1
sw915 digital audio travel partner
Thank you for choosing the SW915 Digital Audio Travel
Partner from AmpliVox Portable Sound Systems. We are
excited in introducing a “leap forward” in portable sound
systems with the incorporation of a fully digital amplifier
system along with an industry leading remote control
operation. Our system combines flexibility with functionality.
Please refer to this user guide as you enjoy the unique
capabilities of another quality product from AmpliVox
Portable Sound Systems. As always, you can reach us at
800-267-5486, Monday - Friday 8am - 6pm CST.
TABLE OF CONTENTS ......................................................... 1
GETTiNG STArTEd/QuiCk SETup ................................... 2
CONTrOL pANEL FuNCTiONS .......................................... 3
CONTrOLS / iNdiCATOrS ................................................ 4
AudiO FuNCTiONS & AdjuSTmENT ............................... 4
iNpuTS / OuTpuTS ............................................................. 5
rEmOTE CONTrOL ......................................................... 6-7
WirELESS miC 8 ...................................................................
Cd pLAYEr .......................................................................... 9
OpTiONAL EQuipmENT
diGiTAL rECOrdEr/pLAYEr .....................................10
CASSETTE rECOrdEr/pLAYEr .................................10
TrOuBLEShOOTiNG .........................................................11
AmpLivOx pOrTABLE SOuNd SYSTEmS
ph. 800-267-5486 Fx. 800-26705489
WWW.AmpLi.COm CuSTOmErSErviCE@AmpLi.COm
Made in USA
NEEd hELp?
CALL 800-267-5486
Or 847-498-9000
EmAiL:
CuSTOmErSErviCE@
AmpLi.COm
uSEr GuidE
2
SW915 DIGITAL AUDIO TRAVEL PARTNER
GettinG Started/Quick Setup (alSo printed on Battery cover)
1. Power unit on with rocker switch. The display will light
with MASTER VOLUME indicated.
Display will go black after one minute’s inactivity to
preserve battery power. Display will illuminate with a
press of any button.
2. Use the remote or the UP and DN buttons on the control
panel, to select a function.
3 To change the level of a selected function, press the
ADJUST button. ADJ will appear on the display. Press UP
or DN button to obtain desired level, then press SAVE.
4. Use UP and DN buttons to cycle through BASS, TREBLE,
DUCKING, REVERB, VOICE, and all VOLUME controls; then
ADJUST and press SAVE.
5. UHF Wireless MIC - To turn receiver on - Press and hold the
SET button for about two seconds. The current channel
will flash three times quickly; then the system will begin
to scan for the next open channel. When it finds an open
channel, it will flash the open channel three times and
then set the channel.
To turn transmitter on - Before turning on the transmitter,
use the provided screwdriver to set the transmitter channel
selector switches to the same number that is displayed on
the receiver. Select channels 1-8.
6. BATT STAT indicator - Red = no battery power, Yellow = 1
hour left. Charge battery overnight for best results.
If you need further assistance, please call 1-800-267-5486,
8am-6pm M-F CST.
PLEASE NOTE: THE REMOTE DOES NOT TURN THE UNIT ON OR OFF.
YOU MUST DO THAT ON THE CONTROL PANEL
ATTENTiON:
ALL SAFETY AND OPERATING INSTRUCTIONS SHOULD BE READ
BEFORE OPERATING APPLIANCE. ALL OPERATING AND USE INSTRUCTIONS
SHOULD BE FOLLOWED WHEN OPERATING THE APPLIANCE. HEED AND
ADHERE TO ALL WARNINGS ON THE APPLIANCE AND IN THE OPERATING
INSTRUCTIONS. RETAIN ALL SAFETY AND OPERATING INSTRUCTIONS FOR
FUTURE REFERENCE.
WATEr & mOiSTurE -
DO NOT USE THE APPLIANCE NEAR WATER; IE.
BATHTUB, WASHBOWL, KITCHEN SINK, LAUNDRY TUB, WET BASEMENT OR
SWIMMING POOL.
hEAT -
SITUATE THE APPLIANCE AWAY FROM HEAT SOURCES SUCH AS
RADIATORS, HEAT REGISTERS, STOVES OR OTHER APPLIANCES (INCLUDING
AMPLIFIERS) THAT PRODUCE HEAT.
pOWEr SOurCES -
CONNECT THE APPLIANCE ONLY TO A POWER SUPPLY
TYPE DESCRIBED IN THE OPERATING INSTR-UCTIONS OR MARKED ON THE
APPLIANCE. GROUNDING OR POLARIZATION - PRECAUTIONS SHOULD BE TAKEN
SO THAT THE GROUNDING OR POLARIZATION MEANS OF THE APPLIANCE ARE
NOT DEFEATED. POWER CORD PROTECTION - POWER SUPPLY CORDS SHOULD
BE ROUTED SO THAT THEY ARE NOT LIKELY TO BE WALKED ON OR PINCHED BY
ITEMS PLACED UPON OR AGAINST THEM, PAYING PARTICULAR ATTENTION TO
CORDS AT PLUGS, CONVENIENCE RECEPTACLES, AND THE POINT WHERE THEY
EXIT FROM THE APPLIANCE.
prOduCT priCES, FEATurES, SpECiFiCATiONS ANd
AvAiLABiLiTY ArE SuBjECT TO ChANGE WiThOuT NOTiCE.
OBjECT & LiQuid ENTrY -
CARE SHOULD BE TAKEN SO THAT OBJECTS DO
NOT FALL AND LIQUIDS ARE NOT SPILLED INTO THE ENCLOSURE THROUGH
OPENINGS.
dAmAGE rEQuiriNG SErviCE -
THE APPLIANCE SHOULD BE SERVICED
BY QUALIFIED SERVICE PERSONNEL WHEN: (A) THE POWER SUPPLY CORD OR
THE PLUG HAS BEEN DAMAGED (B) OBJECTS HAVE FALLEN OR LIQUID HAS
BEEN SPILLED INTO THE APPLIANCE (C) THE APPLIANCE HAS BEEN EXPOSED
TO RAIN (D) THE APPLIANCE DOES NOT APPEAR TO BE OPERATING NORMALLY
OR EXHIBITS A MARKED CHANGE IN PERFORMANCE (E) THE APPLIANCE HAS
BEEN DROPPED OR THE ENCLOSURE DAMAGED.
SErviCiNG -
THE USER SHOULD NOT ATTEMPT TO SERVICE THE APPLIANCE
BEYOND THAT DESCRIBED IN THE OPERATING INSTRUCTIONS. ALL OTHER
SERVICING REFER TO A QUALIFIED SERVICE PERSONNEL.
important Safety inStructionS
NEEd hELp?
CALL 800-267-5486
EmAiL:
CuSTOmErSErviCE@
AmpLi.COm
3
SW915 DIGITAL AUDIO TRAVEL PARTNER
* USB In: Computer can connect here to allow audio files on computer to be played.
** Mini Jack Inputs: To connect devices as MP3 players, portable tape and CD players or any other audio device that has a 1/8-in. output.
*** XLR/Combo Jacks: To connect balanced or unbalanced microphones that have either XLR or phone plug connectors.
**** AC Power Jack: Either 110 or 220 volts can be used WITHOUT needing to move a switch; as the power supply does this action.
***** Battery Status Light: Red = No battery power, Yellow = 1 hour left of battery power. For best results – charge battery overnight.
# Overload light: Lights up when volume is turned up too far and could cause audible distortion.
## ¼-in. Phone Jacks: Can be used for outboard processors, musical instruments and recorders.
control panel
LPOWER
BATT STAT
OVERLOAD
R
A
U
X
USB
IN
POWER
CH. 1 CH. 2 CH. 3
LINE
IN
ADJUSTSAVEDN UP
SELECT
OUT
CHARGE/AC ON
25 AMP
CIRCUIT BREAKER
110/220 VAC
AUTO SWITCHING
PARTNER
QUICK SET UP GUIDE
1. r unit on with rocker switch. The display will light with MASTER ME indicated. Powe VOLU
Display will go black after one minute’s inactivity preser Display will to ve battery power.
illuminate with a press of any button.
2. Use the remote or the UP and DN buttons on the control panel, select a function. to
3. change the level of a selected function, press the ADJUST button. ADJ will appear on the T o
displa Press UP or DN button obtain desired le VE.y. to vel, then press SA
4. Use UP and DN buttons cycle through BASS, TREBLE, DUCKING, REVERB, VOICE, and all to
VOLUME controls; then ADJUST and press SAVE.
5. UHF Wireless MIC - turn receiver on - Press and hold the SET button for about two seconds. T o
The current channel will flash three times quickly; then the system will begin scan for the to
next open channel. When it finds an open channel, it will flash the open channel three times
and then set the channel.
turn transmitter on - Before turning on the transmitter, use the pr ided screwdriver set T o ov to
the transmitter channel selec r switches the same number that is displa d on the to to ye
receiver. Select channels 1-8.
6. BATT STA T indicator - Red = no batter Yellow = 1 hour left. Charge battery ernight y power, ov
for best results.
Please refer to the owners manual for complete instructions.
Instructions are also available on www.ampli.com. If you need further
assistance please call 1-800-267-5486, 8am-6pm M-F CS WWW.AMPLI.COMT.
MADE IN THE USA
INFORMATION DISPLAY
Turns off after 1 minute of inactivity to
save battery. Comes on with touching
any of the 4 buttons below display (DN,
UP, SAVE, ADJUST)
CD PLAYER / RECORDER
WIRELESS MICROPHONE RECEIVER
3 ADDTITONAL SLOTS FOR
OPTIONAL EQUIPMENT:
CASSETTE RECORDER/PLAYER,
DIGITAL RECORDER/PLAYER OR
WIRELESS MICROPHONE RECEIVER
RCA AUXILIARY
INPUTS
* USB INPUT
*** XLR/COMBO JACKS
** MINI JACK INPUTS
CASSETTE PITCH
CONTROL (OPTIONAL
EQUIPMENT)
AUDIO CONTROL BUTTONS - USED
TO SET ALL AUDIO FUNCTIONS
LINE IN / LINE OUT ##
PHONE JACKS (1/4")
INDICATOR LIGHTS:
POWER
***** BATTERY STATUS
# OVERLOAD
INDICATOR LIGHT FOR
AC OR POWER
*** XLR/COMBO JACKS
AC POWER JACK WITH
BUILT-IN LINE FUSE
HOLDER
POWER SWITCH
BATTERY PANEL
USER ACCESSIBLE
Quick Set Up
Instructions are on page 2
NEEd hELp?
CALL 800-267-5486
Or 847-498-9000
EmAiL:
CuSTOmErSErviCE@
AmpLi.COm
