Seite 1/184
Cat. No 613
Model: HTD8813
Instrution date: 25.01.2021
EN
PL
BG
CZ
DE
ES
FR
GR
HU
LT
LV
NL
PT
RO
RU
SE
SK
UA
2
12
22
32
42
52
62
72
82
92
102
112
122
132
142
152
162
172
Non contact infrared body thermometer
Termometr bezdotykowy
Електронен безконтактен термометър
Bezdotykový infračervený teploměr
Kontaktloser elektronischer thermometer
Termómetro electrónico sin contacto
Thermomètre électronique sans contact
Θερμόμετρο υπερύθρων ανέπαφης μέτρησης
θερμοκρασίας σώματος
Érintésmentes infravörös hőmérő
Elektroninis bekontaktis termometras
Elektroniskais bezkontakta termometrs
Contactloze infrarood lichaamsthermometer
Termômetro de corpo infravermelho sem contato
Termometru digital non-contact
Термометр электронный бесконтактный
Beröringsfri infraröd termometer
Bezdotykový infračervený teplomer
Термометр електронний безконтактний
2
The non contact Infrared body thermometer operating Instructions intend to provide the necessary information for
proper operation of HTD8813 thermometer model. Only body mode was reviewed and certied by notied body.
General knowledge of Infrared thermometer and an understanding of the features and functions of the HTD8813
thermometer model are prerequisites for proper use. The non contact infrared body thermometer is a medical
device, and can be used repeatedly, which using life is 5 years. Please read the manual rst before using it, if not fully
understand the usages, please stop using the thermometer. Do not operate any of the Model HTD8813 thermometer
without completely reading and understanding these instructions.
1. GENERAL INFORMATION
INTENDED USE
The Non Contact Infrared Body Thermometers are designed to be used for intermittent measurement and monitoring of human body
temperature by consumers in the home setting and primary care setting as screening tool.
DESCRIPTION OF THE NON-CONTACT INFRA-RED THERMOMETER
The Babyono non-contact infrared-red thermometer is a manual, battery-powered device for measuring human body temperature (on the
forehead). The device uses an infrared-red sensor to measure the temperature. The IR sensor generates various signals when measuring
temperatures of dierent objects or when placed in ambient with varying temperature. The ASIC transforms the infra-red signal into a digital
value and shows on the device’s LCD display.
DESCRIPTION OF CONTROL ELEMENTS, INDICATORS AND SYMBOLS
Fig. 1: infrared-red thermometer, part no. 613
1. LCD display
2. Battery cover
3. On / O
4. SET button
5. MEMO button
6. MODE button
7. IR sensor
8. Surface temperature measurement mode
9. Body temperature measurement mode
10. Readout
11. Result indicator
12. Low battery indicator
13. Sound on / o indicator
14. Saved readout number
15. Fahrenheit degrees
16. Celsius degrees
17. Memory indicator
EN Non contact infrared body
thermometer
2.
3.
4.
5.
6.
7.
1.
11.
10.
9.
8.
17.
12. 13.
16.
15.
14.
3
TECHNICAL SPECIFICATION
Measuring unit °C / °F
Operating mode Adjusted mode (body mode)
Direct mode (surface temperature) Direct mode(surface mode)
Measuring site Forehead
Reference Body Site Axillary
Rated output range Body mode: 34,0 °C ~ 43,0 °C / 93,2 °F ~ 109,4 °F
Surface mode: 0 °C ~ 100 °C / 32 °F ~ 212 °F
Output Range Body mode:34.0°C ~ 43.0 °C/ 93.2 °F - 109.4 °F
Surface mode: 0 °C ~ 100.0 °C / 32°F - 212 °F
Laboratory Accuracy Body mode:
34.0 °C ~ 34.9 °C ± 0.3 °C/ 93.2 °F - 94.8 °F ± 0.5 °F
35.0 °C ~ 42.0 °C ± 0.2 °C / 95.0 °F - 107.6 °F ± 0.4 °F
42.1 °C ~ 43.0 °C ± 0.3 °C / 107.8 °F - 109.4 °F ± 0.5 °F
Surface mode:
± 2 °C / ± 3.6 °F
Display resolution 0,1 °C / 0,1 °F
Three-colour backlight
(colour codes) 35.5 °C - 37.3 °C / 95.9 °F - 99,1 °F Green (normal temperature);
37.4 °C - 38.0 °C (alarm point) / 99,3 °F - 100.4 °F Yellow (slight fever)
38.1 °C - 43.0 °C / 100.6 °F - 109.4 °F Red (high fever)
Caution:
1. The colour codes only work in body temperature measuring mode.
2. The backlight is always green when measuring the temperature of surfaces.
3. In body mode 34.0-35.4°C is with green backlight.
Automatic power off time ≤ 18 s
Measuring time ≤ 2 s
Measuring distance 1 cm - 5 cm
Memory slots 50
Power supply requirements
Batteries 1.5 V (AAA) alkaline x 2 (IEC Type LR03)
Operating voltage range 2.6 V ~ 3.6 V
Ambient conditions
Operating conditions Operating temperature: 15 °C ~ 40 °C (59 °F ~ 104 °F),
relative humidity ≤ 85%, atmospheric pressure: 70 kPa -106 kPa
Transpor t and storage conditions Storage temperature: - 20 °C to + 55 °C / - 4 °F to + 131 °F,
relative humidity ≤ 93%, atmospheric pressure: 70 kPa - 106 Pa
Dimensions and weight
Weight (w/o batteries) 90 g
Dimensions L: 138 mm X W: 95 mm X H: 40 mm
Compliance
Item Compliance with
Device classification Safety standard EN 60601-1: 2006+A1:2013, EN 60601-1-2: 2015
Protection type Internally (battery) powered equipment
Type of protection Internally powerd equipment (on battery power)
Degree of protection: Non Applied part
Front panel and case labeling: EN ISO15223-1:2016
Temperature: EN ISO80601-2-56:2017
Home healthcare environment: EN 60601-1-11:2015
Safety classification of ME EQUIPMENT
Protection against electric shock Internally powered ME equipment
Applied part Non Applied par t
Protection against harmful ingress of water or par ticulate matter IP22
Mode of operation Continuous operation
Note: Not intended to be sterillized. Not for use in an OXYGEN RICK ENVIRONMENT
