CLARITY LIMITED WARRANTY
Clarity warrants its products only to the original purchaser, for its own use, to be free from
defects in materials and workmanship under conditions of normal use and service for a period
of one year from the date of shipment. This Limited Warranty obligation shall be limited to the
replacement, repair or refund of any such defective device within the warranty period, provided
that:
1. inspection by Clarity indicates the validity of the claim;
2. the defect is not the result of damage, misuse or negligence after the original shipment;
3. the product has not been altered in any way or repaired by others and that factory sealed
units are unopened (a service charge plus parts
and labor will be applied to units defaced or physically damaged);
4. freight charges for the return of products to Clarity are prepaid;
5. all units 'out of warranty' are subject to a service charge. The service charge will cove minor
repairs (major repairs will be subject to
additional charges for parts and labor).
This Limited Warranty is in lieu of and excludes all other warranties, expressed or
implied and in no event shall Clarity be liable for any anticipated profits, consequential
damages, loss of time or other losses incurred by the buyer in connection with the
purchase, operation, maintenance, installation, removal or use of the product. The
maximum liability of Clarity under this warranty is limited to the purchase price of the
specific Product covered by the warranty.
Disclaimer. Except for the Limited Warranty provided herein, the product is provided “as-is”
without any warranty of any kind whatsoever including, without limitation, any WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT.
This warranty specifically excludes damage incurred in shipment. In the event a product is
received in damaged condition, the carrier should be notified immediately. Claims for such
damage should be filed with the carrier involved in accordance with the F.O.B. point.
Headquarters:
Clarity
5614 Hollins Road Roanoke, VA 24019-5056
Phone: (540) 563-2000 FAX: (540) 362-9800
TECHNICAL ASSISTANCE
Assistance in troubleshooting is available from the factory. When calling,
you should have a VOM available and call from the job site. Call
(540) 563-2000 and press 1 for Technical Support or visit our website
at http://www.clarity-com.com.
CLARITY equipment is not field repairable. Should repairs be necessary,
attach a tag to the unit clearly stating company name, address, phone
number, contact person and the nature of the problem. Send the unit to:
Clarity
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
INSTALLATION INSTRUCTIONS FOR
DESIGNER WALL SPEAKERS
MODEL NO. S-527A
Issue 1 947441A
CLARITY DESIGNER WALL SPEAKERS
Clarity's Designer Wall Speaker, Model S-527A, is designed for areas that
require a stylish appearance. This speaker incorporates a
speaker/transformer/ baffle assembly for use with any Clarity Mixer-Amplifier
to provide background music or voice paging. The speaker is available in
black or white with a color coordinated cloth grille.
Model S-527A-BK - Black
Model S-527A-W - White
TECHNICAL SPECIFICATIONS
Frequency Response 100 to 10kHz
Max. Power Capability 5 watts
SPL 1 watt/1 meter 1kHz 93 dB
Speaker 5" w/10 oz. magnet, 8 Ohm
WIRING
Make connections as shown in Figure 1.
FIGURE 1
MOUNTING
The baffle provides two methods of mounting:
1. The baffle can be suspended from a nail or hook by a "hanger" that
is attached to the housing. See Figure 2.
2. The unit can be attached to a wall using two mounting bosses.
Distance between the mounting boss centers is 8.5 inches. Remove
grille and secure baffle to wall with screws. This mounting provides
better low frequency response for music and a more secure
attachment to the wall. See Figure 3.
FIGURE 2
FIGURE 3
25 Volt Line
70 Volt Line
Color
Black
Brown
Red
Orange
Green
White
Designation
Common
5 Watt
2.5 Watt
1.25 Watt
0.625 Watt
0.312 Watt
Color
Black
Green
White
Blue
Grey
Violet
Designation
Common
5 Watt
2.5 Watt
1.25 Watt
0.625 Watt
0.312 Watt
