Seite 1/7
Analogue Montior HD
User manual
Table of contents
Important Safety Information 2
In The Box 4
Connections 4
Rear Interface 4
Control Layout 5
How to Connect Your Monitor 5
On-Screen Display (OSD) Operation 6
HDA1/2 Input Conguration 7
HDMI Input Conguration 8
HDA/HDMI Support list 9
Manufacturer reserves the right to upgrade the
product without notice.
IMPORTANT SAFETY INFORMATION
ENVIRONMENT
• Do not install the monitor outdoors or in any extreme environments.
• To prevent re or electric shock, do not expose the monitor to rain or
moisture. Avoid placing the monitor in areas subject to extreme
temperatures such as direct sunlight or near heating
appliances/equipment (such as ampliers, etc) as this may result in
overheating and damage.
• This monitor is designed to be used in an ofce or at home. Do not
subject it to vibration, dust or corrosive gases.
• To obtain a clear picture, do not expose the screen to direct illumination
or sunlight. Using the monitor against a bright background or where
sunlight and other light sources can shine directly on to the monitor can
increase eye strain.
POWER CORD
• Neither the monitor nor any other heavy objects should rest on the
power cord.
• Protect the power cord from being walked on or pinched.
• Firmly grasp the plug when disconnecting the power cord. Do not pull
the power cord itself.
• Do not modify or damage the cord. Damage to a power cord can cause
re or electric shock.
• This monitor is designed to operate on a 100-240V AC supply. Take
caution in connecting it to the correct supply using the correct power
cord.
MOUNTING
• Always place the monitor on a secure table or have it properly mounted
to the wall. Do not hang anything on the monitor.
• Ensure the monitor is located close to a power outlet that is easily
accessible, as removing the power cord is the only way to isolate power.
1.
2.
USING A WALL MOUNT
Caution: Any wall mount must bear a minimum of 5x the monitor’s net weight
to mount safely. The stand must be removed rst before mounting this way.
1. Place the monitor face down on a surface that is soft, yet strong
enough to hold the monitor.
2. Use a screwdriver to remove the screws from the four holes on each
side of the bottom of the monitor’s base.
3. Make sure all cables are already connected to the monitor.
4. Follow the directions included with the wall mount to x the monitor to
the wall.
STORAGE
• Unplug the monitor if it will not be used for a long period.
VENTILATION
• Never cover or block the ventilation slots in the monitor. A minimum
distance of at least 10 cm should be maintained around the unit for
sucient ventilation.
• Never insert any foreign object, metal or liquid into the ventilation slots,
as this could result in re or electric shock.
• Avoid installing a DVR or other equipment too close to the
monitor. Keep such equipment at least 30 cm away from the monitor.
WATER AND MOISTURE
• The monitor should not be exposed to any moisture or liquid.
• Do not use the monitor near water.
• Do not touch the monitor or cable with wet hands as this may cause
electric shock or damage.
CLEANING
• Unplug the unit from the wall outlet before cleaning.
• Do not use liquid or aerosol cleaners. Use a dry soft lint-free cloth for
cleaning. If dust is persistent, wipe with a slightly damp cloth.
IN THE BOX
1 x LCD Monitor, 1 x AC adapter, 1 x HDMI cable, 1 x User Manual
1 x Remote control optional （ ）
CONNECTIONS
Rear Interface
DC: Only use the 12v DC power supply included with the monitor.
HDMI: High-Denition Multimedia Interface connections.
HD Analogue 1 IN: BNC connections support /CVI/TVI/AHD.CVBS
HD Analogue 1 OUT: Video loop though output.
HDA1 Does not support coaxial control protocol.
HD Analogue 2 IN: BNC connections support CVBS/CVI/TVI/AHD.
HD Analogue 2 OUT: Video loop though output.
HDA2 Support for coaxial control protocol.
3.
4.
