Seite 1/4
Encounter
16x70mm
Binocular Telescope
Operating Instructions
WARNING!
NEVER LOOK DIRECTLY AT THE SUN
THROUGH YOUR BINOCULARS WITHOUT
PROFESSIONALLY MADE SOLAR
FILTERS, EVEN FOR AN INSTANT
OR PERMANENT EYE DAMAGE
COULD RESULT. YOUNG CHILDREN
SHOULD USE THESE BINOCULARS
ON SUNNY DAYS ONLY WITH
ADULT SUPERVISION.
Diopter Scale
Removeable
Carry Handle
Eyepiece Holder
Focus Ring Grip
Eyepiece Holder
Lens Shades (Retracted)
IP Knob (Not visible)
Mounting Plate
(Not visible)
Hard Storage Case
Eyepiece
Eyepiece
BARSKA | Pomona, CA 91767 | Tel: 888.666.6769 | Fax: 909.445.8169
www.barska.com
BINOCULAR PARTS
Figure 1.
Telescope. Please carefully read the following instructions. With proper care and use of
this instrument, you will be assured of many years of enjoyable viewing.
Congratulations on your purchase of a BARSKA Encounter 16x70mm Binocular
Encounter 16x70mm Binocular
Telescope Operating Instructions
2.
BARSKA Model AF10738
Professional Photo Tripod
www.barska.com
Figure 4.
ENCOUNTER - BREATHTAKING VIEWS
OF THE NIGHT SKY AND THE LD WOR
AROUND YOU.
The l ge o ical system of the B SKA ar pt AR
Encounter Binocular Telescope provides the
amount of light gathering that is necesssary
for astronomical observation and , unlike a
conventi al telescope, a ows you to use on ll
both eyes simultaneously for viewing. As a
result, you have better image resolution,
contrast and brightness than a similar size
tel cope. es The 90-degree eyepiece viewing
angle makes obs ving at night re er mo
comfortable and convenient. With proper
c e, the ed body con ion and ar rugg st ctru
wat proof design of this inster rument ll wi
en easure y rs of enjoyable viewing.
Impor nt: Pta lease read the ing fo owll
instructions carefully.
2. INSERTING THE EYEPIECES
To install the included eyepieces:
1. Remove the cover caps from the
binoculars and eyepieces.
2. Insert the eyepieces into the binocular's
eyepiece holders.
3. Gently push the eyepieces
down into the holders until
they are fully seated (Fig.2).
4. To remove the eyepieces,
carefully pull the eyepieces
from the holders.
3. EXTENDING THE LENS SHADES
The extendable lens shades help to increase
contrast by preventing unwanted glare from
entering the objective lenses. They also slow
the formation of dew or moisture on the
objective lens exterior surface.
To extend the lens shades:
1. Grasp lens shade with
your fingers.
2. Carefully pull lens shade
outwards (Fig.3).
4. ADJUSTING THE EYEPIECE
DISTANCE BETWEEN YOUR
EYES (INTERPUPILLARY DISTANCE)
To adjust the interpupillary (IP) distance:
1. Turn the chrome IP knob located between
the eyepieces.
2. Rotate the knob until the distance between
the eyepieces matches the distance
between your eyes.
3. When properly
adjusted, you should
see a single round
field of view when
looking through
the eyepieces.
4. Important: Make this adjustment
BEFORE you attempt to focus the
binoculars.
1. USING A TRIPOD
When ob ing with a large aperture serv
binocular like the Encounter, a sturdy photo
tripod such as the
BARSKA AF10738 or
an altazimuth mount
is required. To attach
the Encounter to a
photo tripod, simply
thread the tripod's
1/4"-20 mounting
stud into the threaded
hole in the Encounter's
mounting plate.
To attach the binocular
to an altazimuth mount,
that utilizes a dovetail holder, an optional
dovetail L-Bracket (available from a camera
or telescope d ler) is qui d. The ea re re
L-Bracket ts to the Enco t 's connec un er
mounting plate and has a dovetail bar that
goes rectly into the mo t's dove il di un ta
holder.
Figure 2.
Figure 3.
BARSKA | Pomona, CA 91767 | Tel: 888.666.6769 | Fax: 909.445.8169
3.
www.barska.com
Figure 5.
Diopter Scale
Figure 6.
5. FOCUSING THE ENCOUNTER
BINOCULAR TELESCOPE
The BARSKA Encounter Binocular Telescope
eyepieces can be individually focused and
help maintain optical alignment (Fig.5).
To focus the binocular:
1. During daylight, pick
a stationary distant
object to view such
as a street sign. At
night, the best focus
will be achieved by
focusing on the Moon or a bright star.
2. Cover your right eye (or cover the right
objective lens of the binocular) and focus
the left eyepiece by slowly rotating the
rubber grip ring on the eyepiece holder
until the image appears clearest. To focus
the right eyepiece, repeat this procedure
but cover your left eye or the left
objective lens of the binocular. The
binocular should now be in focus.
3. If you want to view an object at a
different distance, re-focusing of both
eyepieces is required.
4. Changing the eyepieces may also require
some slight focus adjustments.
Astronomical Observation:
All objects will always appear focused at the
infinity focus point. This means that you only
need to focus the bi culars once per no
viewing session. This also means that you
can take note of the diopter scale setting for
each eyepiece when
focused on an
astronomical object and
return to those settings
when observing another
night (Fig.6). Since
everyone's eyes focus
on images slightly
differently, other observers who are using
the binoculars will need to re-focus the
binoculars and adjust them to their own
vision and interpupillary distance.
6. FOLD-DOWN EYEGUARDS
The Encounter Binocular Telescope features
fold-down eyeguards on the eyepieces.
The eyeguards are usually left
in the up position for use
without eyeglasses as this
helps prevent glare from
entering between the eye
and eyepiece.
To use the binoculars with eyeglasses:
1. Fold the eyeguards down in order to get
your eyes close enough to the eyepieces
to see the entire field of view.
7. CLEANING AND CARE OF BINOCULAR
To protect your binocular, please follow these
important instructions:
Outside Surface
1. The Encounter Binocular Telescope is
nitrogen-purged and sealed to be
waterproof and internally fogproof.
However, DO NOT immerse the binocular
in water under any circumstances.
2. If the binocular becomes wet with fresh
water, blot it dry with a clean dry cloth.
3. If the binocular becomes wet with salt
water, the surface should be rinsed off
completely and the binocular blotted dry
with a clean cloth.
4. If the binocular body becomes dirty, it
can be cleaned with warm water and a dry
cloth.
5. If extremely dirty or oily, clean the body
with a dilute solution of warm water and
mild soap on a cloth, then rinse with clean
water and blot dry.
Lens Surface
The lens surfaces of the Encounter Binocular
Telescope are coated with anti-reflection
multi-coatings than can be easily damaged
with careless handling. To protect the
binocular's lenses, please follow these
recommendations:
1. DO NOT CLEAN LENS SURFACE WITH
SOAP AND WATER!
Figure 7.
Encounter 16x70mm Binocular
Telescope Operating Instructions
BARSKA | Pomona, CA 91767 | Tel: 888.666.6769 | Fax: 909.445.8169
