Seite 1/1

900/800/700

371 240

290

370

730

340

Mín. 755 / Máx. 1070

LED

Cod. 02145203 EAN 8422248106177

GRECO 80 GR

DECORATIVESHOODS

Code 02145203

EAN 8422248106177

Model GRECO 80 GR CATA&ROCA

Type Vertical

Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564

AEC (Anual Energy consumption) (kWh/annum) 56,3

EEI class (Energy Eiciency Class) A

FDE (Fluid Dynamic Eiciency) 30,6

FDE class (Fluid Dynamic Eiciency Class) A

LE (Lighting Eiciency) (lux/W) 28,7

LE class (Lighting Eiciency Class) A

GFE (Grease Filtering Eiciency) 91,2

GFE Class (Grease Filtering Eiciency class) B

Air flow at minimum speed (m3/h) 340

Air flow at maximum speed (m3/h) 600

Air flow at intensive speed (TURBO) (m3/h) 850

Sound Power Level at minimum speed (dB) 50

Sound Power Level at maximum speed (dB) 65

Sound Power Level at intensive speed (TURBO) (dB) 67

Po (Power Consumption in o mode) (W) 0,43

Ps (Power Consumption in standby) (W) 0

Integration directive EU 66/2014

ƒ (Time Increase Factor) 0,9

EEI (Energy Eiciency Index) 53,7

QBEP (Flow Rate at Best Eiciency Point) (m3/h)

416,9

PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa) 411

WBEP (Electric Power Input at Best Eiciency Point) (W) 155,7

WL (Nominal Power Consumption of Lighting system) (W) 7

EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux) 201

External Dimensions

Width (mm) 800

Depth (mm) 290

Total max height(mm 1070

Total min height(mm 755

Outlet Diameter (mm) 150/125

Characteristics

Motor BT3

Extraction Levels 3+1

Motor Maximum Power Consumption 280

Maximum Pressure 450

Intensive Speed (TURBO) Pressure 470

Control Type TC4i

Automatic shut-down timer √

Electronic Filter Saturation Indicator √

Filter Type Metallic

Anti-grease Filter Number 1+1

Inner Shield -

Lighting

Light Type EcoLed

Adjustable Intensity Lighting √

Nº of Lamps 2

Installation

Minimum height distance to a electric worktop hob (mm) 530

Minimum height distance to a gas worktop hob (mm) 650

Instalation with Outlet tube to the exterior / Recirculating BOTH

Easy Instalation System √

Electric Connection

Total Rush Power (W) 287

Rated Voltage (V) 220-240

Network Frequency (Hz) 50

Electrical Insulation Class CLASS II

Plug EU - 2 pins

Accessories

Upper Decorative tube Extension 02861303

White Decorative Tube -

Black Decorative Tube 02861403

Island Tube Enhancer -

Check Valve 02832004

MAX PRO Metal Filter -

Metal Filter 02800930+02800904

DUAL Filter (metal + active charcoal) 02800922+02800938

Active Charcoal Filter 02859398

Noiseless Flexible Duct 02893002

850 m3/h850 m3/h850 m3/h

High Eiciency Motor

2013 2015&

❒

Touch Control Panel with authomatic shut-down timer and cleaning filters indicator

❒

4 extraction levels, 3 + 1 TURBO

❒

Extraction power (according to UNE/EN 61591): 850m

/h - 340m

❒

Sound power (Reg.(EU) nº65/2014): 50dB(A), maximum: 65dB(A)

❒

BT3 motor. Ultra silent. Maximum energy consumption 280W

❒

High eiciency Led lighting, adjustable intensity

❒

Easy-to-install system

❒

Non-condensation filter XL

❒

Dishwasher-washable filters

❒

Metallic gray glass finishing

❒

Max. Pressure: 470 Pa

❒

Front panel with opening for intensive use

❒

150/125 mm outlet diameter

❒

Energy Class: A

▶ Accessories

(not included)

Active charcoal filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02859398 / EAN 8422248075497 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Check valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02832004 / EAN 8422248480499 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Top tub BK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02861403 / EAN 8422248078818 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Top tub WH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02861003 / EAN 8422248097765 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Top tub INOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02861303 / EAN 8422248097758 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
