CHANDLER LIMITEDÂź
TG MICROPHONE
USER MANUAL
OFFICIAL
EQUIPMENT
UM
UM
UM
UM
TGMIC
TGMIC
TGMIC
TGMIC-
-
-
-061919
061919
061919
061919
For more information, visit www.chandlerlimited.com. © 2019 Chandler Limited, Inc. All Rights Reserved. UM TGMIC-061919
Abbey Road Studios, EMI, TG, Curve Bender and their associated logos are trademarks of EMI (IP) Limited.
TG MICROPHONE
INTRODUCTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3
TG Microphone - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3
History ------------------------------------------------------ 3
IMPORTANT PROCEDURES & QUICK START - - - - - - - - - - - - - - - - - - - - - - - - - - - 4
Shock Mount -------------------------------------------------- 4
Connections --------------------------------------------------- 4
Power-up ----------------------------------------------------- 4
Warm-up ----------------------------------------------------- 4
Power Down -------------------------------------------------- 4
Vocals ------------------------------------------------------- 4
OPERATING INSTRUCTIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
Dual Tone System - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
System A ----------------------------------------------------- 5
System B ----------------------------------------------------- 5
Tape Equalizer - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
Tape Equalizer Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
Tape Equalizer Curves - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6
Low Cut ----------------------------------------------------- 6
Polar Patterns - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6
Cardioid ----------------------------------------------------- 6
Omni ------------------------------------------------------- 7
Pad --------------------------------------------------------- 7
POWER & CONNECTIVITY - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8
Microphone Input - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8
Microphone Output - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8
Ac power ---------------------------------------------------- 8
Power Switch -------------------------------------------------- 8
MAINTENANCE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
Storage ------------------------------------------------------ 9
SERVICE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
United States - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
International - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
CE CERTIFICATION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
PRODUCT LIMITED WARRANTY - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10
3UM TGMIC-061919
OFFICIAL
EQUIPMENT
INTRODUCTION
TG Microphone
Thank you for purchasing the Chandler Limited ‘TG Micro-
phone,’ you now own a piece of EMI/Abbey Road Studios
ocial equipment.
Continuing in the rich tradition of innovation at EMI and dat-
ing back to the early 1930s with Alan Blumlein, the father
of Stereo, the company’s rst andcoil velocity ‘ribbon’ micro-
phones, and the “Blumlein pair” technique, Chandler Limited
and Abbey Road Studios introduce the second new EMI
badged microphone in over a half century, the TG Micro-
phone.
Designed by Chandler Limited Founder and Chief Designer,
Wade Goeke, the TG Microphone is a solid-state large dia-
phragm condenser microphone, featuring an on-board his-
toric EMI TG12410 mastering console Tape Equalizer, three
TG ampliers and a dedicated external power supply.
The microphone’s on-board tape equalizer and modiers, al-
lows the user to sculpt the sound at the source, rather than
down-stream or later in the production process. The all-in-
one approach reduces electronic circuitry in the signal path
and allows for high-grade audio transmission from the source.
The TG Microphone system includes: microphone, 4-pin mi-
crophone cable, power supply system, shock mount suspen-
sion system, pattern select screwdriver, and wooden micro-
phone box.
Your Chandler Limited TG Microphone has been carefully
crafted and built by hand at Chandler Limited’s factory in
Shell Rock IA, U.S.A., using through-hole components for,
the ultimate analog experience.
At Chandler Limited we are proud of our American made
products and we hope you like them!
Please feel free to call our shop anytime for help or ques-
tions.
Phone: (319) 885-4200.
History
Conceived from meetings in 1967 between Abbey Road
and EMI’s Central Research Laboratories teams, the EMI
TG12345 Mark I desk ushered in a sea of change in sound
and exibility at Abbey Road Studios.
Installed in Abbey Road’s Studio Two in November 1968 and
making its debut on an 8-track recording by the Shadows, the
new transistorized solid-sate desk marked a departure from
the earlier REDD valve consoles.
The EMI TG12345 desk helped shape the sound of the Bea-
tles’ nal album, “Abbey Road,” which was markedly richer
sounding to that of the band’s earlier work. The sonic quali-
ties of classics like “Here Comes the Sun,” “Come Together”
and “Something” would have been very dierent without the
EMI TG12345.
From TG12345 console technology and the need for master-
ing consoles to perform as tape to disk or cutting desks and
the further requirement of tape to tape transfers, would give
rise to the now legendary EMI TG12410 transfer consoles.
Still in use today at EMI/Abbey Road Studios, the EMI
TG12410 transfer consoles and their heralded sound, were
never available to the public.
