Seite 1/48
185D5580P237 49-85155 01-09 JR
Safety Instructions . . . . . .2–7, 25
Operating Instructions
Aluminum Foil . . . . . . . . . . .12, 13
Clock and Timer . . . . . . . . . . . .10
Oven . . . . . . . . . . . . . . . . . . . .10–15
Baking and Roasting . . . . . . . . .12
Broiling . . . . . . . . . . . . . . . . .13, 14
Broiling Guide . . . . . . . . . . . . . .14
Oven Control . . . . . . . . . . . . . . .11
Power Outage . . . . . . . . . . . . . . .11
Preheating . . . . . . . . . . . . . . . . . .12
Surface Cooking . . . . . . . . . . . .8, 9
Thermostat Adjustment . . . . . .15
Care and Cleaning
Air Vents . . . . . . . . . . . . . . . . . . . .21
Broiler Pan and Grid . . . . . . . . .21
Burner Assemblies . . . . . . . .16–18
Burner Caps and Heads . . . . . .18
Burner Grates . . . . . . . . . . . . . . .17
Control Panel and Knobs . . . . .21
Cooktop Surface . . . . . . . . . . . . .19
Drip Pans . . . . . . . . . . . . . . . . . . .16
Lift-Off Oven Door . . . . . . . . . . .20
Lift-Up Cooktop . . . . . . . . . . . . .19
Oven Bottom . . . . . . . . . . . . . . . .20
Oven Interior . . . . . . . . . . . .22, 23
Removable Broiler Drawer . . . .21
Racks . . . . . . . . . . . . . . . . . . . . . . .22
Stainless Steel Surfaces . . . . . . .19
Installation
Instructions . . . . . . . . . . . . .24–39
Anti-Tip Device . . . . . . .28, 38, 39
Connect the Range
to Gas . . . . . . . . . . . . . . . . . . .29–32
Convert to LP Gas . . . . . . . . . . .39
Dimensions and
Clearances . . . . . . . . . . . . . . . . . .27
Electrical Connections . . . .33, 34
Level the Range . . . . . . . . . . . . .38
Light the Pilots . . . . . . . . . . .34–37
Troubleshooting Tips . . . .40–42
Accessories . . . . . . . . . . . . . . . . .45
Consumer Support
Consumer
Support . . . . . . . . . . . .Back Cover
Warranty . . . . . . . . . . . . . . . . . . .46
Write the model and serial
numbers here:
Model #____________________
Serial # ____________________
You can find them on a label on
the front of the range behind the
kick panel or broiler drawer.
Owner’s Manual and Installation Instructions
Model AGBS300
Printed in Mexico
Printed on Recycled Paper
Non-Self-Cleaning Gas
Ranges
www.AmericanaAppliances.com
Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting TipsConsumer Support
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
—WHAT TO DO IF YOU
SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
WARNING: If the information
in this manual is not followed exactly,
a fire or explosion may result causing
property damage, personal injury
or death.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock,
or to prevent property damage, personal injury, or loss of life.
®
To reduce the risk of tipping the range, the range must be
secured by a properly installed anti-tip bracket. See installation
instructions shipped with the bracket for complete details
before attempting to install.
To check if the bracket is installed and engaged properly,
carefully tip the range forward. The bracket should stop
the range within 4 inches. If it does not, the bracket must be
reinstalled. If the range is pulled from the wall for any reason,
always repeat this procedure to verify the range is properly
secured by the anti-tip bracket.
For free-standing or slide-in ranges, never completely remove
the leveling legs or the range will not be secured to the anti-tip
device properly.
If you did not receive an anti-tip bracket with your
purchase, call 1.800.626.8774 to receive one at no
cost (in Canada, call 1.800.561.3344). For installation
instructions of the bracket, visit GEAppliances.com
(in Canada, GEAppliances.ca).
ANTI-TIP DEVICE
Consumer SupportOperating Instructions
Safety Instructions
Installation Instructions Troubleshooting Tips
3
www.AmericanaAppliances.com
WARNING!
Have the installer show you the location of the range gas shut-off valve and how to shut it off if necessary.
Have your range installed and properly
grounded by a qualified installer, in
accordance with the Installation Instructions.
Any adjustment and service should be
performed only by qualified gas range
installers or service technicians.
Do not attempt to repair or replace any
part of your range unless it is specifically
recommended in this manual. All other
service should be referred to a qualified
technician.
Plug your range into a 120-volt grounded
outlet only. Do not remove the round
grounding prong from the plug. If in doubt
about the grounding of the home electrical
system, it is your personal responsibility and
obligation to have an ungrounded outlet
replaced with a properly grounded,
three-prong outlet in accordance with
the National Electrical Code. Do not use
an extension cord with this appliance.
SAFETY PRECAUTIONS
IMPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to
publish a list of substances known to the state to cause birth defects or other reproductive harm, and
requires businesses to warn customers of potential exposure to such substances.
Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon
monoxide, formaldehyde and soot, caused primarily by the incomplete combustion of natural gas or
LP fuels. Properly adjusted burners, indicated by a bluish rather than a yellow flame, will minimize
incomplete combustion. Exposure to these substances can be minimized by venting with an open
window or using a ventilation fan or hood.
WARNING: NEVER use this
appliance as a space heater to heat or
warm the room. Doing so may result
in carbon monoxide poisoning and
overheating of the oven.
