METRA. The World’s best kits.™ metraonline.com1-800-221-0932 © COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
Installation Instructions for AX-ADXSVI
REV. 1/8/2014 INSTAX-ADXSVI
(continued on other side)
AX-ADXSVI
APPLICATIONS
Interface must be used in conjunction with one of the following harness:
I A CNTERF CE OMPONENTS
• AX-ADXSVI interface
TOOLS REQUIRED
• Cutting tool • Tape • Crimping tool
• Connectors (i.e. butt-connectors, bell caps, etc.)
KIT TURESFEA
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems or when replacing amplified systems
• Provides NAV outputs (parking brake, reverse, mute, and V.S.S.)
• Prewired ASWC-1 harness included (ASWC-1 sold separately)
• Retains 3.5mm AUX jack (Fiat and Ram)
• Retains back-up camera, if through the OE radio (Ram)
• High level speaker input
• USB updatable
(a) AX-ADXSVI-CH1
(d) AX-ADXSVI-FD1
(g) AX-ADXSVI-GM1
(j) AX-ADXSVI-GM4
(m) AX-ADXSVI-SP1
(b) AX-ADXSVI-CH2
(e) AX-ADXSVI-FD2
(h) AX-ADXSVI-GM2
(k) AX-ADXSVI-MB1
(n) AX-ADXSVI-SP2
(c) AX-ADXSVI-CH3
(f) AX-ADXSVI-FT1
(i) AX-ADXSVI-GM3
(l) AX-ADXSVI-MB2
(o) AX-ADXSVI-VW1
Note: Applications are noted with characters to indicate which harness needs to be used.
* Indicates chimes will be lost when using this harness.
† Indicates non-navigation models only.
Δ Indicates applications that can be used in non-amplified or amplified systems (excluding
Fender audio systems in VW).
(A)
CHRYSLER
300 ............................... 2005-2007
Aspen .................................... 2007
PT Cruiser ..................... 2006-2010
DODGE
Caliber .......................... 2007-2008
Charger ......................... 2006-2007
Dakota .......................... 2005-2007
Durango ........................ 2004-2007
Magnum........................ 2005-2007
Ram 1500 ..................... 2006-2008
Ram 2500/3500 ............ 2006-2009
JEEP
Commander .................. 2006-2007
Compass ....................... 2007-2008
Grand Cherokee ............. 2005-2007
Patriot ........................... 2007-2008
MITSU ISB HI
Raider ........................... 2006-2007
(B)
CHRYSLER
200 ................................... 2011-up
300 ............................... 2008-2010
Aspen ........................... 2008-2009
Sebring ......................... 2007-2010
Town & Country ................. 2008-up
DODGE
Avenger ............................ 2008-up
Caliber .......................... 2009-2012
Challenger ......................... 2008-up
Charger ......................... 2008-2010
Dakota .......................... 2008-2011
Durango ............................ 2008-up
Grand Caravan................... 2008-up
Journey ......................... 2009-2010
Magnum........................ 2008-2009
Nitro ............................. 2007-2011
Ram 1500 ..................... 2009-2011
Ram 2500/3500 ............ 2010-2011
Ram Chassis Cab
3500/4500/5500 .................... 2011
JEEP
Commander .................. 2008-2010
Compass ........................... 2009-up
Grand Cherokee ............. 2008-2013
Liberty .......................... 2008-2012
Patriot ............................... 2009-up
Wrangler ........................... 2007-up
MITSU ISB HI
Raider ........................... 2008-2009
RAM
1500/2500/3500 .................... 2012
Chassis Cab
3500/4500/5500 .................... 2012
C/V Tradesman .................. 2012-up
V KSOL WAGEN
Routan .............................. 2009-up
(C)
DODGE
Dart ....... 2013-up(small screen option)
FIAT
500L ..............................2014-up Δ
RAM
1500, 2500, 3500 .............. 2013-up
(small screen option)
Chassis Cab
3500, 4500, 5500 .............. 2013-up
(small screen option)
(D)
FORD
Edge ............................. 2007-2010
Escape .......................... 2008-2012
Expedition ......................... 2007-up
Flex .............................. 2008-2012
Focus ............................ 2008-2011
Fusion ........................... 2010-2012
F-150 ............................ 2009-2012
F15 STX/FX2 base/XLT base .... 2013
F150 STX/XLT base ................. 2014
F250/350/450/550 ............ 2008-up
Mustang ............................ 2009-up
Taurus ........................... 2010-2012
LINCOLN
MKX .............................. 2007-2010
MKZ .............................. 2007-2009
Navigator .......................... 2007-up
(only to be used when replacing an
amplified system)
Mazda
Tribute .......................... 2008-2011
Mercury
Mariner ......................... 2008-2011
Milan ............................ 2010-2011
(E)
FORD
Edge (4.2” screen) ................ 2011-up
Explorer (4.2” screen) ........... 2011-up
F-150 (4.2” screen) .............. 2013-up
Fiesta ................................ 2011-up
(without MyFord Touch, with SYNC)
Focus ................................ 2012-up
(without MyFord Touch, with SYNC)
(F)
FIAT
500 ................................2012-up Δ
(G)
B KUIC
Enclave ............................2008-up*
Lucerne........................2006-2011*
CA ACDILL
Escalade ......................2007-2011*
(only to be used when replacing an
amplified system)
DTS .............................2006-2011*
(only to be used when replacing an
amplified system)
AX-ADXSVI
METRA. The World’s best kits.™metraonline.com1-800-221-0932 © COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
K PNOWLEDGE IS OWER
Enhance your inst allation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a better t omorrow.
Metra recommends MECP
certified technicians
IMPORTANT RNING WA
This product includes instructions for installation which must be carefully followed. The instructions are
worded in such a manner to assume that the installer is capable of completing these type of electronic
installations. If you are unclear as to what you are instructed to do or believe that you do not understand the
instructions so as to properly and safely complete the installation you should consult a technician who does
have this knowledge and understanding.
Failure to follow these instructions carefully and to install the interface as described could cause
harm to the vehicle or to safety systems on the vehicle. Interference with certain safety systems
could cause harm to persons as well. If you have any questions in this regard please call the Help
line or Metra at 1-800-221-0932 for assistance.
SRX .............................. 2007-2009*
(only to be used when replacing an
amplified system)
CHEVROLET
Avalanche ........................2007-up*†
Captiva Sport .....................2012-up*
Cheyenne ........................2012-up *†
Equinox ......................... 2007-2009*
Express ............................2008-up*†
Impala .......................... 2006-2013*
Impala Limited ........................2014*
Monte Carlo .................. 2006-2007*
Silverado (new body) ......... 2007-13*†
Silverado 2500/3500 ............ 2014 *†
Suburban .....................2007-2014*†
Tahoe ...........................2007-2014*†
Traverse .............................2009-up*
GMC
Acadia ...............................2007-up*
Savanna ...........................2008-up*†
Sierra (new body) .............. 2007-13*†
Sierra 2500/3500 ..................2014*†
Yukon/XL ......................2007-2014*†
HUMMER
H2 ................................ 2008-2009*
(only to be used when replacing an
amplified system)
PONTIAC
Torrent .......................... 2007-2009*
SATURN
Outlook ......................... 2007-2010*
Vue ............................... 2008-2010*
SUZUKI
XL-7 ............................. 2007-2009*
(H)
CHEVROLET
Cobalt ............................. 2007-2010
HHR .............................. 2006-2011*
Malibu .......................... 2008-2012*
PONTIAC
G5 ................................ 2007-2008*
G6 ................................ 2010-2010*
G6 ................................ 2009-2009*
(5th digit must be a J, K, or L)
Solstice ......................... 2006-2009*
SATURN
Aura .............................. 2007-2009*
Sky ............................... 2006-2009*
(I)
B KUIC
Allure ............................ 2005-2009*
Century ......................... 2004-2005*
Lacrosse ....................... 2005-2009*
Rainier .......................... 2004-2007*
Regal ......................................2004*
Rendezvous .................. 2002-2007*
Terraza ......................... 2005-2008*
CA ACDILL
Escalade ....................... 2003-2006*
(only to be used when replacing an
amplified system)
Escalade ESV & EXT ...... 2003-2006*
(only to be used when replacing an
amplified system)
CHEVROLET
Avalanche ..................... 2003-2006*
C4500-C8500 Kodiak .... 2005-2009*
Cavalier ........................ 2000-2005*
Colorado ....................... 2004-2012*
Corvette ........................ 2005-2013*
(only to be used when replacing an
amplified system)
Express ......................... 2003-2007*
Impala .......................... 2000-2005*
Malibu .......................... 2001-2003*
Malibu (classic) ............... 2004-2005*
Monte Carlo .................. 2000-2005*
Silverado pickup (classic) ..........2007*
Silverado pickup ........... 2003-2006*
SSR .............................. 2003-2006*
Suburban ...................... 2003-2006*
Tahoe ............................ 2003-2006*
Trailblazer ..................... 2002-2009*
Uplander ....................... 2005-2008*
Venture ...........................2000-2005
GMC
Canyon ......................... 2004-2012*
C4500-C8500 Top Kick .. 2005-2009*
Envoy ............................ 2002-2009*
Savanna ........................ 2003-2007*
Sierra ............................ 2003-2006*
Yukon/Yukon XL............. 2003-2006*
HUMMER
H2 ................................ 2003-2007*
(only to be used when replacing an
amplified system)
H3/H3t .......................... 2006-2010*
I ZUSU
Ascender ...................... 2003-2008*
H-Series........................ 2003-2008*
l-Series pickups ............ 2006-2008*
O BLDSMO ILE
Alero ............................. 2001-2004*
Bravada ........................ 2002-2004*
Intrigue ...................................2002*
Silhouette .......................2000-2004
P ACONTI
Aztec ............................ 2001-2005*
Grand Am ...................... 2001-2005*
Grand Prix ..................... 2004-2008*
Montana SV6................. 2005-2008*
Montana .........................2000-2005
Sunfire .......................... 2000-2005*
SAAB
9-7X ............................. 2005-2009*
SATURN
Relay ............................ 2005-2007*
(J)
CHEVROLET
Cobalt ......................... 2005-2006 Δ
Equinox ......................... 2005-2006*
Malibu/Malibu Maxx .... 2004-2007 Δ
(except Classic)
Malibu Classic .......................2008 Δ
PONTIAC
G6 .............................. 2005-2008 Δ
G6 ........................................2009 Δ
(5th digit must be an A, G, H, or M)
Torrent ....................................2006*
(K)
MERCEDES
C Class ...........................2001-2004
CLK Class ................................ 2004
CLK500 .................................... 2003
CLK55 AMG .............................. 2003
(L)
MERCEDES
C Class ...........................2005-2011
CLK Class .......................2005-2009
SLK Class........................2005-2001
G Class ...........................2007-2012
E Class................................2010-up
GLK.................................2010-2012
R Class ...........................2006-2011
(M)
D GEOD
Sprinter.................................... 2007
Sprinter (sound 5 radio) ...... 2008-2009
MERCEDES
Sprinter (sound 5 radio) ...... 2010-2013
FREIGHTLINER
Sprinter.................................... 2007
Sprinter (sound 5 radio) ......2008-2013
(N)
D GEOD
Sprinter ....2008-2009(sound 20 radio)
MERCEDES
Sprinter (sound 20 radio) .... 2010-2013
Sprinter.................................... 2014
FREIGHTLINER
Sprinter (sound 20 radio) ......2008-2013
Sprinter.................................... 2014
(O)
Volkswagen
Beetle ............................. 2012-up Δ
CC .................................. 2009-up Δ
EOS ................................ 2007-up Δ
Golf .......................................2002 Δ
(with double DIN radio)
Golf ............................. 2003-2006 Δ
Golf/Golf R ...................... 2010-up Δ
GLI .................................. 2008-up Δ
GTI .................................. 2002-up Δ
Jetta .....................................2002 Δ
(with double DIN radio)
Jetta .............................. 2003-up Δ
Jetta GLI ........................ 2008-up Δ
Jetta Sportwagen ............ 2010-up Δ
Passat ............................ 2002-up Δ
R32 ............................ 2007-2008 Δ
Rabbit ........................ 2007-2009 Δ
Tiguan ........................... 2009-up Δ

Produktspezifikationen

Marke: Axxess
Kategorie: Nicht kategorisiert
Modell: AX-ADXSVI

Brauchst du Hilfe?

Wenn Sie Hilfe mit Axxess AX-ADXSVI benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Nicht kategorisiert Axxess

Axxess

Axxess AX-MLOC-HD1 Bedienungsanleitung

12 September 2024
Axxess

Axxess AFSI-01 Bedienungsanleitung

30 August 2024
Axxess

Axxess AX-TOYCAM3 Bedienungsanleitung

30 August 2024
Axxess

Axxess AX-MITSUCAM Bedienungsanleitung

30 August 2024
Axxess

Axxess AX-TOYRSAV Bedienungsanleitung

30 August 2024
Axxess

Axxess HDCC-02 Bedienungsanleitung

30 August 2024
Axxess

Axxess AX-TOYCAM2 Bedienungsanleitung

30 August 2024
Axxess

Axxess AX-ADBOX1 Bedienungsanleitung

30 August 2024
Axxess

Axxess CHRYSAV Bedienungsanleitung

30 August 2024
Axxess

Axxess 70-8215AMP Bedienungsanleitung

30 August 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

DAS Audio

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024
Ferplast

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024
AEG

AEG MECK52 Bedienungsanleitung

16 Oktober 2024
Makita

Makita UR012G Bedienungsanleitung

16 Oktober 2024
Stihl

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024
Ernesto

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024
IFM

IFM AC901S Bedienungsanleitung

16 Oktober 2024
Nedis

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024
AEG

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024
ART

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
