Read all instructions before use
* Actual Model May Vary
Interpupillary Distance Adjustment
The distance between the eyes, called “interpupillary
distance” (IPD), varies from person to person. To
achieve perfect alignment of lens to eye, follow
these steps.
1. Hold your binocular in the normal viewing position
and look at an object in the distance.
2. Grasp each of the binocular barrels firmly. Move the
barrels closer together or further apart until you see a
single circular field.
Focusing
After adjusting the interpupillary distance, follow steps
below to focus the binoculars.
1. Close your right eye and look at an object in the
distance through the left eyepiece with your left eye.
Rotate the center focus until image is clear.
2. Close your left eye and look at the same object in the
distance through the right eyepiece with your right
eye. Rotate the right eye diopter until the image
is clear.
3. Look through the binocular with both eyes and image
should be clear, rotate the center focus for any further
image adjustments.
Eye Cups
The binocular is designed with twist up eye cups for
your comfort. To exclude extraneous external light thus
providing improved field of view.
Eye Cups Down
Sunglasses / Eyeglasses Wearers
Eye Cups Up
Non Sunglasses / Eyeglasses Wearers
DO NOT use this optical product to view the
Sun or any light source. CAUTION: Viewing
the Sun can cause permanent eye damage.
BC506
©2016 BARSKA®
855 Towne Center Drive | Pomona, CA 91767
(t) 888.666.6769 | (f) 909.445.8169 | www.barska.com
D
F
B
AC
G
E
Parts Of The Binocular
A. Eyepiece
B. Right Eye Diopter
C. Center Focus
D. Twist Up Eye Cups
E. Neck Strap Eyelet
F. Objective Lens
G. Tripod Adaptable Fitting
Waterproof / Fog Proof
The binocular is O-ring sealed for complete waterproof
protection to keep the inside dry after contact with
moisture. Fog proof protection is achieved from argon
purging which removes all internal moisture to prevent
anti-fogging inside the optical surfaces.
Tripod Adapter Fitting
The binocular is equipped with a built in tripod adapter
fitting. Carefully unscrew the cover screw located at the
base of the binocular hinge to expose the threaded
mounting socket for the tripod adapter to attach to.
Tripod adapter NOT included.
Care and Cleaning
Care
If handled with care, this binocular will provide years of
trouble-free service. Like any fine optical instrument
your binocular should be given sensible care.
- Keep the lens covers on the lenses when binoculars
are not in use.
- Store binoculars with the eye cups down.
- Avoid banging and dropping.
- Store in a cool, dry place.
Cleaning
- Blow away any dust or debris on the lens (or use a
soft lens brush)
- To remove dirt or fingerprints, clean with a soft cotton
cloth rubbing in a circular motion. Use of a coarse
cloth or unnecessary rubbing may scratch the lens
surface and eventually cause permanent damage.
- For a more thorough cleaning, photographic lens
tissue and photographic-type lens cleaning fluid or
isopropyl alcohol may be used. Always apply the fluid
to the cleaning cloth never directly on the lens.
NEVER attempt to clean your binocular internally or
try to take it apart.
See reverse side for more information
User Manual
©2016 BARSKA®11/16BC284
LIMITED LIFETIME WARRANTY
BINOCULARS
BARSKA® Optics, as manufacturer, warrants this new precision
optical product to be free of original defects in materials and/or
workmanship for the length of time specified by this warranty.
This warranty does not include damage caused by abuse, improper
handling, installation, maintenance, normal wear-and-tear,
unauthorized repairs or modifications and tampering in anyway.
This warranty is limited to the original purchaser and is not
transferable. This warranty applies only to products purchased in
the United States of America.
In the event of a defect within 30 days, the consumer must return
the defective unit to the BARSKA dealer (the place of purchase) at
his/her own expense.
Beyond 30 days, BARSKA products should be sent to the following
address for warranty repairs. Products must be packed carefully
and sturdily to prevent damage in transit, and returned freight
prepaid to:
BARSKA OPTICS
Repair Department
855 Towne Center Drive
Pomona, CA 91767
For additional and updated information
please visit our website at www.barska.com
Please email info@barska.com or call 1.888.666.6769 for Return
Merchandise Number (RMA#) before any returns. NOTE: All
merchandise received without a valid RMA # will be returned to
shipper at his/her own expense.
Please include all of the following when returning BARSKA products
for service and/or replacement:
1. Please write your complete details (Name, Address, Telephone #,
E-mail address, RMA#, etc.)
2. Purchase receipt or Proof of Purchase. (Original/Copy)
3. A brief explanation of the defect.
*Please allow 6-8 weeks for delivery.
This product will either be replaced or repaired at the discretion of
the warrantor. If it's a discontinued item, we will replace the product
with an equivalent product. Should the repair not be covered by this
warranty, an estimate will be sent for your approval. Non-warranty
repairs or refurbishing of your optical products are always provided
at a reasonable cost.
BARSKA® Optics shall not be liable for any consequential,
incidental and/or contingent damages whatsoever. We will not pay
shipping, insurance or transportation charges from you to us, or any
import fees, duties and or taxes.This warranty supersedes all
previous BARSKA® Optics warranties.
