Seite 1/3
1. Read all instructions before using this heater.
2. This heater is hot when in use.
To avoid burns, do not let bare skin touch hot
surfaces.
Use handles when moving this heater.
Keep combustible material such as drapery
and other furnishings, at least 1 metre from
the heater.
When in use keep the mains cord of the heater
away from touching the heater body. Do not
drape the cord over the heater while hot.
Extreme caution is necessary when any
heater is used by or near children or invalids
and whenever the heater is left operating
unattended.
3. Always unplug heater when not in use.
4. Do not operate any heater with a damaged
cord or plug or after the heater malfunctions,
has been dropped or damaged in any manner.
Return heater to suitably qualified facility
for examination, electrical or mechanical
adjustment or repair.
5. Do not use outdoors, the product is designed
only for household use.
6. Never locate heater where it may fall into a
bathtub or other water container.
7. Do not run cord under carpeting.
Do not cover cord with throw rugs runners, or
the like. Keep cord away from traf fic areas to
avoid tripping over.
8. To disconnect heater, turn controls to off, then
remove plug from outlet.
9. Connect to properly earthed socket-outlet of
the appropriate voltage.
10. Do not insert or allow foreign objects to enter
any ventilation or exhaust opening as this may
cause an electric shock or fire, or damage the
heater.
11. To prevent a possible fire, do not block the
grilles in any manner.
12. Do not use in areas where petrol, paint, or
flammable liquids are used or stored.
13. Use the heater only as described in this
manual. Any other use not recommended by
the manufacturer may cause fire, electric
shock, or injury.
14. Do not connect via double adapters or power
boards. Avoid the use of an extension cord
because the extension cord may overheat
and cause risk of fire. However, if this heater
is used with an extension cord, use as short
a cord as practical.
15. Do not use this appliance with a programmer,
timer or any other device that switches
the heater on automatically, since a fire
risk exists if the appliance is covered or
positioned incorrectly.
16. In order to avoid overheating, do not cover
the heater.
17. To eliminate a choking hazard for young
children, remove and safely discard the
protective cover fitted to the power plug of
this heater along with all packaging material
and promotional labels.
18. Fully unwind the cord before first time use
19. There are no user serviceable parts in this
heater; any maintenance other than cleaning
should be performed by an authorised service
representative.
20. The installation of a residual current device
(safety switch) is recommended to provide
additional safety protection using electrical
appliances. It is advisable that a safety switch
with a rated residual operating current not
exceeding 30mA be installed in the electrical
circuit supplying power to the appliance. See
your electrician for professional advice.
21. Keep these instructions handy for future
reference.
CPIN002296/3
2000W
convection HeAteR
WITH TImer and Turbo fan
Luxor
User ManUal
FOR PERSONAL INDOOR USE ONLY
CH206
WARNING!
To Reduce The RIsk of fIRe, elecTRIc shock,
oR peRsoNAl INjuRy, ReAd, uNdeRsTANd
ANd folloW INsTRucTIoNs befoRe
usING ThIs heATeR
Keep this manual in a safe place for future reference
CPIN002296/3
Model ceh206
Max Heating Power 2000W max
Rated Frequency 50hz
Rated Voltage 220-240V ~
TechNIcAl specIfIcATIoNs
For all Sales & Warranty enquiries
Arlec Australia Pty. Ltd. ACN 009 322 105
(“Arlec”) gives the Warranty.
Building 3, 31 – 41 Joseph Street, Blackburn North, Victoria, 3130
Blackburn North LPO, P.O. Box 1065, Blackburn North, 3130
Customer Service: (03) 9982 5111
New Zealand Toll Free: 0800 003 329
Email: custservice@arlec.com.au
Arlec guarantees this product in accordance with the Australian
Consumer Law.
Arlec also warrants to the original first purchaser of this product
(“you”) from a retailer that this product will be free of defects
in materials and workmanship for a period of 12 months from
the date of purchase; provided the product is not used other
than for the purpose, or in a manner not within the scope of the
recommendations and limitations, specified by Arlec, is new and
not damaged at the time of purchase, has not been subjected
to abuse, misuse, neglect or damage, has not been modified or
repaired without the approval of Arlec and has not been used for
commercial purposes (“Warranty”).
If you wish to claim on the Warranty, you must, at your own
expense, return the product, and provide proof of original purchase
and your name, address and telephone number, to Arlec at the
address below or the retailer from whom you originally purchased
the product within 12 months from the date of purchase.
Arlec will (or authorise the retailer to) assess any claim you may
make on the Warranty in the above manner and if, in Arlec’s
reasonable opinion, the Warranty applies, Arlec will at its own
option and expense (or authorise the retailer to) replace the
product with the same or similar product or repair the product and
return it to you or refund the price you paid for the product. Arlec
will bear its own expenses of doing those things, and you must bear
any other expenses of claiming on the Warranty.
The Warranty is in addition to other rights and remedies you may
have under a law in relation to the product to which the Warranty
relates.
Our goods come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major
failure.
WARRANTy
IMpoRTANT sAfeGuARds
CH206_CPIN002296-3.indd 5-1 8/11/13 3:55 PM
IDENTIFICATION
2
USER MANUAL
i. POWER CONTROL KNOB
With the power control knob to position “o” the heating element is off. When the rotary
knob is set to • the heater power is 750W (low range). When the knob is set to •• the heater
power is 1250 (mid range). When the knob is set to ••• the heater power is 2000 (high range)
ii. TURBO FAN SWITCH
The heater is equipped with a Fan which helps to distribute heat in the room. The fan draws
some of the convection heat from inside of the unit and blows it from the front turbo fan
outlet grille. The heater can be used with or without the fan which is selected by the switch
on the front of the heater body.
iii. THERMOSTAT SWITCH
The rotary knob is to regulate the heat in order to maintain a desired temperature. When
the room temperature is lower than the temperature setting on the knob, the heater will
function and heat up the room until the desire temperature is at tained. When the ambient
temperature reaches the set temperature, heat setting will be turned off automatically.
Turn the knob more clockwise for higher heat settings.
iv. TIMER CONTROL
The heater will be always On when the slide switch is in “On” position (I).
The heater will be always off when the slide switch is in “Off” position (O).
The heater will be controlled by the times set on the timer when the slide switch is
in TIMER position
To set the timer, rotate the clock dial clockwise, until the current time is aligned with
the indicator arrow at the centre. When you wish the heater to switch ON, push the
corresponding time segment outwards from the centre. Each segment represents
around 15 minutes. For example, if you want the heater continuously ON for 2 hours,
push 8 segments outwards the centre face.
CPIN002296/3
The heater must always be used with feet assembled and in
upright position. At tach the feet to the heater body in the order
given below:
i. Place the convector heater on a flat desk or carton.
ii. Locate the feet in position, make sure the mounting holes
on the leg mounts align with the fixing holes on the heater
body. Make sure the leg mount with the cord entry slot is
attached at the mains cord end.
iii. Using 4 screws for each feet attachment secured the feet
to the heater body.
ASSEMBLY
1
Fasten feet with
supplied screws
2000W
convection
HeAteR
WITH TImer and Turbo fan
› ‹Luxor
CH206 Convection Heater with Turbo Fan is equipped with three heat set tings and a thermostat
to ensure your precise heating needs are met. In addition the heater has a fan turbo option
which assists with circulating warm air through your room
Hot Air Outlet
Timer
Control
Turbo Fan Switch
Turbo Fan
Air Outlet FeetAir Inlet
Power Control
Knob
Thermostat
Knob
MAINTENANCE & CLEANING
4
i. Before cleaning, turn off the heater, unplug the power cord and allow the
heater to cool.
ii. Do not immerse cord, plug or heater into water or other liquid or pour water
or other liquid over the heater.
iii. Use a vacuum cleaner to remove dust and dirt from air openings.
iv. Clean exterior surfaces using a solution of water and mild detergent with wrung out
damp sponge. Use and wring out the damp sponge and wipe the exterior surface again.
Finally wipe with a dry cloth. Allow sufficient time to dry before plugging electrical cord
into outlet.
v. Any other servicing should be performed by an authorized service representative.
Do not use the heater if it has malfunctioned or become damaged in any way.
OPERATION
3
OPERATION
CAUTION: There may be some odour coming from the heater for the very first time you use this
heater. This is normal during the break-in period or after long term storage. Make sure the heater
is in well ventilated area and continue running it until the smell goes away.
Before First Use
Remove all the packaging material along with any promotional material. Unwind the cord to its
full length and place the heater on a firm level surface in a stable, upright position.
Visually inspect p2-he air inlets and outlets to ensure that there are no blockages.
• Set the power control knobs to off position.
• Plug the heater into a 10 amp wall socket
• Ensure the heater is on a flat surface
• Set the power to desired position Low, Medium or High range. Check the time setting and
adjust it to the desired time setting. Turn the thermostat knob until the heater turns on .The
power on led above the knob will glow. Slowly turn the thermostat knob anti clockwise until
the heater shuts off. The heater will automatically maintain this temperature. For a lower
temperature rotate the knob further anti clockwise. For higher temperature, rotate the knob
clockwise.
• Select the fan as desired.
NOTE: If operated at the Low heat setting, the heater will not provide as much heat output
as in the High heat setting, however the low setting will not require as much electrical
power to operate. To avoid overloading a circuit, do not plug the heater into a circuit that
already has other appliances working. When the heater is not in use switch off and unplug.
IMPORTANT SAFEGUARDS
5
CAUTION
• This heater is to be operated only in upright position.
• When the heater is not in use, store in a cool dry location.
• Do not store until the heater cools down.
WARNING
• This appliance is not intended for use by young children or infirm persons unless
they have been adequately supervised by a responsible person to ensure that
they can use the appliance safely.
• Young Children should be supervised to ensure that they do not play
with the appliance.
• The heater must not be located in front of a socket outlet.
• Do not use this heater in the immediate surroundings of a bath, shower
or swimming pool.
HELPFUL ADVISE BERFORE USE
• Please retain all packaging until you have checked and counted all the parts and the
contents of the fixing pack against the parts list.
• The fixing pack contains small items which should be kept away from young children.
• We suggest that you open the fixing pack and place all the contents into a container,
therefore reducing the risk of losing any small pieces.
CH206_CPIN002296-3.indd 2-4 8/11/13 3:55 PM

Produktspezifikationen

Marke: Arlec
Kategorie: Heizung
Modell: Luxor CH206

Brauchst du Hilfe?

Wenn Sie Hilfe mit Arlec Luxor CH206 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Heizung Arlec

Arlec

Arlec Luxor CH206 Bedienungsanleitung

24 August 2024

Bedienungsanleitung Heizung

Neueste Bedienungsanleitung für -Kategorien-

Harvia

Harvia Delta D29EE HDEE290400 Bedienungsanleitung

16 Oktober 2024
MSW

MSW -CTEH-15000 Bedienungsanleitung

16 Oktober 2024
Uniprodo

Uniprodo UNI_HEATER_05 Bedienungsanleitung

16 Oktober 2024
Uniprodo

Uniprodo UNI_HEATER_06 Bedienungsanleitung

16 Oktober 2024
MSW

MSW -TTEH-2000 Bedienungsanleitung

16 Oktober 2024
Uniprodo

Uniprodo UNI_HEATER_04 Bedienungsanleitung

16 Oktober 2024
Uniprodo

Uniprodo UNI_HEATER_07 Bedienungsanleitung

16 Oktober 2024
Jøtul

Jøtul F 361 Bedienungsanleitung

15 Oktober 2024
Adler

Adler AD 7752 Bedienungsanleitung

15 Oktober 2024
MSW

MSW -TTEH-3000 Bedienungsanleitung

15 Oktober 2024
