INSTRUCTION BOOK
L1000
User Guide
1 9
Package
Contents
Components may be changed without prior notice to improve the performance
or quality of the product.
L1000
P er Cord &Adapter: ow Connect to the product and wall outlet to supply power.
Micro-USB Cable: Use to connect to a computer or compatible music source.
User Guide: Overview of product functionality.
Warranty: Please keep the product warranty in case warranty service is needed.
AdapterPower Cord
Micro-USB Cable User Guide
& Warranty
ENGLISH
2 1
Power
Cable
Manage-
ment
1. Connect the adapter to power cord.
2. Connect the adapter cable to [Power] on the back of the product.
3. Connect to power plug and press [Power].
4. When volume and filter LED lights are on, the product is booted.
5. Long-press (4 seconds) the [Power] button to turn the device OFF when it is turned on.
Be sure to only use an officially-certified 12V 5A adapter.
Using an adapter with specifications lower than 12V 5A may damage the product.
After connecting the adapter and power cord to the product, insert the power plug into an
available outlet.
To avoid malfunction or damage to the device, only use the power cord and the adapter supplied
with the product.
Unplug the power supply from the outlet when the device is not in use for an extended period.
Be sure to check nearby outlets and use the proper power plug.
Power ON/OFF
2 0
Descrip-
tion of
Each
Part
The appearance of the product as well as the
printed and engraved information may vary
depending on the model.
1
2
3
4
5
6
7
8
9
10
11
12
Filter LED
Volume LED
Volume Wheel
Headphone and
Earphone Port
Balanced Audio
Port
Filter button
Power button
XLR Balanced
Port
Speaker Port
Micro USB Port
Speaker switch
Power Port
Indicates the selected filter.
Blue LED-Neutral Filter
Green LED - Bass Sound
Filter
Red LED - Boosted Gain
Filter
Volume level indicator.
Turn the wheel to adjust
sound volume.
Connect earphones and
headphones with 3.5mm/6.3
mm terminal for audio output.
Connect earphones or
headphones with 2.5mm
balanced jack for audio output.
Press to select filters.
Turns power ON/OFF.
Connect earphones or
headphones with 4-pin XLR
balanced jack for audio output.
Output sound by connecting
the product to speakers.
Transmit data by connecting
the product to a computer or
music source device.
Turn ON/OFF the output
function of a connected
speaker.
Connect power adapter.
Balanced
Audio Pin Map
R- R+ L+ L-
1
8
9
10
2
3
11
4 5 6 7
12
