Owner’s Manual
A NOTE ABOUT SAFETY
Any time you see this symbol in manuals, instructions and on the
unit, be aware of the potential for personal injury. There are three levels
of precaution:
WARNING signifies hazards that could result in personal injury or
death.
CAUTION is used to identify unsafe practices which would result in
minor personal injury or product and property damage.
NOTE is used to highlight suggestions which will result in enhanced
installation, reliability, or operation.
ABOUT YOUR HEAT PUMP SYSTEM
Our products are designed, tested and built in accordance with US
Department of Energy standardized procedures and other standards;
however, actual operating results and efficiencies may vary based on
manufacturing and supplier tolerances, equipment configuration,
operating conditions and installation practices.
IDENTIFYING YOUR SYSTEM
Your new Carrier heat pump system is what we call a ”split system.” It
has an outdoor unit and an indoor unit connected to each other with
copper tubing called refrigerant lines. Each of these units has a rating
plate with the model and serial numbers you will need to reference when
calling an authorized Carrier dealer about your system.
Take a few moments now to locate those numbers and record them for
future reference.
USING YOUR NEW CARRIER SYSTEM
Your Carrier heat pump system is controlled by a wall-mounted Infinity
Control installed inside your home. This system requires an Infinity
Control which has software designed specifically to operate this system.
See the Infinity Control Homeowner Guide for more details on system
operation.
VARIABLE SPEED OPERATION
You may notice your system runs for longer periods of time. This
system is designed to meet cooling or heating needs of the home at a
wide range of conditions. Your indoor temperature will remain more
consistent with fewer drafts, better humidity control, enhanced comfort
and enhanced energy efficiency.
HEATING AND COOLING YOUR HOME
For heating or cooling operation, make sure the System or Mode control
is set to the appropriate mode. Then, adjust the Temperature control to
your desired setting. Finally, use the Fan control to select Automatic
(turns on and off as heating is needed) or On (runs continuously).
Depending on your typical heating needs, your home comfort system
may also include a supplementary heating source that will automatically
turn on as needed. You may also select this heat source manually if
desired.
OPERATION UNDER EXTREME CONDITIONS
Your heat pump will run as long as necessary to maintain the indoor
temperature selected on your Infinity Control. On extremely hot days,
your heat pump will run for longer periods at a time than on moderate
days. Your system will also run for longer periods of time under the
following conditions:
• Frequent opening of exterior doors
• Operating laundry appliances
• Taking hot showers
• More than the usual number of people present in the home
• More than the normal number of electric lights in use
• Drapes or blinds are open on the sunny side of the home
IMPORTANT HEAT PUMP FACTS
Heat pump systems have a few unique features and operations that you
should be aware of:
• During the heating cycle, your heat pump delivers a constant flow of
air at around 95°F (35°C)to about 105°F (41°C), compared to sudden
blasts of hot air provided by a typical furnace.
• Ice or frost may form on the outdoor coil during winter heating
operation. Your heat pump will automatically melt the ice using its
defrost cycle. During defrost, you may see steam or fog rising from
the outdoor unit, which is normal. At the beginning and end of the
defrost cycle, you may hear a ”whoosh” sound coming from the unit.
This is normal for heat pump applications.
• Heat pumps installed in areas expecting snow are elevated with
support feet.
SOUND
Your new heat pump with Greenspeed Intelligence is different from most
heating and cooling systems. Because this is a variable speed system, it
is designed to operate at different speeds depending on the temperature
and humidity conditions. You may notice the sound coming from the
outdoor unit changing from time to time, and from season to season. In
winter, the system will operate at higher speeds as it gets colder outside
to maintain its heating performance. The higher speed produces a higher
sound. This change of speeds allows the system to operate more
efficiently and maintain comfortable conditions inside the home. You
may also hear a slight “purr” at start-up and shut down. These sounds
are normal and do not represent a problem with your system.
ROUTINE MAINTENANCE
Simple, routine maintenance as described below will enhance your heat
pump system’s ability to operate economically and dependably. Always
remember the following safety precautions:
25VNA
Infinity™Variable Speed Heat Pump
with Greenspeed™ Intelligence
2-5 Nominal Tons
WARNING
!
PERSONAL INJURY, DEATH AND / OR PROPERTY
DAMAGE HAZARD
Failure to follow this warning could result in personal injury, death or
property damage.
Improper installation, adjustment, alteration, service, maintenance, or
use can cause explosion, fire, electrical shock, or other conditions
which may cause personal injury or property damage. Consult a
qualified installer, service agency, or your distributor or branch for
information or assistance. The qualified installer or service agency
must use factory-authorized kits or accessories when modifying this
product.
Read and follow all instructions and warnings, including labels shipped
with or attached to unit before operating your new heat pump.
©2019 Carrier Corp.• 7310 W. Morris Street • Indianapolis, IN 46231 Edition Date: 09/19 Catalog No: OM25VNA-02
Replaces: OM25VNA-01
25VNA: Owner’s Manual
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
2
• Keep Filter Clean
A clogged or improperly installed air filter on your indoor unit will
increase operating costs and shorten the life of the unit. For detailed
filter cleaning information refer to indoor unit literature.
• Do Not Block Floor, Wall or Ceiling Vents
When drapes, furniture, toys or other common household items block
vents, the restricted airflow lessens the system’s efficiency and life span.
• Do Not Cover or Block Outdoor Unit
The outdoor unit needs unrestricted airflow. Do not cover it or place
items on or next to it. Do not allow grass clippings, leaves, or other
debris to accumulate on the sides or top of the unit. And, maintain a 12”
(305 mm) minimum clearance between the outdoor unit and tall grass,
vines, shrubs, etc.
• Check Condensate Drain
Your heat pump removes humidity from your home during the cooling
season. After a few minutes of operation, water should trickle from the
condensate drain of the indoor coil. Check this occasionally to be sure
the drain system is not clogged. Drainage will be limited if you live in a
very dry environment.
• Do Not Operate Below 55°F/13°C in Cooling Mode
Your outdoor unit is not designed to operate when outdoor temperatures
are lower than 55°F/13°C without modification. If operation below this
temperature is required, consult your Carrier dealer.
• Do Not Operate Above 66°F/19°C in Heating Mode
Your outdoor unit is not designed to operate on heating mode when
outdoor temperatures are higher than 66°F/19°C. You can safely operate
the system above 66°F/19°C on emergency or auxiliary heat.
• Base Pan Drainage
Periodically check for and remove debris that has settled around the base
of your outdoor unit. This will ensure proper drainage of the base pan
and eliminate standing water inside the outdoor unit.
• Level Installation
Your Carrier dealer will install the outdoor unit in a level position. If the
support base settles or shifts and the unit is no longer level, be sure to
re-level it promptly to assure proper drainage. If you notice water or ice
collecting beneath the unit, arrange for it to be drained away from the
unit.
SEA COAST COIL MAINTENANCE
Coastal locations often require additional maintenance of the outdoor
unit due to highly corrosive airborne ocean salt. Although your new
Carrier system is made of galvanized metal and is protected by top-grade
paint, take the additional precaution of periodically washing all exposed
surfaces and the outdoor coil approximately every 3 months. Consult
your installing Carrier dealer for proper cleaning intervals and
procedures for your geographic area or ask about a service contract for
regularly scheduled professional cleaning and inspections.
TROUBLESHOOTING
Before you request dealer service, check for these easily solved
problems:
• Check the indoor and outdoor disconnect switches Also check your
main electrical panel circuit breakers or fuses.
• Check for sufficient airflow. Air filter(s) should be reasonably clean
and interior vents should be open and unobstructed.
• Check Infinity Control settings. For cooling, your desired
temperature setting should be lower than the displayed room
temperature, and the System/Mode control should be set to Cool or
Auto. For heating, your temperature setting should be higher than the
displayed room temperature, and the System/Mode control set to Heat
or Auto.
• Time delays - depending on the Carrier heat pump you have, there
may be delays in unit operation that are built-in to protect the
equipment and your comfort. Don’t be alarmed if you notice a time
delay in operation. It may be a standard protection feature of your
equipment. Check with your Carrier Dealer for more information on
time delays.
If you need to contact your Carrier dealer for troubleshooting and/or
repairs, be sure to have the model and serial numbers of your equipment
available.
REGULAR DEALER MAINTENANCE
In addition to the routine maintenance that you perform, your home
comfort system should be inspected regularly by a properly trained
service technician. Many dealers offer this service at a reduced rate with
a service contract. Some service contracts offer additional benefits such
as parts discounts and no additional charge for ”after hours” or
emergency service.
WARNING
!
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal injury or death.
Disconnect all electrical power to the indoor air handler or furnace
before removing access panels to perform any maintenance.
Disconnect power to both the indoor and outdoor units. Lock out and
tag switch with suitable warning label.
NOTE: There may be more than one electrical disconnect switch.
CAUTION
!
CUT HAZARD
Failure to follow this caution may result in personal injury.
Although special care has been taken to minimize sharp edges in the
construction of your unit, be extremely careful and wear appropriate
protective clothing and gloves when handling parts or reaching into the
unit.
25VNA: Owner’s Manual
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
3
* Monthly maintenance items and outdoor unit rinsing may be performed by the consumer. All other maintenance items and all service work must be performed by a qualified service technician. Read all waring labels.
Notes:
1. The above list may not include all maintenance items. Inspection intervals may vary depending on climate and operating hours. Consult your Carrier dealer about a service contract for seasonal inspections.
2. Do not use harsh chemicals or high pressure water on coils. More frequent rinsing is required for units near a sea coast.
Maintenance Checklist Recommended
Interval*
Outdoor unit specific: Monthly Annual
Clear away debris and vegetation near unit. X
Inspect cabinet for damage. Replace components that are damaged or severely rusted. X
Inspect electrical disconnect for proper function. Repair or replace as necessary. X
Inspect electrical wiring and connections. Tighten loose connections. Inspect and perform functional test of equipment as needed to ensure
proper function. Repair or replace damaged or overheated components and wiring. X
Check refrigerant system subcooling and/or superheat (system dependent). X
Inspect inside of unit. Clean if debris is present. X
Inspect condenser coil. Clean if dust, dirt, or debris is present. Rinse unit with fresh water (see Note 2). X
Inspect motor and fan for damage. Make sure fan spins freely. X
Indoor specific: (for fossil fuel furnaces and accessories, refer to unit specific literature)
Inspect, clean, or replace air filter if dirty. X
Inspect and clean blower assembly (includes blower housing, wheel, and motor). X
Inspect internal and external of cabinet. Clean as needed. X
Inspect electrical disconnect for proper function. Repair or replace as necessary. X
Inspect electrical components, wiring, and connections. Tighten loose connections. Repair or replace damaged components and wiring. X
Inspect evaporator coil. Clean if dust, dirt, or debris is present (see Note 2). X
Clean condensate pan, trap, and drain lines (more frequent maintenance may be required in humid climates - consult your local HVAC dealer). X
Inspect airflow system (ductwork). Check for leaks and repair as needed. X
Produktspezifikationen
| Marke: | Carrier |
| Kategorie: | Wärmepumpe |
| Modell: | Infinity 25VNA0 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Carrier Infinity 25VNA0 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Wärmepumpe Carrier
29 August 2024
29 August 2024
29 August 2024
29 August 2024
29 August 2024
29 August 2024
15 Januar 2024
Bedienungsanleitung Wärmepumpe
- Wärmepumpe Samsung
- Wärmepumpe LG
- Wärmepumpe Bosch
- Wärmepumpe AEG
- Wärmepumpe Siemens
- Wärmepumpe ATAG
- Wärmepumpe Electrolux
- Wärmepumpe Miele
- Wärmepumpe Blaupunkt
- Wärmepumpe Grundig
- Wärmepumpe Hotpoint
- Wärmepumpe Inventum
- Wärmepumpe Wilfa
- Wärmepumpe Atlantic
- Wärmepumpe Balay
- Wärmepumpe Mitsubishi
- Wärmepumpe Hisense
- Wärmepumpe Arçelik
- Wärmepumpe Vaillant
- Wärmepumpe Qlima
- Wärmepumpe Junkers
- Wärmepumpe De Dietrich
- Wärmepumpe Remeha
- Wärmepumpe Stiebel Eltron
- Wärmepumpe Viessmann
- Wärmepumpe Orima
- Wärmepumpe Dimplex
- Wärmepumpe Fujitsu
- Wärmepumpe Westinghouse
- Wärmepumpe Baxi
- Wärmepumpe Tesy
- Wärmepumpe Vivax
- Wärmepumpe Itho Daalderop
- Wärmepumpe Gree
- Wärmepumpe Olimpia Splendid
- Wärmepumpe Danfoss
- Wärmepumpe Ferroli
- Wärmepumpe Nibe
- Wärmepumpe Daikin
- Wärmepumpe Fisher & Paykel
- Wärmepumpe Elco
- Wärmepumpe Fairland
- Wärmepumpe Flojet
- Wärmepumpe Harmopool
- Wärmepumpe Hydro-Pro
- Wärmepumpe Maxicool
- Wärmepumpe Nefit
- Wärmepumpe Techneco
- Wärmepumpe Thermor
- Wärmepumpe Wita
- Wärmepumpe Zodiac
- Wärmepumpe AstralPool
- Wärmepumpe JANDY
- Wärmepumpe Armstrong
- Wärmepumpe MRCOOL
- Wärmepumpe Wilo
- Wärmepumpe Grundfos
- Wärmepumpe Kospel
- Wärmepumpe Waterco
- Wärmepumpe Alpha Innotec
- Wärmepumpe AWB
- Wärmepumpe Azuro
- Wärmepumpe Calorex
Neueste Bedienungsanleitung für -Kategorien-
1 Oktober 2024
30 September 2024
21 September 2024
19 September 2024
16 September 2024
13 September 2024
7 September 2024
7 September 2024
7 September 2024
6 September 2024
