Seite 1/12
I
IN
NS
ST
TA
AL
LL
LA
AT
TI
IO
ON
NI
IN
NS
ST
TR
RU
UC
CT
TI
IO
ON
NS
S
NOTE: FOR OPTIMUM QUIETNESS, FULLY ASSEMBLE FAN AND RUN 24 HOURS
!
“INSTRUCTIONS PERTAINING TO RISK OF FIRE OR INJURY TO PERSONS”
INSTALLATION AND WIRING TO BE IN ACCORDANCE WITH CEC,
NEC, LOCAL ELECTRICAL CODES and ANSI/NFPA 70.
Consult a qualified electrician if you are not familiar with wiring.
“READ ALL INSTRUCTIONS”
“IMPORTANT SAFETY
INSTRUCTIONS”
“SAVE THESE INSTRUCTIONS”
TOOLS AND MATERIALS REQUIRED
- Philips Screw Driver
- Blade Screw Driver
- Step Ladder
- Wire Cutters
- Wiring supplies as required by electrical code.
DOWNROD MOUNT SERIES
“ for purchasing our product. It is our policy to furnish you with high quality Thank you”
products at a fair price. With proper installation your fan should provide you with years of
money saving comfort.
This fan is guaranteed to be free from defects in workmanship and Material for a period
of five (5) years from date of purchase. Within the first (1) year from date of purchase any
defective product should be returned to your along with proof of purchase. RETAIL OUTLET
For the balance of the warranty, four (4) years, the MOTOR WINDINGS ONLY shall be free
of defects. We will correct such defects or replace the motor assembly at our option if the
product is returned, , to us. The returned fan must be accompanied by FREIGHT PREPAID
your proof of purchase and a cheque for $20.00 for handling and labour charges. All costs of
removing and re-installing the product are YOUR RESPONSIBILITY damage to any part as
such by accident, misuse, improper installation or by affixing any accessories IS NOT covered
by this warranty. As a result of varying climatic conditions in our area this warranty does not
cover any changes in finishes, including rusting, pitting, corroding, tarnishing or peeling.
WARRANTY VOID: In cases of alteration, abuse, installation not in accordance with
5 YEAR LIMITED WARRANTY
11/16
.rekcitS AS C eht fo LAVOMER ro snoitcurtsni
CF-17A
LED
07/21
2555 Rue Bernard
Lefebvre Laval, Quebec
H7C 0A5
PH: (450) 665-2535
FX: (450) 665-0910
2157 Parkedale Ave.,
Brockville, Ontario
K6V 5V6
PH: (613) 342-5424
FX: (613) 342-8437
Pg. #2
Pg. #11
- To r
-
- Mount
floor or
-DO
be
chain
WARNING
educe the risk of fire or electrical shock, ONLY use model CQ006
remote control for optional remote control adaptability.
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL
INJURY, MOUNT TO OUTLET BOX MARKED ACCEPTABLE FOR FAN SUPPORT
AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX.
with the lowest moving parts at least Meters (7 Feet) above 2.10
grade level.
NOT operate reversing switch while fan blades are in motion. Fan must
turned
off
and
rotating
blades
stopped,
reverse
chain
pulled,
the
speed
pulled
again
to
start
in
the
opposite
direction.
INSTRUCTIONS
way of
pull
chains. On a fan/light combination, three pull chains will exist: One for light,
on and
off. The second is for fan speeds. This will be marked (SPEED) on the fan
switch
housing.
1st
Pull
will
give
fan
High
Speed
2nd
Pull
will
give
fan
Medium
Speed
3rd
Pull
will
give
fan
Low
Speed
4th
Pull
will
Shut
Fan
Off
The
third
pull
chain
is
for
Forward/Reverse#( Note:
Some
models
come
with
a
slide
switch
instead
of
a
pull
chain).
This
setting
would
usually
be
changed
twice
per
year. Downdraft
in
summer
to
create
a
wind
chill
to
give
a
cooling
effect.
in
winter
to
circulate
the
hot
stratified
air
off
the
and
back
down
to
the floor
without
creating
a
wind
chill.
A ceilling fan has a completeky internal switchung system for total operation by
Updraft
ceilling
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee
of this device could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This device contains licence-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference
that may cause undesired operation of the device.
Supplier's Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Unique Identifier: CANARMNA
Responsible Party
CanarmInc.
709 East Main Street, Teutopolis, Illinois, USA 62467
1.800.267.4427
SAFETY PRECAUTIONS
1. Turn off power at main electrical service box before starting installation
2. Electrical connections must comply with local code ordinances, national electrical
codes, CEC, NEC and ANSI/NFPA 70.
3. Make sure the installation site you choose allows the fan blades to rotate freely
without any obstructions.
4. When mounting the fan on a ceiling outlet box, Use an approved (CSA for Canada and
UL for U.S.) ceiling fan box marked " ". Ensure the outlet box is FOR FAN SUPPORT
securely installed in place such that it is able to support at least the fan weight.
5. WARNING: To reduce the risk of fire, electric shock, or other personal injury, mount
fan only on an outlet box or supporting system marked acceptable for fan support of
35 lbs (15,9 kg) or less and use the mounting screws provided with the outlet box.
Most outlet boxes commonly used for the support of lighting fixtures are not
acceptable for fan support and may need to be replaced. Consult a qualified
electrician if in doubt.
6. Total Fan Weight For Reference: 42"approximate 7.5 kgs(16.53lbs).
Pg. #3
1. Wooden Joist
2. proved (CSA for Canada Ap
and UL for U.S.) ceiling fan box
(not provided)
3. Ceiling
4. J-Hook
5. Rubber Gasket
6. Screws & Lock Washers
(set of 4)
7. Mounting Bracket c/w Ground
Wire
8. Outlet Box Screws (not provided)
9. Lock Pin
10. Hemisphere Jam Screw
11. Hemisphere
12. Downrod c/w Ground Wire
13. Ceiling Canopy
14. Bolt
15. Motor Assembly
16. Jam Screws
17. Cotter Pin
18. Flat Washer
19.
1.
2.
3.
4.
5.
6.
7. 8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
ASSEMBLY DRAWING
Pg. #10
Fig. 1
TROUBLESHOOTING
TROUBLE SUGGESTIONS
- Check fuses and circuit breakers.
1. Fan will not start - Check wiring connections to fan.
- Check wiring connections in switch housing.
CAUTION: Turn power off for last two items.
2. Fan sounds noisy - Check to make sure that all screws in motor housing are snug.
- Check to make sure that blade bracket screws are tight.
- Check to make sure that marrettes in switch housing
are not rattling against wall of switch housing.
- If fan has a light kit make sure switch housing
screws and set screws are tight.
- Some fan motors are sensitive to signals from solid
state variable controls. If solid state controller is
used, change to an alternative control.
- Allow a 24- hour break- in period to eliminate most noises.
3. Fan wobbles - Check that all blades are screwed firmly into blade brackets.
or shakes
excessively.
- Check that blade brackets are secured firmly to motor.
- Check distance from tip of blades to ceiling.
- Check distance between blade tip to blade tip. All
measurements should be equal. Loosen blade
screws and position blade until even then re-tighten.
- Check that the downrod hemisphere notch is engaged in canopy.
- Check to make sure that jam screws in downrod are tightened.
- Make sure canopy and mounting bracket are tightened
securely
to wooden joist.
Stamped Blade
Brackets
26.
23. 25.
24.
22.
21.
20.
Light Kit
19.
Flat Washer
Fibre Washer
Blade
26.
Motor Screw
Blade Bracket
Blade Bracket Screws
Hex Nut
20.
21.
22.
23.
24.
25.
- Make sure warpage has not occurred in wooden
blades. If so, contact the customer service
department for replacement parts.
