TT111
| Sun Visor Mount for TomTom GPS
!Safety Precautions
It is your responsibility to place, secure, and use your device in a
manner that will not cause accidents, personal injury, or property
damage, or obstruct the driver’s view of the road. Do not operate
device while driving. Always observe safe driving practices.
Do not install in an air bag deployment zone. Arkon Resources,
Inc. is not responsible for any damages caused to your car, your
device, or yourself due to the use of this mounting accessory.
The Mobile Mounting Specialistsâ„¢
Consumer Hotline:
USA (800) 841-0884
INT’L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
Visor mount for holding GPS device in convenient location. Place, secure, and
use your device in a manner that does not obstruct the driver’s view of the road.
Do not operate device while driving. Always observe safe driving practices.
!
Step 1. Slide the adapter plate up into the grooves on the back
of the TomTom ONE, ONE XL, or ONE XL • S.
TomTom ONE, ONE XL, and ONE XL • S Adapter Plate Installation
TomTom GO Adapter Plate Installation
TomTom Start Adapter Plate Installation
Sun Visor Mounting
Lower the vehicle sun visor and place the clip mount over
the top of the visor. Slide the mount left or right to adjust
the location on the visor.
Step 1.
Step 1. Attach the adapter plate by sliding it up into the slot on the
back of the TomTom GO 520, 530, 630, 720, 730, 920, 920T
or 930 device as shown. Attach the device as shown to the
right.
Step 1. Attach the device cradle to the visor pedestal by inserting
the dual T-Tabs of the pedestal (A) into the T-slots of the
adapter plate (B).
TomTom Device Attachment
A
B
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2010 Arkon Resources, Inc.
CM01
CM01
CM01
CM011
1
1
1-
-
-
-2
2
2
2CM011-2
Sun v
Sun v
Sun v
Sun visor
isor
isor
isor Sun visor
mou
mou
mou
mount
nt
nt
ntmount
A
B
Attach the TomTom dual-T adapter plate to the mount by
inserting the dual-T tabs of the pedestal (A) into the dual
T-slots on the adapter plate (B).
Step 1.
APTTO
Adapter plate for
TomTom ONE
APTTOXL
Adapter plate for
TomTom ONE XL
and XL • S
APTTGO520
Adapter plate for
TomTom GO x20, x30
Check Compatibility
Check Compatibility
Check Compatibility
Check Compatibility
Check Compatibility
APTTEP
Adapter Plate for
TomTom EasyPortâ„¢
APTTSE
Adapter Plate for
TomTom Startâ„¢ and Easeâ„¢
Package Contents:
(1) CM011-2 Sun visor mount
(1) APTTO - Adapter plate for TomTom ONEâ„¢ Series
(1) APTTOXL - Adapter plate for TomTom ONE XL / XL • S™ Series
(1) APTTGO520 - Adapter plate for TomTom GOâ„¢ Series
(1) APTTEP - Adapter plate for TomTom EasyPortâ„¢ Series
(1) APTTSE - Adapter plate for TomTom Startâ„¢ and Easeâ„¢
TomTom, ONE, GO, and EasyPort, Start and Ease are product names, trademarks, or registered
trademarks of TomTom International b.v. Arkon Resources, Inc. is not affi liated with TomTom
International b.v.
TomTom Device Compatibility:
TomTom ONE 125 125-SE (TomTom EasyPort Mount)
TomTom ONE 130, ONE 130-S (TomTom EasyPort Mount)
TomTom ONE 140, ONE 140-S (TomTom EasyPort Mount)
TomTom XL 325, XL 325-S, XL 325-SE (TomTom EasyPort Mount)
TomTom XL 330, XL 330-S (TomTom EasyPort Mount)
TomTom XL 335 Series (TomTom EasyPort Mount)
TomTom XL 340, XL 340-S, XL 340 LIVE Series (TomTom EasyPort Mount)
TomTom XL 350 Series (TomTom EasyPort Mount)
TomTom XXL 530-S, XXL 535-T, XXL 540-S/WTE, XXL 550 Series (TomTom EasyPort Mount)
TomTom ONE (US Edition, US 3rd Edition)
TomTom ONE XL (1st Edition) - TomTom ONE XL-S (1st Edition)
TomTom ONE 22, ONE 22 Regional, ONE 22 Regional Traffi c
TomTom XL 22, XL 22 Regional (TomTom EasyPort Mount)
TomTom ONE UK / EUROPE (NEW Edition aka 2nd Edition, 3rd Edition)
TomTom GO 520 / 530 / 630 / 720 / 730 / 920 / 920T / 930
TomTom Start and Ease
Patented & Patents Pending
While holding the mounted TomTom adapter plate, gently
insert the TomTom device (not included, sold separately)
into the adapter plate until an audible click is heard.
Step 2.
TT111
| Sun Visor Mount for TomTom GPS
!Safety Precautions
It is your responsibility to place, secure, and use your device in a
manner that will not cause accidents, personal injury, or property
damage, or obstruct the driver’s view of the road. Do not operate
device while driving. Always observe safe driving practices.
Do not install in an air bag deployment zone. Arkon Resources,
Inc. is not responsible for any damages caused to your car, your
device, or yourself due to the use of this mounting accessory.
The Mobile Mounting Specialistsâ„¢
Consumer Hotline:
USA (800) 841-0884
INT’L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2010 Arkon Resources, Inc.
Connect the dual T-slots (C) on the adapter plate to the dual
T-tabs (D) on the sun visor mount.
Step 1.
Step 1. Insert your TomTom device into the adapter plate.
TomTom EasyPort Adapter Plate Installation
TomTom EasyPort Device Insertion
C
D
