezési rátával
● Működik vezetékkel és vezeték nélkül
● 11 színű háttérvilágítás 13 móddal
● LCD képernyő 2 gombbal a DPI, lekérdezési ráta,
LOD és szögbeállítás finom hangolásához
● 600 mAh lítium akkumulátor
● Akkumulátor élettartam akár 20 óra 1000 Hz
lekérdezési rátával
● Akkumulátor kijelző LCD képernyővel
● OMRON kapcsolók 50 millió nyomással
● Ergonomikus forma független gombnyomási felülettel
és ujjhelyekkel.
HUNGARIAN
● Optischer Gaming-Sensor mit 7200 dpi und
dpi-Feineinstellung
● Drahtlostechnologie mit 1000 Hz Abtastrate
● Funktioniert sowohl kabelgebunden als auch kabellos
● 11-farbige Hintergrundbeleuchtung mit 13 Modi
● LCD-Bildschirm mit 2 Tasten zur Feineinstellung von
dpi, Abtastrate, LOD und Winkeleinrastung
● 600-mAh-Lithium-Akku
● Akkulaufzeit von bis zu 20 Stunden bei einer
Abtastrate von 1000 Hz
● Akkustandanzeige am LCD-Bildschirm
● OMRON-Schalter mit 50 Millionen Anschlägen
● Ergonomische Form mit unabhängiger
Tastendruckoberfläche und Fingerkerben
DEUTSCH
● 7200 DPI оптический игровой сенсор с настройкой DPI
● Беспроводная технология с частотой опроса 1000 Гц
● Работает как с проводной, так и с беспроводной сетью
● 11-цветная подсветка с 13 режимами
● ЖК-экран с 2 кнопками для настройки DPI, частоты
опроса, LOD и настойки угловой привязки
● Литиевая батарея 600 мАч
● Срок службы батареи до 20 часов при частоте
опроса 1000 Гц
● Индикатор аккумулятора на ЖК-дисплее
● Переключатели OMRON с 50 миллионами нажатий
● Эргономичная форма с независимой кнопкой
нажатия на поверхности и пазами для пальцев
РУССКИЙ
12
3
Searching
4
Left Click ( OMRON 50 million )
Wheel Click ( ALPS Encoder )
Right Click ( OMRON 50 million )
Color Backlight Cycle
LCD Screen
Dongle
Wireless Power switch
Forward
Left Button
Right Button
Backward
7200 DPI
1000 Hz
7200 DPI
1000 Hz
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C
Tel:+886-6-356-0606
Service E-Mail: service@cougargaming.com
More information you will find at cougargaming.com
Compucase Enterprise Co.,Ltd.
All rights reserved.
Made in China
Please do not directly look into the optical beam!
DISCLAIMERS
● COUGAR does not authorize or endorse the user of COUGAR products as a part of, together with, or connected to,
life support devices, medical equipment in general, military equipment, traffic or transportation-related equipment or
disaster prevention systems.
● COUGAR is not liable for any damage, expense, loss, cost, injury or any other result derived from the use of COUGAR
products not specifically for PC gaming in the compatible operative systems indicated by COUGAR.
● COUGAR is not liable for any damage, expense, loss, cost, injury or any other result due to use of COUGAR products
not in strict accordance with the instructions provided by COUGAR in the instruction manual.
● Software, instruction manuals, consumables (for example mouse pads, mouse feet, etc.), boxes or other external
packaging are not covered by the warranty.
● For inquiries about the warranty, please contact us at service@cougargaming.com
This manual was created by Compucase Enterprise and may not be completely or partially copied, passed on, distributed
or stored without written consent by Compucase Enterprise.
COUGAR® is a registered brand of Compucase Enterprise Other product and company names mentioned in this
documentation may be brands or trademarks of their respective owners.
Compucase Enterprise reserves the right to make changes concerning the contents of the manual and the technical data
of the product without previous announcement.
All o t he r regist ered tra d ema r k s
be lon g to t h ei r r e spe ctiv e
comp an i e s.
MSIP-REI-CEE-
COUGAR
SURPASSION RX
Tested to comply with FCC standards
FOR HOME OR OFFICE USE
R63088
RoHS
COUGAR USA Technical Service
Tel: (833) 256-3778
Mail: rma@compucaseusa.com
https://cougargaming.com/support/contact/upload/
WARRANTY AGREEMENT
● If the product has defects in material or manufacture, COUGAR will provide product repair and replacement service
within the warranty period.
● Our warranty service is based on the date of the invoice or warranty card (must be affixed with the store stamp).
If you lose the aforementioned evidence, we will apply the original shipping date of the product as the beginning date
of warranty period. The shipping date will be identified by the product serial number(S/N).
CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED
● Any fault or damage caused by natural disasters (including storm, fire, flood, thunder, earthquake, etc).
● Any fault or damage caused by accidental factors and man-made reasons (including hit, scrape, crash, moving,
compression, stain, corrosion, use of incurred on unsuitable voltage, computer virus, riot, misuse, malicious damage, etc).
● Use in an improper operating environment (including high temperature, high humidity, water inflow, etc).
● Inability to provide the product warranty card, purchase receipt or invoice to prove the product is still within the
warranty period and the shipping date of the product is out of warranty.
● The warranty card or product serial number has been altered or its number is hard to identify.
● The warranty period has expired.
● Any fault or damage caused by non-compliance with regulations stated on the user manual or improper, rough and
careless treatment.
● Any fault or damage caused by use of parts not certified by COUGAR original manufacturer.
●
The problem is caused by improper repair or adjustment by the buyer or any manufacturer without authorization from COUGAR.
● The product is not acquired from an authorized distributor of the company or is acquired from illicit sources.
● Paper carton, instruction and other accessories are not warranted.
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR SURPASSION RX gaming mouse
Warranty : 1 Year
This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.
COUGAR SURPASSION RX Gaming Mouse
Dongle / Cable / User Manual
To achieve optimal performance, it is highly recommended
that you use this product with COUGAR Mouse Pads.
LR
Press the right button to activate or
deactivate Angle Snapping.
Press the right button to switch between
L (Low distance) and H (High distance).
Press the right button to switch between
the four polling rate levels.
Press and hold the right button three seconds
to switch between these three customization
modes. The active setting will be show on
the lower part of the LCD screen.
(LOD: Lift off distance, AS: Angle snapping)
Press and hold the left button for three
seconds; when the DPI number on the LCD
screen starts to blink, use the forward/
backward buttons to increase or decrease the
DPI level in 50 DPI intervals. When you’ve
reached the desired DPI level, press the Left
button again to start using this mode.
Press the left button to switch between the
six DPI modes. The default DPI values for
each of the six modes are
400/800/1600/3200/5600/7200 DPI
Click
LR
Click
LR
Click
LR
Click
R
3 Sec 3 Sec 3 Sec
R R
AS : off
L
Click
3
2
год и месяц изготовления продукции указаны в серийном номере продукта. (существует 2 способа
определения даты изготовления, оба способа описаны ниже)
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702
После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже, и означают
год, последующие две цифры – месяц изготовления.
Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02
● Например, AG = 17 = 2017 год
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B C E F G I JD H
1 3 4 5 6 8 9 02 7
A
B
1600 DPI
1000 Hz
1600 DPI
1000 Hz
1600 DPI
1000 Hz
1600 DPI
LOD : L
1600 DPI
LOD : L
1600 DPI
AS : of f
1600 DPI
AS : off
To restore the default settings, please press and hold the forward, backward and wheel buttons and, without releasing
them, connect the mouse to the computer.
2
1
3
1
22
Connect the dongle to your computer’s USB port and, within 15 seconds of connecting it, press the right mouse button
and the wheel button simultaneously to pair mouse and dongle.
within 15 seconds
Please use the mouse in wired mode to recharge its battery.
Please press any
2050 DPI
1000 Hz
Produktspezifikationen
| Marke: | Cougar |
| Kategorie: | Maus |
| Modell: | Surpassion RX |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Cougar Surpassion RX benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Maus Cougar
5 September 2024
21 August 2024
21 August 2024
21 August 2024
21 August 2024
21 August 2024
21 August 2024
21 August 2024
21 August 2024
21 August 2024
Bedienungsanleitung Maus
- Maus 3M
- Maus A4Tech
- Maus Acer
- Maus Anker
- Maus Approx
- Maus Asus
- Maus BeeWi
- Maus BenQ
- Maus Connect IT
- Maus Corsair
- Maus Exibel
- Maus Gembird
- Maus Genius
- Maus Gigabyte
- Maus Gyration
- Maus Hama
- Maus HP
- Maus HyperX
- Maus KeepOut
- Maus Kensington
- Maus Lexibook
- Maus LogiLink
- Maus Logitech
- Maus Mad Catz
- Maus Manhattan
- Maus Maxxter
- Maus Medion
- Maus Microsoft
- Maus Nacon
- Maus Nedis
- Maus NGS
- Maus Niceboy
- Maus Philips
- Maus Rapoo
- Maus Roccat
- Maus Saitek
- Maus Sandberg
- Maus Seal Shield
- Maus Sharkoon
- Maus SilverCrest
- Maus Speedlink
- Maus SteelSeries
- Maus Sweex
- Maus T'nB
- Maus Targus
- Maus Trust
- Maus Typhoon
- Maus Verbatim
- Maus Watson
- Maus Zalman
- Maus LG
- Maus Buffalo
- Maus CSL
- Maus Eminent
- Maus ISY
- Maus Denver
- Maus König
- Maus MarQuant
- Maus Renkforce
- Maus Vivanco
- Maus Xiaomi
- Maus Livoo
- Maus Cherry
- Maus Icy Box
- Maus Dell
- Maus LC-Power
- Maus Lenovo
- Maus MSI
- Maus Acme
- Maus Razer
- Maus Logik
- Maus Adj
- Maus Genesis
- Maus Cooler Master
- Maus NZXT
- Maus SilverStone
- Maus Thermaltake
- Maus Bakker Elkhuizen
- Maus Ednet
- Maus KeySonic
- Maus Penclic
- Maus Kogan
- Maus Energy Sistem
- Maus Conceptronic
- Maus EVOLVEO
- Maus I-Tec
- Maus SPC
- Maus Digitus
- Maus Mediacom
- Maus Tracer
- Maus BlueBuilt
- Maus Defender
- Maus Wortmann AG
- Maus Speed-Link
- Maus Ducky
- Maus Sven
- Maus Vorago
- Maus X9 Performance
- Maus Krom
- Maus Gamesir
- Maus INCA
- Maus IRIS
- Maus Media-tech
- Maus Sanwa
- Maus Steren
- Maus BakkerElkhuizen
- Maus Alienware
- Maus Man & Machine
- Maus Siig
- Maus Best Buy
- Maus Ozone
- Maus Iogear
- Maus Konix
- Maus Mitsai
- Maus Kunft
- Maus ModeCom
- Maus Mousetrapper
- Maus NPLAY
- Maus XPG
- Maus Natec
- Maus Posturite
- Maus Adesso
- Maus ThunderX3
- Maus V7
- Maus GMB Gaming
- Maus Equip
- Maus Raidsonic
- Maus Satechi
- Maus NOX
- Maus Xcellon
- Maus Fractal Design
- Maus Hamlet
- Maus UGo
- Maus Mars Gaming
- Maus Vakoss
- Maus Perixx
- Maus Savio
- Maus Vultech
- Maus Contour Design
- Maus ENDORFY
- Maus TEKLIO
- Maus Canyon
- Maus Keychron
- Maus R-Go Tools
- Maus Evoluent
- Maus Humanscale
- Maus G-Cube
- Maus White Shark
- Maus IOPLEE
- Maus Swiftpoint
- Maus 3Dconnexion
- Maus Xtrfy
- Maus Micro Innovations
- Maus Goldtouch
- Maus Silver Eagle
- Maus Sygonix Connect
- Maus Kondator
- Maus Spartan Gear
- Maus Raspberry Pi
- Maus Urban Factory
- Maus CoolerMaster
- Maus Bluestork
- Maus Balam Rush
Neueste Bedienungsanleitung für -Kategorien-
15 Oktober 2024
15 Oktober 2024
14 Oktober 2024
12 Oktober 2024
11 Oktober 2024
9 Oktober 2024
7 Oktober 2024
7 Oktober 2024
7 Oktober 2024
6 Oktober 2024
