Cod. 02186207 EAN 8422248105774
CORONA X 120
120
c
m
90
c
m70
cm
60
c
m
t i r a
l e d
1195/895/695/595
1161/861/661/561
1100/800/600/500
260
263 339
75
307
157
46
310
203
mín. 203
máx. 324
mín. 310
máx. 350
INTEGRATIONHOODS
Electronic Control Panel with digital display authomatic shut-down timer
3 extraction levels, 2 + 1 TURBO
Extraction power (according to UNE/EN 61591): 850m
3
/h - 340m
3
/h
Sound power (Reg.(EU) nº65/2014): 50dB(A), maximum: 65dB(A)
BT3 motor. Ultra silent. Maximum energy consumption 283,5W
High eiciency strip led lighting
Easy-to-install system
Fully stainless steel washable dishwasher filters
Glass Visor
Stainless steel finishing
Max. Pressure: 470 Pa
150/125 mm outlet diameter
Energy Class: A
Accessories
(not included)
Active charcoal filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cod. 02859398 / EAN 8422248075497 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02832004 / EAN 8422248480499 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
850 m3/h
High Eiciency Motor
Code 02186207
EAN 8422248105774
Model CORONA X 120
Type Integrated
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Anual Energy consumption) (kWh/annum) 56,3
EEI class (Energy Eiciency Class) A
FDE (Fluid Dynamic Eiciency) 30,6
FDE class (Fluid Dynamic Eiciency Class) A
LE (Lighting Eiciency) (lux/W) 55,7
LE class (Lighting Eiciency Class) A
GFE (Grease Filtering Eiciency) 84,27
GFE Class (Grease Filtering Eiciency class) C
Air flow at minimum speed (m3/h) 340
Air flow at maximum speed (m3/h) 600
Air flow at intensive speed (TURBO) (m3/h) 850
Sound Power Level at minimum speed (dB) 50
Sound Power Level at maximum speed (dB) 65
Sound Power Level at intensive speed (TURBO) (dB) 67
Po (Power Consumption in o mode) (W) 0,45
Ps (Power Consumption in standby) (W) 0
Integration directive EU 66/2014
ƒ (Time Increase Factor) 0,9
EEI (Energy Eiciency Index) 52,1
QBEP (Flow Rate at Best Eiciency Point) (m3/h)
416,9
PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa) 411
WBEP (Electric Power Input at Best Eiciency Point) (W) 155,7
WL (Nominal Power Consumption of Lighting system) (W) 3,5
EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux) 195
External Dimensions
Width (mm) 1195
Depth (mm) 310-350
Total max height(mm 339
Total min height(mm 339
Outlet Diameter (mm) 150/125
Characteristics
Motor BT3
Extraction Levels 2 + 1
Motor Maximum Power Consumption 283
Maximum Pressure 450
Intensive Speed (TURBO) Pressure 470
Control Type VL3i
Automatic shut-down timer
Electronic Filter Saturation Indicator -
Filter Type Metallic
Anti-grease Filter Number 2
Inner Shield -
Lighting
Light Type Eco Led Strip
Adjustable Intensity Lighting -
Nº of Lamps 2
Installation
Minimum height distance to a electric worktop hob (mm) 550
Minimum height distance to a gas worktop hob (mm) 650
Instalation with Outlet tube to the exterior / Recirculating BOTH
Easy Instalation System
Electric Connection
Total Rush Power (W) 283,5
Rated Voltage (V) 220-240
Network Frequency (Hz) 50
Electrical Insulation Class CLASS II
Plug EU - 2 pins
Accessories
Upper Decorative tube Extension -
White Decorative Tube -
Black Decorative Tube -
Island Tube Enhancer -
Check Valve 02832004
MAX PRO Metal Filter -
Metal Filter 02800205
DUAL Filter (metal + active charcoal) -
Active Charcoal Filter 02859398
Noiseless Flexible Duct 02893002
