INSTALLATION
AND
OPERATING
INSTRUCTIONS
INTENDED FOR OTHER THAN HOUSEHOLD USE
Model: M Series
Model: AT / BT Series
RETAIN THIS MANUAL FOR FUTURE REFERENCE
UNIT MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES
P/N 57212 9/06
1
DIAGONAL CONTACT CONVEYOR TOASTER
HORIZONTAL RADIANT CONVEYOR TOASTER
APW WYOTT
729 Third Avenue
Dallas, TX 75226
This equipment has been engineered to provide you with year-round dependable service when used
according to the instructions in this manual and standard commercial kitchen practices.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury or death. Read the Installation, Operating and
Maintenance Instructions thoroughly before installing or servicing this equipment. !!
R
TABLE OF CONTENTS
GENERAL INFORMATION AND TROUBLESHOOTING 2
M SERIES - DIAGONAL CONTACT CONVEYOR TOASTERS 3-9
Electrical Specications 3
Installation 3
Location 6
Operating Instructions 6
Field Adjustments & Cleaning 7
Troubleshooting Guide 9
AT SERIES - HORIZONTAL RADIANT CONVEYOR TOASTERS 10-13
Electrical Specications 10
Installation 11
Convertible Instructions 12
Operating Instructions 13
BT-15 SERIES 14-16
Electrical Specications 14
Installation 14
Operating Instructions 15
WARRANTY IN FORMATION 19
GENERAL INFORMATION
General Installation:
1. Always clean equipment thoroughly before rst use. (See general cleaning instructions).
2. Check rating label for your model designation & electrical rating.
3. Locate equipment on level counter and plug into a grounded outlet so that the plug is accessible.
(See individual description for electrical loads).
4. On units bearing the CE marking, the appliance must be connected by an earthing cable to all other
units in the complete installation and then to an independent earth connection.
GENERAL TROUBLESHOOTING
Always ask & check:
1. Is the unit plugged in?
2. Check circuit breaker.
3. Is power switch on and pilot light glowing?
4. Check rating label. Are you operating unit on proper voltage?
5. If the supply cord is damaged it should be replaced by an identical supply cord.
If the above checks out and you still have problems, call an APW Wyott authorized service agency.
2
!
!
WARNING: In Europe, appliance must be connected by an earthing cable to all other units
in the complete installation and thence to an independent earth connection in compliance
with EN 60335-1 and/or local codes
! !
WARNING: An earthing cable must connect the appliance to all other units in the complete
installation and from there to an independent earth connection.
Model Stock Dimensions* Electrical Productivity Weight
Number Number Halves/Hour Net/Ship
83501 120V-1600W-13.3A Up to 1600
M-83 83502 20"H x 24 5/8"W x 12"D 208V-1600W-7.7A “ “ 83/93 Ibs
83504 50.8 cm x 62.6 cm x 30.5 cm 230V-1470W-6.4A-50Hz “ “ 37.7/42.2 kg
240V-1600W-6.7A
84578 120V-1600W-13.3A Up to 1600
M-830 84579 20"H x 24 5/8''W x 12"D 208V-1600W-7.7A “ “ 83/93 Ibs
84590 50.8 cm x 62.6 cm x 30.5 cm 230V-1470W-6.4A-50Hz “ “ 37.7/42.2 kg
240V-1600W-6.7A
M952AA001 120V-1800W-15A
M-95-2 M952CA001 30 1/2"H x 21 1/2"W x 17 1/2"D 208V-2780W-13.4A 681bs.
M952EA001 77.5 cm x 54.7 cm x 44.5 cm 230V-2550W-11.1 A-50Hz 30.9 kg
240V-2780W-11.6A
M953AA001 120V-1800W-15A
M-95-3 M953CA001 30 1/2"H x 24 1/2"W x 17 1/2"D 208V-2780W-13.4A 77lbs.
M953EA001 77.5 cm x 62.3 cm x 44.5 cm 230V-2550W, 11.1 A-50Hz 35 kg
240V-2780W-11.6A
*With Superfeeder: M-83 & M-83D - add 11” (28cm) to height, 4 1/2” (11.5cm) to depth.
M-83, M-83-D & M-91 & M-95
SPECIFICATIONS:
PLEASE READ PAGE 2 - “GENERAL INFORMATION”, BEFORE YOU CONTINUE.
Electrical Information - All Models
Each unit is equipped with a 4 foot (122cm), 3 wire grounded power supply cord which terminates with a 3
prong plug. The 120V units have a NEMA 5-15P plug. The 208/240V units have a NEMA 6-20 plug.
NOTE: Units rated 120V for installation in Canada have a NEMA 5-20P plug.
INSTALLATION
1. UNPACK UNIT
a) Remove unit from shipping carton, unwrap loose parts and remove any packing tape,
plastic wrap and nylon tie-down.
b) Refer to the illustrations below and account for the following parts:
Part M-83 M83-D M-91 M-95
Legs (Item 1) wrapped, internal package wrapped, internal package wrapped, internal package wrapped, internal package
Butter Roller (Item 2) plastic wrapped, shipped in place - plastic wrapped, shipped in place -
Butter Pan (Item 3) plastic wrapped, shipped in place - plastic wrapped, shipped in place -
Conveyor (Item 5) boxed, external package. boxed, external package strapped in place with nylon tie -
Bun Chute Feeder (Item 7) shipped in box with Conveyor shipped in box with Conveyor wrapped, internal package wrapped, internal package
Instruction Manual wrapped, internal package wrapped, internal package wrapped, internal package wrapped, internal package
Teon Sheet Kit (optional) wrapped, internal , package wrapped, internal package wrapped, internal package -
NOTE: Prior to initial start-up, all removable parts and the grill surface should be cleaned with warm, soapy
water to remove manufacturing oils, then rinsed and dried thoroughly. Apply oil to the conveyor chain after
washing. Also the grill surface should be seasoned with a light coating of oil (fry oil works well) and pre-
heated for 15 - 20 minutes.
3
