Made in FALLS-ENG China INS-1902022B-TACOMA 8-30-23
For the most up to date assembly manual,
to register your set, or to order replacement parts please visit
www.backyarddiscovery.com
SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT
YOU NEED TO ORDER REPLACEMENT PARTS.
Model # 1902022B
TACOMA FALLS SWING SET
Owner's Manual & Assembly Instructions
MANUFACTURED BY:
Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
800-856-4445
averag 2 person ssembly timee a
assembly time may vary based n level o skill
average tube e assembly e slid tim
WARNING
Adult Assembly Required.
The assembly manual must be retained since it contains important information
Not suitable for children under two years due to sharp points and small parts.
FOR DOMESTIC USE ONLY. INTENDED FOR OUTDOOR USE.
CAN ICES-003 (B)/NMB-003(B)
Safe Play Zone
SAFE PLAY HEIGHT: 16'-9 3/4" [5.1 m]
MAXIMUM FALL HEIGHT: 7'-1/4" [2.1 m]
General Information:
Your set has been designed and engineered for children only and for residential use only.
A maximum of 150 lbs. per child is recommended for play activities designed for individual use.
A maximum of 120 lbs. per child is recommended for play activities designed for multiple child use.
A maximum of 9 children is recommended for this swing set.
Owner's Manual Basic Setup Dimensions & Assembly Notes
Ground Dimension
19'-7" x 14'-3 1/4" x 10'-2 3/4"
6m x 4.4m x 3.1m
Safe Play Area
32'-8 1/2" x 27'-4 7/8"
10m x 8.4m
SAFE PLAY AREA DIAGRAM
Place the set on level ground, not less than 6'- 7" [2 m] from any structure or obstruction such as a fence, garage, house,
overhanging branches, laundry lines, or electrical wires.
•
While assembling unit, take time before and after each phase to make sure fort is level. If fort is not level, assembly will
be difficult and improper assembly may result. Extra care must be taken to insure the fort is square.
•
The safe play area refers to a zone extending 6'- 7" (2m) beyond the play product on all sides, including the space above
the play product.
14'-3 1/4"
[4.4 m]
19'-7"
[6 m]
10'-2 3/4"
[3.1 m]
7'- 1/4"
[2.1 m]
27'-4 7/8"
[8.4 m]
32'-8 1/2"
[10 m]
6'-7"
[2 m]
6'-7"
[2 m]
2
Parts Identification Wood Components (Not to Scale)
SWING BEAM - W4L12440
3 3/8"x5 1/4"x89 1/2" (86x134x2274)
A1
(x1)
POST - W4L12286
3"x3"x89 1/2" (76x76x2274)
B1
(x1)
POST - W4L12287
3"x3"x89 1/2" (76x76x2274)
B2
(x1)
POST - W4L12288
3"x3"x89 1/2" (76x76x2274)
B3
(x1)
UPPER POST - W4L12397
3"x3"x21 1/4" (76x76x541)
B5
(x2)
UPPER POST - W4L12428
3"x3"x21 1/4" (76x76x541)
B6
(x2)
BRACE - W4L12312
1 3/8"x3 3/8"x13 5/8" (36x86x347)
E1
(x3)
BRACE - W4L12418
1 3/8"x3 3/8"x13 7/8" (36x86x351)
E2
(x2)
SB 9" BLOCK - W4L12441
3 3/8"x5 1/4"x9" (86x134x228)
A2
(x1)
BRACE - W4L12500
1 3/8"x3 3/8"x37 3/4" (36x86x959)
E3
(x1)
S.B. ANGLE BRACE - W4L12444
1 3/8"x3 3/8"x88 3/4" (36x86x2254)
E4
(x2)
S.B. END SUPPORT - W4L12443
1 3/8"x3 3/8"x44 1/8" (36x86x1120)
E5
x1)
LEFT UPRIGHT - W4L12490
1 3/8"x3 3/8"x58" (36x86x1474)
E6
(x1)
MIDDLE UPRIGHT - W4L12491
1 3/8"x3 3/8"x58" (36x86x1474)
E7
(x1)
RIGHT UPRIGHT - W4L12495
1 3/8"x3 3/8"x58" (36x86x1474)
E8
(x1)
WALL UPRIGHT - W4L12398
1 3/8"x2 3/8"x60 3/8" (36x60x1533)
F1
(x2)
POST - W2A02758
3"x3"x89 1/2" (76x76x2274)
B4
(x1)
3
