Seite 1/4
3
ERPOW
BASS TL
REB E
LINE L INE LI NE LINE
LVOUME L
VO UME LVOUME L
VOUME
EL
TR B E E LTRB EEBL
TR EEL
TRB E
0000 0
00
555
0000
ASSB ASSB ASSB SSBA
5555
EFF EF F EFF EF F
MIC IN
MIC I N
MIC I N MIC IN
CAD/TPE EFF S RMATE
CN EL
HA N 1C N EL
HA N 2 C N L
HA NE
3CNEL
4
HA N
ZATI NEQUALI O
(12). REC OUT JACKS(REC )
(13). TAPE IN(CD/TAPE IN)
These are input jacks that allow the signal from an external device to be added to the
MAIN output.
(14). SEND JACKS(SEND)
The signal level is sent to the built-in digital effect through the SEND jacks.
(15). RETURN JACKS(RETURN)
The level of the effect signal is returned from the built-in digital effect to the MAIN bus thr-
ough the RETURN jacks.
Please read this manual carefully and proper take care of this manual
USER'S MANUAL
4. SPECIFICATIONS
Power handling: 100W
Frequency response: 70Hz-18KHz
Sensitivity(1m/1W): 93dB
Nominal impedance: 4ohms
LF driver: 1x10”with 1.5” voice coil
HF driver: 1x1” voice coil
HF protection: PTC protective circuit
Dimensions(WxDxH) 480x310x643mm
Net weight: 23.7KGS
CAUTION: Describes precautions that should be observed to prevent the danger of the apparatus.
* 4 Channel powered mixer
* Stereo output 100 watts RMS; load 4 Ohms;
* ”4 input connectors on each channel; XLR or 1/4 phone jack.
* CD/TAPE input on back panel with level control on the front panel.
* Treble bass delay and level control on each channel., ,
* Master volume control.
* :MIXER (1) built-in Electronic Reverb.
ON: Denotes the apparatus is turned on.
OFF: Denotes the apparatus is turned off.
WARNING: Describes precautions that should be observed to prevent the danger of injury or death
to the operator.
2 INTRODUCTION.
1 IMPORTANT SAFETY SYMBOLS.
3 FEATURES.
1
REC IN
CD/TAPE
L
R
EFFECT LOOP
SEND RETURN
2
Front panel
(4) (1)(2)(3) (6)(7) (8) (9) (5)
(10) (11)
(12) (13) (14) (15)
Rear panel
(1). EQUALIZER CONTROLS(TREBLE,BASS)
This is a 2-band equalizer that adjusts the high frequency range, mid frequency range, and
low frequency range of each channel.
TREBLE: 12.5KHz 15dB shelving type±
BASS: 80Hz 15dB shelving type .±
(2) EFFECT CONTROL(EFF)
This controls the amount of signal that is sent to the EFFECT bus for each channel.
(4) CHANNEL INPUT JACKS (MIC IN ,LINE) ~1 4
These are the input JACKS for channels 1~4.
(3) VOLUME CONTROL(VOLUME)
This adjusts the output volume for each channel.
(5) POWER SWITCH
This switch turns on/off the power of MIXER.
(6). EQUALIZATION CONTROL(EQUALIZATION)
This is a 3-band equalizer that allows you to adjust the frequency response of the MAIN bus
signal.
(7). TAPE IN CONTROL(TAPE IN)
This adjusts the amount of signal that is sent from the TAPE IN jack to the MAIN bus.
(8) EFF RETURN CONTROL(EFF RETURN)
This adjusts the level of the effect signal which is returned from the built-in digital effect to the
MAIN bus.
(9) MASTER CONTROL(MASTER)
This adjusts the final level of the MAIN bus.
Protective grounding terminal
Alternating current/voltage
Hazardous live terminal
The symbol is used to indicate that some hazardous live terminals are involved within this
apparatus, even under the normal operating conditions, which may be sufficient to constitute
the risk of electric shock or death.
The symbol is used in the service documentation to indicate that specific component shall
be replaced only by the component specified in that documentation for safety reasons.
CHANNEL 4
REC IN
CD/TAPE
L
R
(10). MAINS INPUT
(11). FUSE: ~115V-T3 15AH/250V.
~230V-T1.6AH/250V
