Seite 1/44

BG-4KND-12XUHP

4K UHD PTZ CAMERA

User Manual

Attention

This manual introduces functions, installations and operations for this 4K camera in detail. Please read this

manual carefully before installation and use.

1. Caution

1.1 Avoid damage to product caused by heavy pressure, strong vibration or immersion during transportation,

storage and installation.

1.2 Housing of this product is made of organic materials. Do not expose it to any liquid, gas or solids which may

corrode the shell.

1.3 Do not expose the product to rain or moisture.

1.4 To prevent the risk of electric shock, do not open the case. Installation and maintenance should only be carried

out by qualied technicians.

1.5 Do not use the product beyond the specied temperature, humidity or power supply specications.

1.6 Wipe it with a soft, dry cloth when cleaning the camera lens. Wipe it gently with a mild detergent if needed. Do

not use strong or corrosive detergents to avoid scratching the lens and affecting the image.

1.7 This product contains no parts which can be maintained by users themselves. Any damage caused by

dismantling the product by user without permission is not covered by warranty.

2. Electrical Safety

Installation and use of this product must strictly comply with local electrical safety standards.

The power supply of the product is ±12V, the max electrical current is 2A .

3. Install

3.1 Do not rotate the camera head violently, otherwise it may cause mechanical failure.

3.2 This product should be placed on a stable desktop or other horizontal surface. Do not install the product

obliquely, otherwise it may display inclined image.

3.3 Ensure there are no obstacles within rotation range of the holder.

3.4 Do not power on before completing the install .

4. Magnetic Interference

Electromagnetic elds at specic frequencies may aect the video image. This product is Class A. It may cause

radio interference in household application. Appropriate measure is required.

Content

1. CAMERA INSTALLATION ............................................................................................................................. 4

1.1 C AMERA NTERFACESI ................................................................................................................................... 4

1.2 P - I OWER ON NITIAL ONFIGURATIONC ............................................................................................................ 4

1.3 V O IDEO UTPUT ............................................................................................................................................ 5

1.4 M B OUNTING RACKETS................................................................................................................................. 5

2. PRODUCT OVERVIEW .................................................................................................................................. 7

2.1 P I . 7 RODUCT NTRODUCTION ............................................................................................................................

2.1.1 Dimension ............................................................................................................................................ 7

2.1.2 Accessories ........................................................................................................................................... 8

2.2 M F AIN EATURES .......................................................................................................................................... 8

2.3 T ECHNICAL PARAMETERS............................................................................................................................. 8

2.4 I NTERFACES NSTRUCTIONI ......................................................................................................................... 10

2.4.1 External Interface ............................................................................................................................... 10

2.4.2 RS-232 Interface..................................................................................................................................11

3. APPLICATION INSTRUCTION 13....................................................................................................................

3.1 V O IDEO UTPUT .......................................................................................................................................... 13

3.1.1 Power-On Initial Conguration ........................................................................................................... 13

3.1.2 Video Output ...................................................................................................................................... 13

3.2 R C EMOTE ONTROL ..................................................................................................................................... 13

3.2.1 M ATCH ODE FOR IRELESS EMOTE ONTROLC W R C ..................................................................................... 13

3.2.2 Keys Introduction for IR Remote Control 14...........................................................................................

3.3 M I ENU NTRODUCTION................................................................................................................................ 17

3.3.1 Main Menu ......................................................................................................................................... 17

3.3.2 System Setting .................................................................................................................................... 18

3.3.3 Camera Setting ................................................................................................................................... 19

3.3.4 P/T/Z .................................................................................................................................................. 22

3.3.5 Video Format ...................................................................................................................................... 23

3.3.6 Version ............................................................................................................................................... 23

4. NETWORK CONNECTION .......................................................................................................................... 24

4.1 C M 24 ONNECTION ODE...................................................................................................................................

4.2 W B L EB ROWSER OGIN ............................................................................................................................... 26

4.2.1 Web Client .......................................................................................................................................... 26

4.2.2 Preview .............................................................................................................................................. 26

4.2.3 Playback ............................................................................................................................................. 27

4.2.4 Conguration ..................................................................................................................................... 27

4.2.5 Video Conguration ........................................................................................................................... 28

4.2.6 Network Conguration ....................................................................................................................... 30
