Seite 1/6
For technical support, call (888) 942-3060 or email info@visiontechamerica.com www.VisionTechAmerica.com
USER MANUAL
VTL17AI
Concealed License Plate Backup Camera
With Intelligent Pedestrian and Vehicle Detecon and Warning
1. Part List
Camera
Buzzer
Video Extension
Power Harness
2. Features 3. Specicaon
Concealed license plate mount
ed camera
Intelligent object detecon
Detects: pedestrians, vehicles (cars, trucks, motorcycles, …)
Audible warning buzzer when object is in warning area
High, low, and oî…– - buzzer volume control
Buzzer, cables, and mounng screws included.
Images Sensor CVBS- 1/2.9” GC2053
TV System NTSC
Eecve Pixels 976 (H) x 592 (V)
Minimum Illuminaon 0.1Lux
Viewing Angles 130 (H), 170 (D)
Operang Temperature -4 158
Operang Voltage 6V ~ 15V DC
Video Ext. / Buzzer Cable 24 feet
4. Wiring
Camera Power Harness
Video Extension
5. Pedestrian and Vehicle Detecon Area Adjustment
ď‚· The green loop on the camera pigtail.
o If uncut, the AI detects all persons and vehicles in the camera view, no parking guidelines will
be displayed, and no alarm will occur.
o If cut, the alarm area will be shown, and alarm will sound when object(s) is in the alarm area. Alarm sound
can be turned oî…– using the volume control on the speaker.
ď‚· The alarm area is shaded in BLUE. When an object is in the alarm area, the alarm area color changes to RED and
alarm sounds.
 To adjust the detecon area, loosen the two screws next to the camera and lt the camera up or down.
RED: Backup Light (+)
BLACK: Ground (Chassis)
RED wire: To Monitor
Reverse Trigger
RCA: To Monitor
Backup Camera
Volume Control: on
the speaker
Produktspezifikationen
| Marke: | Boyo |
| Kategorie: | Dashcam |
| Modell: | VTL17AI |
