Seite 1/52
C H A P T E R
1-1
Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router
OL-32185-02
1
Overview of the Cisco 4000 Series ISR
This chapter contains the following sections:
•About the Cisco 4000 Series ISR, page 1-1
•Safety Warnings, page 1-6
•Chassis Views, page 1-6
•Locating the Serial Number, PID, VID, and CLEI, page 1-25
•Hardware Features, page 1-26
•About Slots and Interfaces, page 1-39
•Specifications, page 1-42
•Periodic Inspection and Cleaning, page 1-51
About the Cisco 4000 Series ISR
The Cisco 4000 Series Integrated Services Routers (ISRs) are modular routers with LAN and WAN
connectivity. They support several interface modules, including Cisco Enhanced Service Modules
(SM-X), and Cisco Network Interface Modules (NIMs).
The Cisco 4000 Series ISR target these applications:
•Enterprise applications—Intended as the mid-size aggregation and gateway router typically residing
in a regional or large branch office:
–
WAN aggregation at Cisco Enterprise core
–
Internet gateway
–
Branch or regional office aggregation
–
Remote access aggregation
•Service provider applications—Intended for high-end Enterprise Branch environments:
–
High-end customer premises equipment (CPE) for business-quality Internet access
–
Service provider leased line aggregation
–
Provider edge (PE) and high-end customer edge (CE) for Layer 2 VPN or Layer 3 VPN services
–
Low-end Ethernet aggregation
1-2
Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router
OL-32185-02
Chapter 1 Overview of the Cisco 4000 Series ISR
About the Cisco 4000 Series ISR
The Cisco 4000 Series ISR are available in these models:
•Cisco 4451-X ISR
•Cisco 4431 ISR
•Cisco 4351ISR
•Cisco 4331ISR
•Cisco 4321 ISR
•Cisco 4221 ISR
The sections in this documentation apply to all platforms unless explicitly stated otherwise.
Cisco 4451-X ISR
The Cisco 4451-X ISR provides these capabilities:
•Two single-wide SM slots that can be converted into one double-wide SM slot.
•Three single-wide NIM slots that can be converted into one double-wide (NIM1 and NIM2) and one
single wide NIM slot (NIM3).
•One 10/100/1000 RJ-45 Ethernet port for system management (labeled {GE 0} with {MGMT} on
the left of the connector)
•Two USB Type A host ports
•One USB mini-Type B console (placed next to the RJ-45 console port)
•One RJ-45 console port
•One RJ-45 auxiliary port
•Four combo ports that can function as SFP or RJ-45 ports:
–
4 10/100/1000 RJ-45 Ethernet ports (labeled GE 0/0/0, 0/0/1, 0/0/2, and 0/0/3)
–
4 100/1000 SFP Ethernet ports (labeled SFP 0/0/0, 0/0/1, 0/0/2, and 0/0/3)
•LEDs for Ethernet and console status
•LED for the CompactFlash memory card
•Two DDR3-240 pin Control Plane DIMM (dual in-line memory module) slots supporting
replaceable DIMM modules
•One DDR3-240 pin Forwarding Plane DIMM slot, which can be supporting replaceable DIMM
modules
•One CompactFlash slot, which is serviceable when the fan tray is removed
•One internal 30-W PoE daughter card for two of the front Gigabit Ethernet ports (labeled GE 0/0/0
and 0/0/1)
•One available ISC slot for an op gh-density Packet Voice Digital tional serviceable daughter card hi
Signal Processor Module (PVDM4) to add IP voice and video capability
•Environment monitoring
•Field replaceable fan tray
•Dual redundant power supply units (PSUs)
•Support for dual 500-W PoE converter power supply module
1-3
Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router
OL-32185-02
Chapter 1 Overview of the Cisco 4000 Series ISR
About the Cisco 4000 Series ISR
Cisco 4431 ISR
The Cisco 4431 ISR provides these capabilities:
•3 single-wide NIM slots that can be combined into one double-wide (NIM1 and NIM2) and one
single-wide NIM.
•10/100/1000 RJ-45 Ethernet port for system management (labeled GE mgmt)
•Two USB 2 Type A host ports
•One USB mini-Type B console (placed next to the RJ-45 console port)
•One RJ-45 console port
•One RJ-45 auxiliary port
•Four combo ports that can function as SFP or RJ-45 ports:
–
4 10/100/1000 RJ-45 Ethernet ports (labeled GE 0/0/0, 0/0/1, 0/0/2, and 0/0/3)
–
4 100/1000 SFP Ethernet ports (labeled SFP 0/0/0, 0/0/1, 0/0/2, and 0/0/3)
•LEDs for Ethernet and console status
•Two DDR3 240-pin Control Plane DIMM (dual in-line memory module) slots supporting
replaceable DIMM modules
•One DDR3 240-pin Forwarding Plane DIMM slot supporting replaceable DIMM modules
•One eUSB flash slot, which is serviceable
•One internal 30-W PoE daughter card for two of the front Gigabit Ethernet ports (labeled GE 0/0/0
and 0/0/1)
•One available ISC slot for an op gh-density Packet Voice Digital tional serviceable daughter card hi
Signal Processor Module (PVDM4) to add IP voice and video capability
•Environment monitoring
•Field replaceable fan tray
•Dual redundant power supply units (PSUs)
•Support for dual 500-W AC+PoE power supply units
Cisco 4351 ISR
The Cisco 4351ISR provides these capabilities:
•Two single-wide SM slots that can be converted into one double-wide SM slot.
•Three single-wide NIM slots that can converted into one double-wide (NIM1 and NIM2) and one
single-wide NIM slot (NIM3).
•One 10/100/1000 RJ-45 Ethernet port for system management (labeled {GE 0} with {MGMT} on
the left of the connector)
•Two USB Type A host ports
•One USB mini-Type B console (placed next to the RJ-45 console port)
•One RJ-45 console port
•One RJ-45 auxiliary port
