Seite 1/7
AUSTRALIA / NEW ZEALAND
Assembly and Operating Instructions SIDE BURNER
BS26010, BS26410
2CONTENTS
Dear customer,
Congratulations and thank you for choosing our appliance.
We are sure you will find it a pleasure to use. Before you use
the appliance, we recommend that you read through the
relevant sections of this manual, which provide a description
of your appliance and its functions.
To avoid the risks that are always present when you use
an appliance, it is important that the appliance is installed
correctly and that you read the safety instructions carefully to
avoid misuse and hazards.
We recommend that you keep this instruction booklet
for future reference and pass it on to any future owners.
After unpacking the appliance, please check it is not
damaged. If in doubt, do not use the appliance but contact
your local customer care centre.
This appliance complies with requirements of Australian
Standards AS4563.
CONDITIONS OF USE
These important notes apply to your appliance, failure to
adhere to these conditions of use may affect your ability to
make a claim under the manufacture’s warranty.
• This appliance MUST be installed and serviced only by a
qualified licensed person.
• This product is intended for installation and use at a
domestic residence only. This product is not intended for
commercial use.
• This product is not suitable for installation or use in
marine craft, caravans or recreational vehicles.
• This product must be installed in accordance with these
instructions, the requirements of AS/NZS 5601.1 and in
accordance with local authority.
• This product must be installed, operated and maintained
as per the instructions.
• Ventilation holes in the unit must not be obscured by the
installation.
Please ensure you read the instruction manual fully
before you call for service, or a full service fee could
be applicable.
Record model and serial number here:
Model number: ...............................................................................
Serial number: ................................................................................
PNC: ................................................................................................
CONTENTSCONGRATULATIONS
Important safety instructions .......................................................3
Assembly .......................................................................................4
Operating instructions ................................................................ 6
Care and maintenance .................................................................7
Location ........................................................................................9
Otdoor installation ........................................................................9
Warranty .....................................................................................11
Please read the user manual carefully and store in a handy
place for later reference.
The symbols you will see in this booklet have these
meanings:
WARNING
This symbol indicates information concerning your
personal safety.
CAUTION
This symbol indicates information on how to avoid
damaging the appliance.
IMPORTANT
This symbol indicates tips and information about use
of the appliance.
ENVIRONMENT
This symbol indicates tips and information about
economical and ecological use of the appliance.
IMPORTANT INFORMATION THAT MAY
IMPACT YOUR MANUFACTURER’S WARRANTY
Adherence to the directions for use in this manual
is extremely important for health and safety. Failure
to strictly adhere to the requirements in this manual
may result in personal injury, property damage
and affect your ability to make a claim under the
BeefEater manufacturer’s warranty provided with
your product. Products must be used, installed and
operated in accordance with this manual. You may
not be able to claim on the BeefEater manufacturer’s
warranty in the event that your product fault is due to
failure to adhere this manual.
4
Connection to Barbecue
Ensure all gas controls on the barbecue and side burner are
set to OFF.
Take the connector hose that came with the side burner.
Connect one end to the inlet of the barbecue. Connect the
other end to the left side gas connection point of the
side burner.
If your barbecue came with a cabinet trolley/ cart, your
connector hose should already be attached to the barbecue
inlet (as indicated by the separate cart instructions). In this
case, simply pass the free end of the hose through the hose
access hole in the side of the cart prior to connecting to the
side burner inlet.
side burner gas
connection
connector hose
Connection To Gas Supply
Ensure all gas controls on the barbecue and side burner are
set to OFF.
Attach the gas supply hose to the right side inlet of the
side burner.
If the gas supply hose is not already attached to the gas
supply, then attach it now.
If your barbecue came with a cabinet trolley/cart, your gas
supply hose may already be attached to a portable gas
cylinder located inside the cabinet. In this case, simply pass
the free end of the hose through the hose access hole in the
side of the cart prior to connecting to the side burner inlet.
Using two spanners, tighten all gas connections. Do not
overtighten.
LPG gas
supply hose
4ASSEMBLY AND GAS CONNECTION
ASSEMBLY AND GAS CONNECTION INSTRUCTIONS
NATURAL
GAS
REFER TO LOCAL
GAS AUTHORITY FOR CONFIRMATION OF GAS
TY FIEP DNI OU TB
LPG
PROPANE
GAS
REFER TO LOCAL
GAS AUTHORITY FOR CONFIRMATION OF GAS
TY TBUODNIFIEP
Assembly
Attach your side burner to your barbecue trolley as explained
in the separate barbecue/trolley instructions.
Attach The Trivet
Place the trivet on the body of the side burner. The small
notches underneath the trivet should sit neatly in the holes
in the steel, as shown.
Temporarily Remove The Drip Plate
In order to properly connect the hoses to the side burner, you
may find it easier to remove the drip plate from underneath
the side burner.
Simply undo the screw at the front of the side burner as
shown, and then ease the rear drip plate tabs from the side
burner body.
You now have clear access to the side burner inlets.
hose
access
hole
