QUICK START GUIDE
PDXL-2 Dual Power over DXLink Controller
Overview
The PDXL-2 (FG1090-170) is a Power over DXLink injector which allows for remote
powering of any two DXLink devices. The device simplifies installation by allowing the
DXLink Transmitters and Receivers to be placed anywhere even where there are no AC
power outlets—simply install a PDXL-2 in any convenient place within the 100 meter
path to provide power.
The PDXL-2 provides power for DXLink devices by “injecting” power through the twisted
pair cable. The PDXL-2 also accepts I/O control from a NetLinx controller allowing
power down capabilities to either (or both) of the connected DXLink devices to achieve
power savings when the devices are not in use.
Specif ications
The following table lists the specifications for the PDXL-2:
* Cable runs with a minimum specif ication of ANSI/TIE/EIA 568A-5 and ratings of 250
MHz or better (for HD content) and 500 MHz or better (for UHD content) may be used
with DXLink equipment. However, cable run topology and environmental influences can
affect the overall successful distance capabilities of these runs. For successful
deployments up to 100 meters (for HD content) and 80 meters (for UHD content) without
consideration to outside variables, AMX requires the use of shielded Cat6 category cable
(for HD content) and shielded Cat6A category cable (for UHD content) for DXLink runs.
For more details and helpful cabling information, please contact your AMX representative
for a copy of the white paper titled "Cabling for Success with DXLink".
Important Safety Information
• The PDXL-2 should be connected to DXLink devices only. Outside network
connections are not supported.
• Only qualified personnel can install or remove the PDXL-2.
• AC Power Cord Set:
* The power cord must have regulatory agency approval for the specific country
in which it is used (for example, UL, CSA, VDE, etc.)
* The power cord must be a three-conductor type (two current-carrying
conductors and one ground conductor) terminated on one end by an IEC 60320
appliance coupler (for connection to the PDXL-2), and on the other end by a plug
containing a ground (earthing) contact.
* The power cord must be rated for a minimum of 250 VAC RMS operation, with a
minimum rated current capacity of 5 amps or a minimum wire gauge of 18 AWG
(0.75 mm2).
• A PDXL-2 installed in Australia requires power cords with a minimum wire gauge
of 16 AWG (1.0 mm2).
• The PDXL-2 DATA and DATA & POWER ports are shielded RJ45 data sockets. They
CANNOT be used as Plain Old Telephone Service (POTS) telephone sockets. Only
RJ45 data connectors may be connected to these sockets.
• The AC wall socket-outlet must be near the PDXL-2 and easily accessible. You can
remove AC power from the PDXL-2 by disconnecting the AC power cord from
either the wall socket-outlet or the PDXL-2 appliance coupler.
• The PDXL-2 “DATA” and “DATA & POWER” interfaces are qualified as Safety
Extra-Low Voltage (SELV) circuits according to IEC 60950-1. These interfaces
may only be connected to SELV interfaces on other equipment.
• AMX only supports the use of our Enova DGX, Enova DVX, DXLink or Power over
DXLink solutions as the use of any other power supplies or non-compatible
standard PoE solutions may potentially damage the DXLink equipment.
WARNINGS
• The PDXL-2 should only be connected to devices compatible with this product.
Using the PDXL-2 with incompatible devices may cause damage to the device.
• Read the installation instructions before connecting the PDXL-2 to its power
source.
• Follow basic electricity safety measures before connecting the PDXL-2 to its
power source.
• A voltage mismatch can cause equipment damage and may pose a fire hazard. If
the voltage indicated on the label is different from the power outlet voltage, do
not connect the PDXL-2 to this power outlet.
FIG. 1 PDXL-2 DUAL POWER OVER DXLINK CONTROLLER
PDXL-2 Specifications
Active Power Requirements:
Power Connector (1) 100-240V, 50/60 Hz, 1.6A
Power Capabilities • Maximum Current Draw: 1.0A
• Typical Current Draw: 0.35A
Note: Power consumption depends on the device connected to
the DXLink port.
Environmental:
Temperature (Operating) 32° to 104° F (0° to 40° C)
Temperature (Storage) –4º to 158ºF (–20º to 70ºC)
Humidity (Operating) 90%, Non-condensing (maximum)
Humidity (Storage) 95%, Non-condensing (maximum)
Operating Altitude –1000 to 10,000 ft. (–304.8 to 3048 m)
DXLink:
DXLink ports (2) sets of 2 RJ-45 DXLink connectors
Transport Layer
Throughput
10.2 Gbps pass thru
Power over DXLink Output
(per output)
• Pin Assignment & Polarity 4/5 (+), 7/8 (-)
• Output Power Voltage 55 VDC
• Output Power 30 Watts (guaranteed)
• Output Current 0.6 A (maximum)
Indicators:
AC Power Indicator 2 LED (1 for each DXLink Powered Output)
• Yellow (On): power is on and active
• Green (On): A remote terminal is connected
Channel Power Indicator (1) LED green
General:
Dimensions (HWD) 1 7/16” x 7” x 6 13/16” (3.63cm x 17.78cm x 17.24cm)
Weight 2.25 lbs (1.02 kg)
Front Components • AC Power Indicator
• Channel Power Indicator
• DXLink ports
Back Components • (4) 3.5 mm (female) captive-wire connectors. 1 each for:
* Ground
* Relay port 1 (to be fed from I/O connection)
* Relay port 2 (to be fed from an I/O connection)
* +12V power feed
• (1) Power connector
Mounting Options • Rack: MPA-VRK Rack Mounting Tray (FG5968-30)
• Surface: AVB-VSTYLE-SURFACE-MNT Surface Mount
Brackets (FG1010-722)
• Pole: AVB-VSTYLE-POLE-MNT Single Module Pole Mounting
Kit (FG1010-723)
PDXL-2 Specifications (Cont.)
Compatible AMX Products • DXLink HDMI Transmitter Module
• DXLink Multi-Format Transmitter Module
• DXLink Multi-Format Decor Style Wallplate Transmitters (US)
• DXLink Multi-Format Wallplate Transmitters
• DXLink HDMI Receiver Module
• DXLink 4K HDMI Decor Style Wallplate TX
• DXLink 4K HDMI RX
Twisted Pair Cable Type* • Shielded Cat6A minimum for 4K signal support.
• Shielded Cat6 minimum for 1080p and below.
For more details and helpful cabling information, reference the
white paper titled "Cabling for Success with DXLink" available at
www.amx.com or contact your AMX representative.
Twisted Pair Cable
Length*
• Up to 262 ft. (80 m) for full 4K signal support.
• Up to 328 ft. (100 m) for 1080p and below.
Important: DXLink twisted pair cable runs for DXLink
equipment should only be run within a common building.
Certifications • FCC Part 15 Class A
• CE EN 55022 Class A
• C-Tick CISPR 22 Class A
• UL 60950-1
• CE EN 55024
• CE EN 60950-1
• IEC 60950-1
© 2017 Harman. All rights reserved. NetLinx, Enova, AMX, AV FOR AN IT WORLD, and HARMAN, and their respective logos are registered
trademarks of HARMAN. Oracle, Java and any other company or brand name referenced may be trademarks/registered trademarks of their
respective companies.
AMX does not assume responsibility for errors or omissions. AMX also reserves the right to alter specifications without prior notice at any time.
The AMX Warranty and Return Policy and related documents can be viewed/downloaded at www.amx.com.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 AMX.com | 800.222.0193 | 469.624.8000 | +1.469.624.7400 | fax 469.624.7153
AMX (UK) LTD, AMX by HARMAN - Unit C, Auster Road, Clifton Moor, York, YO30 4GD United Kingdom • +44 1904-343-100 • www.amx.com/eu/
93-1090-170 REV: D
Last Revised:4/19/2017
Mounting the Device
The PDXL-2 may be mounted on a flat surface using AVB-VSTYLE-SURFACE-MNT
Surface Mount Brackets (FG1010-722) to mount the device. See the Module Options for
V Styles Modules Quick Start Guide for mounting instructions.
• Use MPA-VRK Rack Mount Brackets (FG5968-30) for a rack mount installation.
• Use the AVB-VSTYLE-POLE-MNT Single Module Pole Mounting Kit (FG1010-723)
for a pole mount installation.
Preliminary Steps
Before placing the PDXL-2:
• Ensure that AC power is applied to the PDXL-2, using an operational ground
connection.
• Connect the incoming DXLink twisted pair connection to the Data port and
connect the twisted pair connection for the DXLink device to be powered to the
Power port.
• Do not cover the device or block the airflow to the device with any foreign objects.
Keep the PDXL-2 away from excessive heat and humidity and free from vibration
and dust.
• Ensure that the cable length from the originating DXLink source to the final
DXLink destination does not exceed 328 feet (100 meters). The device is not a
repeater and does not amplify the DXLink data signal.
• The PDXL-2 does not have a power switch. Simply plug the device into an AC
power source.
Installing the PDXL-2
Perform the following steps to install the PDXL-2:
1. Connect the PDXL-2 to an AC outlet (100-240VAC) using an appropriate power
cord.
2. Connect the DATA & POWER port to a DXLink Transmitter, Receiver, or Wallplate
via the appropriate twisted pair cable.
3. Use an additional twisted pair cable to connect the DATA port to a separate DXLink
Transmitter, Receiver, or Wallplate.
Note: If connecting both DATA & POWER ports to separate devices, use the provided
twisted pair cable to connect the two DATA ports together. Connecting the DATA
ports is not necessary if you are only connecting one DATA & POWER port to
another device.
IMPORTANT: The minimum length from TX to PDXL-2 is 12ft (3.6m). The minimum
length from RX to PDXL-2 is 6ft (1.8m).
eg. TX -> 12ft(min) -> PDXL-2(with 12inch data cable) -> 6ft(min) -> RX
4. (Optional) Connect the PDXL-2 to the I/O port on your Master so you can power
off connected devices. See Powering Off Connected Devices for details.
FIG. 2 displays an example configuration when using only one DATA & POWER port to
power a device. In this example, the RX is powered by the PDXL-2 while the TX is
powered by a local power supply, so a power line to the TX is not needed.
FIG. 3 displays an example configuration when using both DATA & POWER ports to
power two separate devices:
Pin Connections
FIG. 4 describes the PDXL-2 pin-out connections for the IN and OUT Ports on the front
panel of the device:
Relay Port Wiring
Connecting the PDXL-2 to the I/O port on your Master enables you to power off devices
connected to the PDXL-2. FIG. 5 displays the relay port on the rear panel of the PDXL-2:
Powering Off Connected Devices
The relay port on the PDXL-2 is set to ON by default.
The following diagram (FIG. 6) illustrates how the Relay Port on the PDXL-2 connects to
an I/O port on a NetLinx Master Controller:
• Note that the +12V Power pin on the PDXL-2 is a power input (unlike the relay
connectors on many other AMX products). In this case, the +12V Power (output)
pin on a NetLinx I/O Port connects directly to the +12V pin on the PDXL-2 Relay
Port.
• The RELAY PORT 1 and RELAY PORT 2 pins on the PDXL-2 connect to the pins on
the NetLinx I/O port associated with the devices that will be powered off.
• Also note that a GND-to-GND connection between these connectors is not
necessary.
To turn off power on a DXLink port, you must connect the relay port to an I/O port on a
Master and set the corresponding I/O channel on the Master to ON. For example, to
turn off power on DXLink port 1 (assuming the connection shown in FIG. 6):
ON [dvIO,1]
To turn on Power to DXLink port 1:
OFF [dvIO,1]
Consult the NetLinx Integrated Controllers WebConsole & Programming Guide for more
information on channels and commands.
FIG. 2
WIRING USING ONE DATA & POWER PORT
FIG. 3 WIRING USING BOTH DATA & POWER PORTS
To RX To TX
(not used)
To RX To Wallplate
twisted pair cable
FIG. 4 PDXL-2 PIN-OUT CONNECTIONS
FIG. 5 RELAY PORT
FIG. 6 WIRING DIAGRAM - PDXL-2 RELAY PORT TO NETLINX MASTER I/O PORT
Pins 1/2 (DATA only)
Pins 3/6 (DATA only)
Pins 4/5 (DATA + PWR)
Pins 7/8 (DATA + PWR)
= TransformerNote:
DATA
DATA
DATA
DATA
POWER (+)
POWER (-)
DATA & POWER DATA
GND = Signal Ground
RELAY PORT 2 = Input/Output
RELAY PORT 1 = Input/Output
+12V = Power input
PDXL-2 Relay Port
NetLinx Master I/O Port
PDXL-2 Relay Port
+ 12V
RELAY PORT 1
RELAY PORT 2
NetLinx I/O
Port
+ 12V
I/O Port x

Produktspezifikationen

Marke: AMX
Kategorie: Nicht kategorisiert
Modell: PDXL-2

Brauchst du Hilfe?

Wenn Sie Hilfe mit AMX PDXL-2 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Nicht kategorisiert AMX

AMX

AMX HPX-MSP-7-SL Bedienungsanleitung

6 September 2024
AMX

AMX HPX-MSP-10-SL Bedienungsanleitung

6 September 2024
AMX

AMX TPC-WIN8-TAB Bedienungsanleitung

5 September 2024
AMX

AMX NMX-DEC-N1222A Bedienungsanleitung

4 September 2024
AMX

AMX NMX-DEC-N2222A Bedienungsanleitung

4 September 2024
AMX

AMX NMX-DEC-N1233 Bedienungsanleitung

4 September 2024
AMX

AMX NMX-DEC-N2211 Bedienungsanleitung

4 September 2024
AMX

AMX NMX-ENC-N1134A Bedienungsanleitung

4 September 2024
AMX

AMX NMX-ENC-N1133 Bedienungsanleitung

4 September 2024
AMX

AMX NMX-ENC-N2315-WP Bedienungsanleitung

4 September 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung fĂĽr -Kategorien-

DAS Audio

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024
Ferplast

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024
AEG

AEG MECK52 Bedienungsanleitung

16 Oktober 2024
Makita

Makita UR012G Bedienungsanleitung

16 Oktober 2024
Stihl

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024
Ernesto

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024
IFM

IFM AC901S Bedienungsanleitung

16 Oktober 2024
Nedis

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024
AEG

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024
ART

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
