CHAMBER TUBELESSâ˘
Floor pump
Part# 7085522
31.8mm stem clamp
15.75" riser bars
Alloy pump mode lever
OPERATING IN PUMP/RELEASE MODE
Operate pump in âPump/Releaseâ mode with lever
locked in vertical position (FIGURE A). This will allow
air to bypass reservoir for more efficient
direct-to-tire pumping.
T6063 Alloy barrel
Hose pivot
Anyvalve⢠pump head
160 PSI, top-mounted gauge
Air bleed button
Stamped metal base
Extra long 4ft hose
Note: Air bleed does not work on Dunlop valves.
2. PUMP
1. CHARGE
3. RELEASE
TO USE IN CHARGE MODE AND SEAT TIRE
1. Rotate lever up 90° to âCHARGEâ mode with lever in
horizontal orientation. Insure it locks in place.
2. Operate pump and charge reservoir to 160psi. (Figure B)
3. Return lever back to âPump/Releaseâ mode to
instantly release tire bead seating pressure.
SHORT PRESTA/
DUNLOP
LONG PRESTA/
SCHRADER
Air bleed
>20mm LONG
PRESTA
<20mm SHORT
PRESTA
ANYVALVE PUMP HEAD WITH AIR BLEED BUTTON
WARNING: DO NOT CHARGE YOUR PUMP PAST 160PSI AS INDICATED ON THE GAUGE. NEVER OVERINFLATE YOUR TIRE. SEE SIDEWALL FOR MANUFACTURER
RECOMMENDED TIRE INFLATION PSI. KEEP FINGERS CLEAR OF TIRE WHEN SEATING BEAD.
B.
A.
Customer Service: 1-800-456-2355
Blackburndesign.com
Printed in Taiwan
CHAMBER TUBELESS
â˘
Floor pump
â
FIGURE 1A FIGURE 1B
â
FIGURE 2A FIGURE 2B
FIGURE 3
FIGURE 4
FIGURE 5
FOUR (4) HEX BOLTS
Visit us at blackburndesign.com for product updates.
WHEN SEATING AND INFLATING TUBELESS TIRES
Carefully follow the tire manufacturerâs recommended installation instructions. When installing new valve
stems, tighten the stem completely as to ensure a leak free seal. If installation is correct, the bead of the
tire will audibly pop into the rim as shown in Figure 3 and the tire will inflate. Use the pump to dial in your
desired pressure. Use the air bleed button on the ANYVALVE pump head to release air if necessary.
NOTE: There are two common reasons for inflation and bead seal failure.
1. The tire was not properly installed. See figure 1A for a correct tire installation.
2. The valve stem was not tightened completely. See figure 2A for a correct valve stem installation.
If inflation fails, deflate the tire and check for correct installation of the rim and valve. Once correct
installation is confirmed, follow the inflation sequence again to correctly install and inflate the tire.
USING THE CONDENSATION DRAIN (FIGURE 4)
It is recommended that you drain the water periodically to prevent water from collecting inside the chamber.
The drain valve is located on the base of the pump. Use a flathead screwdriver to loosen the valve. (FIGURE 4)
NOTE: The valve does not completely remove from the pump. Make sure the valve is completely
locked tight after you drain the water. Air leak may happen if the valve is not locked tight
.
USE YOUR OWN 31.8MM HANDLEBARS
This pump can be customized using any 31.8mm handlebar and the grips of your choice. To install, remove the
four 3mm hex bolts from the stem clamp (FIGURE 5). Replace the bars. Reinstall the hex bolts and tighten securely.
Customer Service: 1-800-456-2355
Blackburndesign.com
Printed in Taiwan
