Seite 1/1
600
ø120
85
450
340
60
c
m
LED
Cod. 02011317 EAN 8422248105231
LF-2060 X
CONVENTIONAL
Code 02011317
EAN 8422248105231
Model LF-2060 X
Type Standard
"Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564"
AEC (Anual Energy consumption) (kWh/annum) 45,1
EEI class (Energy Eiciency Class) C
FDE (Fluid Dynamic Eiciency) 9,4
FDE class (Fluid Dynamic Eiciency Class) E
LE (Lighting Eiciency) (lux/W) 14,5
LE class (Lighting Eiciency Class) D
GFE (Grease Filtering Eiciency) 79,6
GFE Class (Grease Filtering Eiciency class) C
Air flow at minimum speed (m3/h) 107,5
Air flow at maximum speed (m3/h) 195,6
Air flow at intensive speed (TURBO) (m3/h) -
Sound Power Level at minimum speed (dB) 56
Sound Power Level at maximum speed (dB) 69
Sound Power Level at intensive speed (TURBO) (dB) -
Po (Power Consumption in o mode) (W) 0
Ps (Power Consumption in standby) (W) 0
Integration directive EU 66/2014
ƒ (Time Increase Factor) 1,7
EEI (Energy Eiciency Index) 82,4
QBEP (Flow Rate at Best Eiciency Point) (m3/h) 116,2
PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa) 192
WBEP (Electric Power Input at Best Eiciency Point) (W) 66,2
WL (Nominal Power Consumption of Lighting system) (W) 5,5
EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux) 80
External Dimensions
Width (mm) 600
Depth (mm) 452
Total max height(mm 85
Total min height(mm 85
Outlet Diameter (mm) 120
Characteristics
Motor L1N
Extraction Levels 3
Motor Maximum Power Consumption 65
Maximum Pressure 325
Intensive Speed (TURBO) Pressure -
Control Type Mechanic
Automatic shut-down timer -
Electronic Filter Saturation Indicator -
Filter Type Metallic
Anti-grease Filter Number 2
Inner Shield -
Lighting
Light Type LED E-14
Adjustable Intensity Lighting -
Nº of Lamps 1
Installation
Minimum height distance to a electric worktop hob (mm) 550
Minimum height distance to a gas worktop hob (mm) 650
Instalation with Outlet tube to the exterior / Recirculating BOTH
Easy Instalation System
Electric Connection
Total Rush Power (W) 65,5
Rated Voltage (V) 220-240
Network Frequency (Hz) 50
Electrical Insulation Class CLASS I
Plug -
Accessories
Upper Decorative tube Extension -
White Decorative Tube -
Black Decorative Tube -
Island Tube Enhancer -
Check Valve 02849002
MAX PRO Metal Filter -
Metal Filter 02833170
DUAL Filter (metal + active charcoal) -
Active Charcoal Filter 02846764
Noiseless Flexible Duct -
Mechanical control panel
3 extraction levels
Extraction power (according to UNE/EN 61591): 195m3/h - 107m3/h
Motor maximum airflow free outlet: 350m3/h
Sound power (Reg.(EU) nº65/2014): 56dB(A), maximum: 68dB(A)
Tangential motor. Extra silent. Maximum energy consumption 65W
E-14 LED lighting
Easy-to-install system
Dishwasher-washable filters
Finished in stainless steel
Max. pressure 325 Pa
120mm outlet diameter
Energy Class: C
Accesorios (not included)
Active charcoal filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02846764 / EAN 8422248078276 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
