Seite 1/32

INSTALLATION USER GUIDEAND

FOR RESIDENTIAL USE ONLY

24007 rev. A

AB0039

CENTRAL VACUUM POWER UNITS

M SFDB-DH, SFDB-DI, SFDB-DJ SFDB-DTODELS AND

VENMAR VENTILATION WWW BROAN ULC . .CA 1-877-896-1119

BQ550 / BQ650 / BQ700 / BQ500KIT

SAVE THESE INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE

WARNING

To reduce the risk of fire, electric shock or injury:

1. Do not use on wet surfaces or outdoors.

2. Do not vacuum liquids or fine powders (such as

drywall dust).

3. Do not use to pick up flammable or combustible

liquids such as gasoline or use in areas where they

may be present.

4. Do not pick up anything that is burning or smoking,

such as cigarettes, matches, or hot ashes.

5. Do not allow to be used as a toy. Close attention is

necessary when used by or near children.

6. Use only as described in this manual. Use only

manufacturer's recommended attachments.

7. Keep hair, loose clothing, fingers and all parts of

body away from openings and moving parts.

8. Turn off all controls before unplugging.

9. Use extra care when cleaning on stairs.

10. Do not handle plug or appliance with wet hands.

11. Do not use with damaged cord or plug. If appliance

is not working as it should, if it has been dropped,

damaged, left outdoors, or dropped into water, return

it to a Service Center.

12. Keep your work area well lighted.

13. Connect to a properly grounded outlet only. See

grounding instructions shown on page 9.

14. When performing installation, servicing or cleaning

the unit, it is recommended to wear safety glasses

and gloves.

15. When applicable local regulations comprise

more restrictive installation and/or certification

requirements, the aforementioned requirements

prevail on those of this document and the installer

agrees to conform to these at his own expenses.

CAUTION

1. Do not put any object into openings. Do not use with

any opening blocked; keep free of dust, lint, hair and

anything that may reduce air flow.

2. Ensure air flows freely and exhausts unobstructed

from top or side outlet.

3. Do not use without filter (or filters, according to the

model) in place.

4. Do not use to blow leaves or debris.

5. Do not place any object on top of the unit.

6. Do not install the unit horizontally.

7. Do not use the pail as a wash bucket.

8. Do not use the pail as a stool.

9. Avoid picking up sharp objects.

10. This appliance is for use on a standard 120 VAC,

dedicated 15-amp branch circuit. Some brands of

house panel breakers may be more sensitive to

startup current than others (for example, Square

D brand). In the event where nuisance tripping of

the house panel breaker occurs*, we recommend

changing the breaker with an “HM” type of the same

AMP rating.

*after ensuring that the circuit is DEDICATED to the

central vacuum unit, meaning that there is no other

electrical device connected to the central vacuum

unit circuit.

11. Do not unplug the unit by pulling on cord. To unplug,

grasp the plug, not the cord.

12. Store your vacuum cleaner indoors in a clean, dry

area, and away from extreme temperatures.

13. Any servicing other than that recommended in

this manual should be performed by an authorized

service facility.

14. We recommend that your unit be inspected by a

specialized technician once a year.

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the following:

TABLE OF CONTENTS

GENERAL INFORMATION .........................................................................................................4

TOOL LISTING .......................................................................................................................................................4

WORKING WITH PLASTIC TUBING......................................................................................................................4

CUTTING TUBING ......................................................................................................................................................4

M ........................4AKING A JOINT ..............................................................................................................................

C .......4EMENTING FLEXIBLE TUBING ..............................................................................................................................

S ............4ECURE WIRE TO TUBING ..............................................................................................................................

WALL INLET INSTALLATION ....................................................................................................4

M AKING THE WALL INLET CUTOUT ................................................................................................................................4

ATTACHING THE INLET MOUNTING PLATE (V144) ............................................................................................................4

C OMPLETING THE INLET ASSEMBLY ..............................................................................................................................4

INSTALLING THE INLET (V111) ....................................................................................................................................4

V800W CANSWEEP® UNDER CABINET INSTALLATION .................................................... 5-6

V800W CANSWEEP® BASEBOARD WALL INSTALLATION ....................................................7

POWER UNIT INSTALLATION ...................................................................................................8

LOCATING THE POWER UNIT ..............................................................................................................................8

CHANGING INTAKE LINE DIRECTION .................................................................................................................8

MOUNTING THE POWER UNIT ............................................................................................................................9

FITTING MAIN LINE TO POWER UNIT ...............................................................................................................10

GROUNDING INSTRUCTIONS ................................................................................................10

WIRING ................................................................................................................................................................ 10

OPERATION AND MAINTENANCE .........................................................................................11

WHEN TO CHANGE BAG* OR EMPTY DEBRIS PAIL ........................................................................................ 11

HOW TO EMPTY DEBRIS PAIL (BQ650 AND BQ700 POWER UNITS ONLY) ................................................... 11

BQ550 AND BQ500KIT POWER UNITS DETAILED VIEW .................................................................................. 11

DISPOSABLE BAG REPLACEMENT (BQ550 AND BQ500KIT POWER UNITS ONLY) ..................................... 11

PERMANENT FILTER (BQ650 AND BQ700 POWER UNITS ONLY) ..................................................................12

REMOVAL AND INSTALLATION OF PERMANENT FILTER (BQ650 AND BQ700 POWER UNITS ONLY) ........12

MOTOR FOAM FILTER (ALL UNITS) ..................................................................................................................12

REMOVING FOAM FILTER MOTOR ................................................................................................................................ 12

REINSTALLING FOAM FILTER MOTOR ............................................................................................................................12

ACCESSORIES (BQ500KIT ONLY) .........................................................................................13

ACCESSORIES INCLUDED ................................................................................................................................13

INSTALLING HOSE HANGER ............................................................................................................................. 13
