Seite 1/1
100
c
m
LED
-+
960
70
12
1000 600
290 290
580
Mín. 285 / Máx. 500
Cod. 02111001 EAN 8422248077750
DECORATIVEISLANDS
Code 02111001
EAN 8422248077750
Model ISLA SIRIN 1000 WH
Type Island
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Anual Energy consumption) (kWh/annum) 58,9
EEI class (Energy Eiciency Class) A
FDE (Fluid Dynamic Eiciency) 31,5
FDE class (Fluid Dynamic Eiciency Class) A
LE (Lighting Eiciency) (lux/W) 36,6
LE class (Lighting Eiciency Class) A
GFE (Grease Filtering Eiciency) 91,2
GFE Class (Grease Filtering Eiciency class) B
Air flow at minimum speed (m 3/h) 340
Air flow at maximum speed (m 3/h) 600
Air flow at intensive speed (TURBO) (m 3/h) 850
Sound Power Level at minimum speed (dB) 50
Sound Power Level at maximum speed (dB) 65
Sound Power Level at intensive speed (TURBO) (dB) 67
Po (Power Consumption in o mode) (W) 0,3
Ps (Power Consumption in standby) (W) 0
Integration directive EU 66/2014
ƒ (Time Increase Factor) 0,9
EEI (Energy Eiciency Index) 54,6
QBEP (Flow Rate at Best Eiciency Point) (m3/h)
350,4
PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa) 380
WBEP (Electric Power Input at Best Eiciency Point) (W) 132,8
WL (Nominal Power Consumption of Lighting system) (W) 14
EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux) 513
External Dimensions
Width (mm) 1000
Depth (mm) 600
Total max height (mm) 500
Total min height (mm) 285
Outlet Diameter (mm) 150
Characteristics
Motor BT3
Extraction Levels 3+1
Motor Maximum Power Consumption 280
Maximum Pressure 450
Intensive Speed (TURBO) Pressure 470
Control Type TC4i
Automatic shut-down timer √
Electronic Filter Saturation Indicator √
Filter Type Metallic
Anti-grease Filter Number 3
Inner Shield -
Lighting
Light Type EcoLed
Adjustable Intensity Lighting √
Nº of Lamps 4
Installation
Minimum height distance to a electric worktop hob (mm) 550
Minimum height distance to a gas worktop hob (mm) 660
Instalation with Outlet tube to the exterior / Recirculating BOTH
Easy Instalation System √
Electric Connection
Total Rush Power (W) 294
Rated Voltage (V) 220-240
Network Frequency (Hz) 50
Electrical Insulation Class CLASS II
Plug EU - 2 pins
Accessories
Upper Decorative tube Extension -
White Decorative Tube -
Black Decorative Tube -
Island Tube Enhancer -
Check Valve 02832006
MAX PRO Metal Filter 02800917
Metal Filter 02800200*
DUAL Filter (metal + active charcoal) 02800918
Active Charcoal Filter 02859398
Noiseless Flexible Duct 02893002
❒
Touch control panel with authomatic shut-down timer and cleaning filters
indicator + remote control
❒
4 extraction levels, 3 + 1 TURBO
❒
Extraction power (according to UNE/EN 61591): 850m
3
/h - 340m
3
/h
❒
Maximum air flow (free outlet): 1200m
3
/h
❒
Sound power (Reg.(EU) nº65/2014): 50dB(A), maximum: 65dB(A)
❒
BT3 motor. Extra silent. Maximum energy consumption 280W
❒
High eiciency LED lighting, adjustable intensity
❒
Easy-to-install system
❒
Dishwasher-washable filters
❒
White finishing
❒
Max. Pressure: 470 Pa
❒
150 mm outlet diameter
❒
Ceiling installation
▶ Accessories
(not included)
Active Charcoal Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cod. 02859398 / EAN 8422248075497 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adaptator+Check Valve 150mm . . . . . . . . . . . . . . . . . . . . . . . . .
Cod. 02832006 / EAN 8422248079167 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
850 m3/h
High Eiciency Motor
SIRIN 1000 WH ISLAND
SIRIN WH ISLAND
Rotary Motor Covers all
exit directions
Le moteur rotatif couvre
toutes les directions de
sortie
