Seite 1/1
60
c
m
LED
Cod. 02034501 EAN 8422248082136
TF
TF 5260 WH_2 MOTORES
TELESCOPICHOODS
Code 02034501
EAN 8422248082136
Model TF-5260 WH
Type Telescopic
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Anual Energy consumption) (kWh/annum) 78,3
EEI class (Energy Eiciency Class) D
FDE (Fluid Dynamic Eiciency) 9
FDE class (Fluid Dynamic Eiciency Class) E
LE (Lighting Eiciency) (lux/W) 9,3
LE class (Lighting Eiciency Class) E
GFE (Grease Filtering Eiciency) 66,5
GFE Class (Grease Filtering Eiciency class) D
Air flow at minimum speed (m 3/h) 174,8
Air flow at maximum speed (m 3/h) 325,1
Air flow at intensive speed (TURBO) (m 3/h) -
Sound Power Level at minimum speed (dB) 54
Sound Power Level at maximum speed (dB) 68
Sound Power Level at intensive speed (TURBO) (dB) -
Po (Power Consumption in o mode) (W) 0
Ps (Power Consumption in standby) (W) 0
Integration directive EU 66/2014
ƒ (Time Increase Factor) 1,7
EEI (Energy Eiciency Index) 93,5
QBEP (Flow Rate at Best Eiciency Point) (m3/h) 198
PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa) 185
WBEP (Electric Power Input at Best Eiciency Point) (W) 113,3
WL (Nominal Power Consumption of Lighting system) (W) 11
EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux) 102
External Dimensions
Width (mm) 600
Depth (mm) 280
Total max height (mm) 175
Total min height (mm) 175
Outlet Diameter (mm) 120
Characteristics
Motor 2 x L1N
Extraction Levels 3
Motor Maximum Power Consumption 2 x 65
Maximum Pressure 301
Intensive Speed (TURBO) Pressure -
Control Type Slider
Automatic shut-down timer -
Electronic Filter Saturation Indicator -
Filter Type Metallic
Anti-grease Filter Number 2
Inner Shield -
Lighting
Light Type LED E-14
Adjustable Intensity Lighting -
Nº of Lamps 2
Installation
Minimum height distance to a electric worktop hob (mm) 550
Minimum height distance to a gas worktop hob (mm) 650
Instalation with Outlet tube to the exterior / Recirculating BOTH
Easy Instalation System √
Electric Connection
Total Rush Power (W) 141
Rated Voltage (V) 220-240
Network Frequency (Hz) 50
Electrical Insulation Class CLASS II
Plug EU 2 Pins
Accessories
Upper Decorative tube Extension -
White Decorative Tube -
Black Decorative Tube -
Island Tube Enhancer -
Check Valve 02849002
MAX PRO Metal Filter -
Metal Filter 02825270
DUAL Filter (metal + active charcoal) -
Active Charcoal Filter 02846762
Noiseless Flexible Duct -
❒
Sliding Control Panel
❒
3 extraction levels
❒
Extraction power (according to UNE/EN 61591): 325m
3
/h - 175m
3
/h (EU Model)
❒
Maximum air flow (free outlet): 350m
3
/h
❒
Sound power (Reg.(EU) nº65/2014): 54dB(A), maximum: 68dB(A)
❒
2 Motor. Maximum energy consumption 2 x 65W
❒
Max. pressure 325 (EU Model) / 205 Pa
❒
LED E-14 lighting
❒
Easy-to-install system
❒
Dishwasher-washable filters
❒
Finished in white glass or stainless steel front panel
❒
120mm outlet diameter
❒
Energy Class: D
▶ Accesorios (no incluidos)
Filtro de Carbón Activo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cod. 02846762 / EAN 8422248001816 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Válvula antirretorno . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cod. 02849002 / EAN 8422248044394 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
50
cm
