4x2 HDMI 2.0a Q -uad View Video Processor
with 4K2K60 4:4:4 & USB 3.0 FHD Video
Capture Function
User Manual
BG 4X2- - -UHD QVP
Safety and Notice
The BG UHD- - - QVP 4X2 4x 2.0a 2K60 4:4:42 HDMI -Quad View Video Processor with 4K & USB
3.0 FHD Video Capture Function has been tested for conformance to safety regulations and
requirements, and , has been certified for international use. However, like all electronic equipment
the BG UHD- - - QVP 4X2 should be used with care. Please read and follow the safety instructions to
protect yourself from possible injury and to minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION .................................................................................................................. 1
FEATURES ........................................................................................................................... 1
PACKAGE CONTENTS ........................................................................................................ 2
SPECIFICATIONS ................................................................................................................ 3
HARDWARE INSTALLATION 4..............................................................................................
CONNECTION DIAGRAM .................................................................................................... 4
PANEL DESCRIPTIONS ...................................................................................................... 5
OPERATION APPROACH .................................................................................................... 6
USB PIN DEFINITION ........................................................................................................ 21
WARRANTY ....................................................................................................................... 22
SECOND YEAR ASSURANCE………..………..………..………..………..………………..23
MISSION STATEMENT………..………..………..………..………..………..………..……..23
1
INTR U OD CTION
The BG UHD- -QVP-4X2 4x & 2 HDMI 2.0a Quad-View Video Processor with 4K2K60 4:4:4
USB 3.0 FHD Video Capture Function provides the most flexible and cost effective solution in
the market to route ultra- definition video source from any of the four UHD HDMI sources to high
the remote display at the same time. Using powerful built-in USB 3.0 capture & auto scale down
features, users can broadcast up to 1080p video & 2ch audio thru real-time on line software,
such as skype. This unique function makes this 4K video processor perfectly work as a live
switch for either educational or multiple commercial applications. This solutio also well suited n is
for use in digital signage, conference room presentation systems or other similar settings or
applications.
With up to 4K2K60 4:4:4 output resolution, users can display the mixed video with improved
presentation quality. In the meantime, the unit can be controlled thru the popular serial port and
Ethernet port to provide the most flexible control way to fit into any applications.
FEATURES
l 4x HDMI inputs and 2x HDMI outputs
l Input resolutions support from 640x480 to x @60Hz (4:4:4 8bits), interlaced or 4096 2160
progressive
l Output resolutions support up to 4K2K@60Hz (4:4:4 8bits)
l Adjustable size & position through software and Cloud
l Supports PIP, PBP, POP, full screen & quad-view display
l HDCP 1.4 com /2.2 pliant
l Firmware upgradable support of new features and technology enhancements to
l Titles, borders and colored backgrounds
l Supports Background picture & logo update
l Resize, position, zoom & pan and blend output video
l Supports seamless, fade- -&- and dissolve switching on full screen mode in out wipe,
l Perfect as a video converter and a live video switcher
l Pure unaltered uncompressed 7.1ch digital HDMI
l Software control through RS-232 and Ethernet
l Supports IR remote and front panel control
l Supports Cloud Control*
l Supports USB 3.0 FHD Video Capture
- HDMI video and audio streams over USB 3.0
