Subwoofer Owner’s Manual:
SubCompactTM 6, SubCompactTM 8, SubCompactTM 10
SubSonicTM, Baby BoomerTM, S-Fit Cnr Sub 300 TM, CS 66TM, CS 88TM
Baby Boomer PlusTM, Sonic 500TM
Digital SubTM 600, SuperSonicTM & UltraSonicTM
 2008 PINNACLE LOUDSPEAKERS
1
2
We congratulate and thank you for choosing a PINNACLE ® subwoofer. Our subwoofers exemplify the
best in modern audio technology, and are designed to produce tremendous amounts of deep bass. Please
read this manual completely to ensure the best possible performance from your Home Theater or sound
system.
SOLID BRASS ISOLATION CONES:
If your subwoofer comes with solid brass isolation cones, please make sure to install them into the
bottom of your subwoofer cabinet. They are an important part of the performance of the product and will
improve the bass definition.
With the cabinet on its side, simply screw the cones into their receptacles on the bottom of the
cabinet. Then, with the cabinet upright, adjust the cones individually as needed to level the cabinet. When the
cones have been adjusted to the proper height, screw each nut up the threaded shaft flush with the bottom of
the cabinet to secure the height setting. If you intend to place your subwoofer on wooden or vinyl floors, we
suggest placing a penny under each cone to prevent any indentations.
PLACEMENT:
Recommended Subwoofer Placement:
a) within a few inches of the room corner closest to your left or right front speaker (maximum low bass
output);
b) against the wall between your left and right front speakers (strong low bass output with optimal
blending to front speakers);
c) near any other room corner or wall.
Other locations will provide varying degrees of low bass impact and blending with your front speakers.
We recommend listening to your system, with the subwoofer in different room positions, to obtain a location
with an optimum response.
A Special Note to SubSonic T M
, Baby BoomerT M, Baby Boomer PlusT M
& UltraSonicT M
owners: Due to the
bipole configuration of your subwoofer be sure to leave at least an inch or two between the rear woofer and
your wall.
If you must place your subwoofer near baseboard heaters or forced hot air vents try to leave at least 4”
of clearance for proper ventilation. Do not place your subwoofer outdoors, or in any wet or excessively damp
environment.
Note: Because of your subwoofer’s powerful magnet, be sure to place your subwoofer far enough
away from your TV (approximately 2-3 feet) to avoid color distortion and any other anomalies in the picture. If
you experience picture distortion, simply move the subwoofer away from the TV until the picture becomes
distortion free. We also recommend keeping magnetic media such as audio/videotapes and computer disks
