Seite 1/1
This Pack Contains 1 Pole
www.btechavmounts.com
SINGAPORE
B-Tech AV Mounts PTE Ltd
Ruby Industrial Complex,
Singapore 347740
Tel: (+65) 68412988 Fax: (+65) 6491 5613
Email: info@btechavmounts.com.sg
EUROPE
B-Tech PRO-AV bvba
Brixtonlaan 32, Zaventem 1930,
Brussels, Belgium.
Tel: +32 (0)2 720 92 71 Fax: +32 (0)2 725 42 15
Email: info@btechproav.com
NORTH AMERICA
B-Tech Audio Video Mounts
203 Eggert Road,
Buffalo, NY 14215, USA.
Tel: (1)800 975 5812 Fax: (1)800 592 2876
Email: info@btechavmounts.com
HEAD OFFICE
B-Tech International Ltd.
Bennett House, Long March,
Daventry, Northants, NN11 4NR, UK.
Tel: +44 (0)1327 300 787 Fax: +44 (0)1327 706 562
Email: info@btechavmounts.co.uk
PAGE 1 / 1
IP-BT7850-025-V1-PROBX-230810-01
ASIA PACIFIC
B-Tech International (Hong Kong) Ltd.
1503 Prosperity Millennia Plaza, 663 King's Road,
Quarry Bay, Hong Kong.
Tel: (+852) 2556 7337 Fax: (+852) 2556 7321
Email: info@btechavmounts.com.hk
©2010 Bennett Technologies Limited. All rights reserved.B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech, Better By Design & Mountlogic are registered trademarks of Bennett Technologies Limited.
All other brands and product names are trademarks of their respective owners. Photographs are for illustrative purposes only. E&OE.
MADE IN CHINA
Attention!
Identical safety bolt holes are provided at each end of the
pole. Two orientations are provided at 90 degrees to each
other so that you can best align your AV equipment with the
cable management hole in the ceiling mount or pole joiner.
If poles are cut to length during installation then these
holes should be re-drilled at the equipment end, leaving the
original holes for use in the ceiling mount. The pole end ring
is then used to cover the sawn end and protect your cables
from the rough edge while leaving a clean finish.
Safety bolts are included with all 50mm 'System 2' products
and MUST be set in place before any AV equipment is
fitted. It is imperative that a safety bolt is used through all
ceiling mounts and pole joiners.
1
2
BT7824
EXTERNAL POLE
JOINER
BT7823
INTERNAL POLE
JOINER
When drilling new holes always ensure they
are diametrically opposite each other so that
the bolt can pass straight through.
O10.5mm
20mm
Safety bolt hole
size and location
Optional Pole Joiners
No
PART NAME QTY
1 Ø50mm (2”) POLE : LENGTH 0.25m (9.8”) 1
2 POLE END RING (BT7057) 1
