For Outdoor Use Only
www.coleman.com
NOTE:
Propane cylinder is not
included.
IMPORTANT
Read this manual carefully before assembling,
using or servicing this grill. Keep this manual
for future reference. If you have questions
about assembly, operation, servicing or repair
of this grill, please call Coleman at 1-800-835-
3278 or TDD: 1-316-832-8707. In Canada call
1-800-387-6161.
Gas Barbecue
Use, Care & Assembly Manual
With Grill Lighting Instructions
Model 9955 Series (LP Gas)
ASSEMBLER/INSTALLER:
Leave these instructions with the consumer.
CONSUMER/USER:
Read all instructions and keep in a safe place for future reference.
English - 2
This manual contains important information about the
assembly, operation and maintenance of this outdoor
propane appliance. General safety information is
presented on this page and is also located throughout
these instructions. Particular attention should be paid to
information accompanied by the safety alert symbol:
“ DANGER”, “ WARNING”, “ CAUTION”.
Keep this manual for future reference and to educate
new users of this product. This manual should be read in
conjunction with the labeling on the product.
Safety precautions are essential when any mechanical or
propane fueled equipment is involved. These precautions
are necessary when using, storing, and servicing. Using
this equipment with the respect and caution demanded will
reduce the possibilities of personal injury or property damage.
The following symbols shown below are used
extensively throughout these instructions. Always heed
these precautions, as they are essential when using any
mechanical or propane fueled equipment.
CALIFORNIA PROPOSITION 65:
WARNING: This fuel, and by products of combustion of this
fuel, contain chemicals known to the state of California to
cause cancer, birth defects, or other reproductive harm.
Technical Characteristics
General Safety Information
Contents
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
personal injury, or property damage.
CAUTION
• DO NOT move grill while it is lit.
• Keep outdoor cooking gas appliance area clear and
free from combustible materials, gasoline and other
flammable vapors and liquids.
WARNING
WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
WARNING
1. Do not store or use gasoline or other
flammable liquids or vapors in the vicinity
of this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
WARNING
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
DANGER
• FOR OUTDOOR USE ONLY. NEVER operate grill in
enclosed areas, as this could lead to gas accumulating
from a leak, causing an explosion or a carbon monoxide
buildup which could result in injury or death. DO NOT
use in garages, breezeways, sheds or any
enclosed area.
• NOT FOR USE BY CHILDREN.
• If these instructions are ignored, a hazardous fire
or explosion could result in physical injury, death or
property damage!
DANGER
Input Rating: 1 burner tube @ 11,000 BTU/H
Category: Pressure regulated propane
Fuel: 16.4 oz. disposable propane cylinders
Regulator: 9955 must be used
Contents ................................................................................................... 2
Technical Characteristics ......................................................................... 2
General Safety Information ....................................................................... 2
General Installation ................................................................................... 3
Portable L.P. Gas Barbecue Cylinders ..................................................... 3
Grill Features ............................................................................................ 4
Assemble Grill .......................................................................................... 5
Installing 1 lb. Propane Cylinder ............................................................... 6
Burner and Orice .................................................................................... 6
Leak Testing - Disposable LP Gas Cylinders ........................................... 7
How to Check for Leaks ........................................................................... 7
Fixing A Fuel Leak .................................................................................... 7
Start-Up Check List .................................................................................. 7
Lighting Instructions ................................................................................. 8
Lighting The Burner .................................................................................. 8
Shutting Off the Grill ................................................................................. 9
General Use and Correct Burner Flames ................................................. 9
Grilling Tips and Hints .............................................................................. 9
In Case of Grease Fire ............................................................................ 10
Cooking Methods ................................................................................... 10
Care, Maintenance and Cleaning ........................................................... 10
Cleaning the Venturi ............................................................................... 11
Moving and Storage ............................................................................... 12
Troubleshooting ...................................................................................... 12
Replacement Parts List — 9955 Series .................................................. 15
Warranty ................................................................................................. 16
English - 3
General Installation
Portable L.P. Gas Barbecue Cylinders
• Installation must conform with local codes or, in the
absence of local codes, with either the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane
Installation Code, CSA B149.1, or Propane Storage and
Handling Code, CSA B149.2, as applicable.
• To check local codes, see your local L.P. gas dealer
or natural gas company listed in the Yellow Pages for
recommended installation procedures and regulations.
Connections must comply with local requirements and
are the sole responsibility of the person performing
the work.
Liqueed Petroleum gas (abbreviated L.P. gas or
propane), is highly ammable. It becomes liquid when
stored under high pressure inside a cylinder and vaporizes
when released. L.P. gas is heavier than air and tends to
collect in low areas. It is important that there are no leaking
connections on your gas grill that could cause a re or
explosion (see the section titled “LEAK TESTING”).
Portable LP gas grills require a fuel delivery system which
is comprised of an adjustable regulator [A] and an L.P.
gas supply cylinder [B]. (Fig. 1) Illustration in Fig. 1 is for
description purposes only.
Cylinder Specications
• All L.P. gas cylinders used with this appliance shall
be constructed and marked in accordance with the
Specifications for L.P. Gas Cylinders of the U. S.
Department of Transportation (DOT) or the National
Standard of Canada, CAN/CSA-B339, Cylinders, Spheres
and Tubes for Transportation of Dangerous Goods; and
Commission, as applicable; and a cylinder connection
device compatible with the connection for outdoor
cooking appliances.
• Read labels on the L.P. Gas Supply Cylinder.
Your new barbecue grill is equipped with a CGA # 600
regulator [A]. DO NOT attempt to connect this regulator
to any other disposable L.P. cylinder not equipped with a
mating CGA # 600 tting [C]. This grill may only be used
with the pressure regulator supplied with this unit, or
pressure regulators specied by Coleman for use with this
unit. Replacement regulators must only be those specied
by Coleman. (Fig. 1)
WARNING
• DO NOT attempt to adjust the regulator as this
could create a situation causing personal injury or
property damage.
WARNING
• NEVER use charcoal briquettes or lighter fluid in a
gas grill.
• Grill is hot when in use; to avoid burns, DO NOT touch
any hot grill surface. Keep children and pets away from
hot grill.
• NEVER leave the grill unattended while it is in use.
• It is your responsibility to assemble, install, operate and
care for your gas grill properly.
• DO NOT use gas grill indoors.
• Under some circumstances, propane may lose the
distinctive odor that was added. Other strong odors may
hide or mask the odor of propane. Colds, allergies, sinus
congestion, and the use of tobacco, alcohol or drugs
may impair your ability to detect the odor of propane.
WARNING
This appliance is not to be installed in or on a recreational
vehicle and/or boat.
Follow these safety rules before each use:
1. A minimum clearance of 24 inches from the left,
right and back sides of the grill must be maintained
between the grill and any combustible construction
such as wood siding of a building.
2. Never locate the grill under an unprotected
combustible material or overhang.
3. Do not obstruct the flow of combustion and
ventilation air.
4. The grill should be level and not facing directly into
the wind.
WARNING
A liquid propane tank, not connected for use with this gas
barbecue, shall not be stored in the vicinity of this or any
other appliance.
WARNING
A
B
C
Fig. 1
