AL802ULADAJ
NAC Power Extender
Installation Guide
(See Application Guide for additional information)
- 2 - AL802ULADAJ
Agency Listings:
• UL Listed Control Units for Fire Protective
Signaling Systems (UL 864).
• MEA - NYC Department of Buildings Approved.
• CSFM - California State Fire Marshal Approved.
• FM - Factory Mutual Approved.
• NFPA 72 Compliant.
Input:
• Power input 120VAC 60 Hz, 5 amp.
• Two (2) Class A, Style Z or two (2) Class B,
Style W, Y FACP inputs.
• Two (2) NC dry contact trigger inputs.
Output:
• Class 2 Rated power limited outputs.
• 24VDC @ 8 amp max total alarm current.
• 2.5 amp max current per output.
• Separate 1.0 amp auxiliary output.
• Programmable supervised indicating circuit outputs:
Four (4) Class B, Style W, Y or Two (2) Class A,
Style Z or One (1) Class A, Style Z and Two (2) Class B,
Style W, Y (see Application Guide).
• Thermal and short circuit protection with auto reset.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switchover to stand-by battery when
AC Fails.
• Zero voltage drop when switching over to
battery backup.
Supervision:
• AC fail supervision (form "C" contact, 1 amp / 28VDC).
Factory set for 30 seconds with optional 2.5 to 3 hour
delay setting (field selectable).
• Instant local AC trouble reporting relay
(form “C” contact, 1 amp / 28VDC).
• Batter vision y presence and low battery super
(form "C" contact, 1 amp / 28VDC).
Visual Indicators:
• Input and output status LED indicators.
Special Features:
• 2-wire horn/strobe Sync mode allows audible
notification appliances (horns) to be silenced
while visual notification appliances (strobes)
continue to operate.
• Temporal Code 3, Steady Mode, Input to Output
Follower Mode (maintains synchronization of
notification appliances circuit).
• Compatible with 12VDC or 24VDC fire panels.
• Output loop supervision steered to input 1 or input 2.
• Signal circuit trouble memory (helps identify
intermittent loop problems).
• Common trouble input and output.
• Ground fault detection.
Added Features:
• Unit includes power supply, red enclosure, cam lock,
and battery leads.
Enclosure Dimensions and Descriptions:
AL802ULADAJ
18"H x 14.5"W x 4.5"D
Product Weight:
19 lbs.
Overview:
The Altronix AL802ULADAJ is an extremely cost effective 8 amp remote power supply/battery charger. It may be con-
nected to any 12 or 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit
(NAC such as strobes and horns) expansion support to meet ADA requirements. It also provides auxiliary power to sup-
port system accessories. The unit delivers electronically regulated and filtered 24 volt power to Class B, Style W, Y or Class
A, Style Z NAC loop circuits. Additionally, a separate 1.0A auxiliary output with reset for four (4)-wire smoke detectors
is available. The 8 amp max. alarm current can be divided between the four (4) outputs for powering NAC devices. Each
output is rated at 2.5 amp max., and can be independently programmed for Steady, Temporal Code 3 or Strobe
Synchronization. All outputs may be programmed for Input to Output Follower Mode (output will follow input. i.e. March
Time Input, March Time Output). In non-alarm condition independent loop supervision for Class A, Style Z and/or Class
B, Style W, Y FACP NAC circuits is provided. In the event of a loop trouble, the FACP will be notified via the steered input
(input 1 or input 2). In addition, there are common trouble output terminals [NC, C, NO] which are used to indicate gen-
eral loop/system trouble. A common trouble input is provided for optional NC (normally closed) devices to report trouble
to the FACP. Two (2) FACP signaling outputs can be employed and directed to control supervision and power delivery to
any combination of the four (4) outputs.
Specifications:
AL802ULADAJ - NAC Power Extender
AL802ULADAJ - 3 -
Power Supply Specifications:
Stand-by Specifications:
Note: Unit is equipped with 1 amp max. auxiliary output: “AUX” will remain battery backed up during power
outage. For loads connected to “AUX” please, refer to battery “Stand-by Specifications” above for ratings. When
loads are connected to “AUX” output during alarm condition, the remaining outputs may, not exceed 8 amp total
alarm current (example: AUX = 1 amp, outputs up to 7 amp).
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA
72/ANSI, and with all local codes and authorities having jurisdiction.
Product is intended for indoor use only.
Carefully review:
Application Guide for AL602ULADAJ, AL802ULADAJ, AL1002ULADAJ
Power Supply Specifications (pg. 3)
Stand-by Specifications (pg. 3)
Output Programming Selection Table (pg. 4)
Sync Mode Selection Table (pg. 4)
Terminal Identification Table (pgs. 5-6)
LED Status Indication Table (pg. 6)
1. Mount the unit in desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads
protruding. Place the enclosure’s upper keyholes over the two upper screws, level and secure. Mark the position
of the lower two holes. Remove the enclosure. Drill the lower holes and install the two fasteners. Place the
enclosure’s upper keyholes over the two upper screws. Install the two lower screws and make sure to tighten
all screws (Enclosure Dimensions, pg. 12).
Secure enclosure to earth ground (Fig. 1, pg.3).
2. Connect the line (L), ground (G), and neutral (N) terminals to a separate unswitched AC circuit (120VAC, 60Hz)
dedicated to the Fire Alarm System.
3. Measure output voltage before connecting devices.This helps avoid potential damage.
4. Connect battery to terminals marked [+ BAT --] on the Power Supply Board (battery leads included).
Use two (2) 12VDC batteries connected in series.
5. Set output selection switches marked [OUT1 through OUT4] to follow corresponding input [IN1 & IN2] and
desired output signal type (Output Programming Selection Table, pg. 4).
6. Connect FACP output to desired AL800LGK logic board inputs, and notification appliances to desired AL800LGK
logic board outputs (see Application Guide).
L G N
line
ground
neutral
Fig. 1
AC Input: 120VAC 60Hz, 5 amp, supplied by a maximum 15 amp dedicated branch circuit.
Output:
Four (4) regulated supervised NAC output circuits, 24VDC, 2.5 amp maximum current.
One (1) aux. special application 24VDC power output circuit 1 amp, non-supervised total
output current must not exceed current 8 amp in Alarm Condition.
Battery: Use two (2) 12VDC / 12AH or two (2) 12VDC / 7AH
batteries connected in series.
Stand-by/Alarm Current
Consumption: 90mA/175mA
EOL Resistor (end of line): 2.2K (2200 ohm), Altronix Model # AL-EOL22 (included).
Ground fault maximum
test impedance: 1000 ohm.
Stand-by Batteries Stand-by Time Total Amp/Minutes Alarm Output Current Aux. Output
24VDC/7AH 24 Hours 8 amp/5 minutes ---
24VDC/12AH
(use two (2) 12VDC batteries in series) 24 Hours 8 amp/5 minutes 50mA
24VDC/36AH 24 Hours 8 amp/5 minutes 1 amp
