Seite 1/19

TS-E24mm f/3.5L

TS-E45mm f/2.8

TS-E90mm f/2.8

Instructions

COPY

ENG-1

Canon’s TS-E lenses are tilt-shift lenses

designed for EOS cameras. The tilt-shift

mechanism enables photographers to control

the depth of field and the area photographed

and to correct image distortion, making it

possible to take sophisticated pictures that

cannot be shot using a conventional lens.

● To ensure that you make the most of the TS-E lens

functionality, it is recommended that you use it with

an EOS camera with 100% viewfinder visibility

(EOS-1, EOS-1D or EOS-1Ds series) and use the

laser matte with grid focusing screen Ec-D and a

tripod.

● On EOS cameras with a built-in flash, some partial

restrictions may apply to the shift and rotation

functions.

● On EOS cameras equipped with a grip for vertical

shooting, some partial restrictions may apply to the

shift and rotation functions.

Features

1. The lens can be tilted up to ±8° and shifted up

to ±11mm.

2. The tilt and shift functions can be used singly

or in combination.

3. The lens can be rotated to change the tilt or

shift direction.

Conventions used in this instruction

Warning to prevent lens or camera malfunction

or damage.

Supplementary notes on using the lens and

taking pictures.

Thank you for purchasing a Canon product.

COPY

ENG-2

aSafety Precautions

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

Do not make any changes or modifications to the equipment

unless otherwise specified in the instructions. If such changes or

modifications should be made, you could be required to stop

operation of the equipment.

This equipment has been tested and found to comply with the

limits for a class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of

the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Consult the dealer or an experienced radio/TV technician for

help.

This Class B digital apparatus complies with Canadian ICES-003.

aSafety Precautions

●

Do not look at the sun or a bright light source

through the lens or camera. Doing so could result in

loss of vision. Looking at the sun directly through the

lens is especially hazardous.

●

Whether it is attached to the camera or not, do not

leave the lens under the sun without the lens cap

attached. This is to prevent the lens from concentrating

the sun’s rays, which could cause a fire.

Handling Cautions

● If the lens is taken from a cold environment into a

warm one, condensation may develop on the lens

surface and internal parts. To prevent condensation

in this case, first put the lens into an airtight plastic bag

before taking it from a cold to warm environment. Then

take out the lens after it has warmed gradually. Do the

same when taking the lens from a warm environment

into a cold one.

● Do not leave the lens in excessive heat such as in a

car in direct sunlight. High temperatures can cause

the lens to malfunction.

COPY

Produktspezifikationen

Marke:	Canon
Kategorie:	Objektiv
Modell:	TS-E 24mm f/3.5L II
Gewicht:	780 g
Produktfarbe:	Schwarz
Vergrößerung:	0.34 x
Naheinstellgrenze:	0.21 m
Länge (mm):	106.9 mm
Durchmesser:	88.5 mm
Maximale Blendenzahl:	22
Feste Brennweite:	24 mm
Betrachtungswinkel des Objektivs, diagonal:	84 °
Objektivaufbau (Elemente/Gruppen):	16/11
Anzahl Blendenlamellen:	8
Filtergröße:	82 mm
