Portable Mp3/CD /AM/FM Stereo Tuner
Tuning Control Volume Control
AC Socket
FM ST. POWER
Frequency Dial
Handle
CD Door
Phone Jack
Function
Selector
DIGIT
PROGRAM
LCD
Display
Antenna
Band Switch
PREVIOUS
NEXT
PLAY/PAUSE
STOP
MODE
LOCATION OF CONTROLS IMPORTANT SAFEGUARDS
IMPORTANT
CONCERNING COMPACT DISC
CARE and MAINTENANCE
MODEL NO: MP-CD 451
2
6
INTRODUCTION
POWER SUPPLY
3
OFF position to stop radio.
or a MP3 disc.
HEADPHONES(Not included)
RADIO OPERATION
CD/MP3 OPERATION
4
1
and
TRACKING mode
1. Press the button once to get the beginning of current track.
2. Repeatedly press the button to go to the previous tracks.
3. Press the button to go to the next track.
4. To fast backward/fast forward through the disc,
press and hold the button.
1. Under the stop mode or the playback mode, repeatedly press
the DIGIT button, the digit starts flashing for each time DIGIT
button is pressed. For MP3 there are three digits and CD two
digits.
2. Press SEARH button to enter the desired track and press
PLAY/PAUSE button to start playback.
1. Press the PROGRAM button at stop mode. Program indicator
appears on the screen.
2. Press the or button to select the desired track, and
then press PROGRAM to confirm.
3. Repeat step 2 to set up to 20 tracks.
4. Press the PLAY/PAUSE button to start playing.
5. To stop the program play, press the STOP button once.
6. To exit program mode, press the STOP button twice, program
indicator disappears and the memory will be erased.
/
TROUBLE SHOOTING
Should your player develop a problem, please check below
before requesting service.
* Check if the power cord has been properly
connected to the power outlet.
* Be sure to select a sound source.
* Unplug the main unit, and then reconnect it. This
allows the unit to reset itself after a power surge
or power interruption.
* Increase the volume.
* Disconnect any headphones.
* No disc. Load a disc.
* Disc has been loaded upside down. Place the
disc withthe label side up.
* Disc is damaged or dirty. Clean the disc or try
another one.
* Moisture may be condensed inside the player.
Remove the disc and leave the unit power on for
one or two hours.
* Disc is incorrect type for the player.
* You may be in an area of weak signal coverage.
Symptom Check and Action
System does
not function at
all
No sound
CD does
not play
Radio does
not work
Power Supply: 110V~60Hz/220V~50Hz dual voltage
Applicable disc: CD/CD-R/MP3
Power Consumption: 4.2W
Output Power: 1W x2
Speaker: 8 OHM
Dimensions: 210(L) x143.5 (H) x220 (W) mm (main unit)
Weight: 1650g (main unit)
RADIO
Frequency Range: AM: 530KHz - 1700KHz
FM: 88MHz - 108MHz
CD Player
Laser Wavelength: 760 ~ 800 nm
Tracking Method: 3-spot error detection/3.86 mm lens
Design and specifications are subject to change without notice.
SPECIFICATION
