Seite 1/4
Exceptional efficiency: This 80 Plus
Gold certified unit can achieve Titanium
level efficiency at 10% and 20% loads in a
115V test.
Advanced thermal performance: A
hexagonal fan cover with a maximum 80%
airflow intake and a synchronous
rectifier dedicated heat sink provide
enhanced thermal performance.
ATX 3.0 support & a durable 12VHPWR
cable: Includes ATX 3.0 support and a 90-
degree 12+4pin (12VHPWR) PCIe 5.0 cable
featuring lower temperatures, enhanced
durability, and improved safety.
Silent fan performance with a zero-RPM
mode: A zero-RPM default mode
automatically turns the fan on when your
PC reaches a specific temperature.
Japanese-designed main capacitor: A
large, high-quality Japanese main capacitor
feature reduced ripple noise and enhanced
reliability.î µ
GX II Gold 850
The GX II Gold brings a new standard of durability and
efficiency to Cooler Master’s lineup of power supply units.
This 80 Plus Gold certified unit can achieve Titanium level
efficiency at light loads in a 115V test.
With an APFC half bridge LLC and DC- -DC design, the to
GX II Gold has achieved an 80 Plus Gold efficiency
certification with top-tier performance. A zero-RPM
default mode reduces noise and improves heat
dissipation. Combined with an ATX 3.0 12VHPWR native
cable featuring a space-saving, durable 90-degree
connector, the GX II Gold is a powerhouse.
BUIT LASTTO
Fully modular cabling: Efficiently reduces clutter,
increases airflow, and improves overall efficiency
and thermal performance.
10-year warranty: This unit comes with a
standard limited manufacturing warranty of 10
years from the date of purchase.
FEATURE HIGHLIGHTS
Exceptional efficiency
Can achieve 80 Plus Titanium level
efficiency during general use.
Advanced thermal performance
An airflow maximum of 80% from
the hexagonal fan cover
enhances thermal performance.
80 Plus Gold efficiency certification Fully modular cabling
Silent and smart performance A durable 12VHPWR cable
Certified to achieve more than 90%
efficiency at typical loads.
Modular cabling reduces clutter and
improves overall thermal performance.
Zero-RPM default mode below 40%
loads.
An advanced thermal structure
and flexible cable provide
improved safety.
Product Name II Gold 850WGX
Item Code MPX- - -2***8503 AFAG
ATX Version ATX 12V Ver. 3.0
PFC Active PFC
Input Voltage -100 240V
Input Current -10 5A
Input Frequency - 60Hz50
Dimensions (L x W x H) 160 x 150 x 86mm
Fan Size 120mm
Fan Bearing HDB
Fan Speed rpm2500
Efficiency ≥90% @ Typical Load
80 PLUS Rating 80 PLUS Gold
ErP 2014 Lot 3 Yes
Operating Temperature 0 ~ 40℃
Power Good Signal -150 ms100
Hold TimeUp ≥16ms @80%Load
MTBF >100,000 hours
Protections OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge Inrush&
Protection
Regulatory cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA,
RoHS2.0 / BIS, KC (based requeston region’s .)
Connectors
ATX 24 Pin x1 = 1x (550mm)
EPS 4+4 x1 = 1x (600mm)Pin
EPS 8 x1 = 1x (600mm)Pin
SATA x6 = 2x (500(s)+120(s)+120(s)+120(p)mm)
Peripheral x2 = 2x (500(s)+120(s)+120(s)+120(p)mm)4 Pin
PCI Pin-e 6+2 x4 = 2x (500+120mm)
12VHPWR x1 = 1x (650mm)
AC INPUT -240V~ 10 - 5A 50 - 60Hz100
DC OUTPUT +3.3V - +5Vstb+5V +12V 12V
20A 20A 3A70.8A 0.3A
TOTAL POWER 849.6W 3.6W120W 15W
850W
