Seite 1/12
Tesla Model 3 & Y
PSS-TSLA 20240220v2 1/12
Important Notice
WARNING: This aftermarket plug-and-play audio system for Tesla vehicles ("Product") is intended for
installation by qualied professionals with experience in automotive electrical systems. Improper installa-
tion can result in serious damage to your vehicle, electrical system, and personal injury or death. By
purchasing and/or installing this Product, you acknowledge and agree to the following:
Installation at your own risk: You assume all responsibility and risk associated with the installa-
tion of this Product. Neither Alps Alpine North America, Inc. nor its aliates are responsible for
any damage or injury caused by improper installation.
The installation of this product requires specialized skills and experience. We recommend that
you have the product installed by an Alpine authorized dealer
Potential for electrical damage: Improper installation can cause electrical damage to your Tesla
vehicle, including, but not limited to, blown fuses, shorts, res, and damage to sensitive elec-
tronic components and batteries.
No warranty for improper installation: This Product's warranty is expressly limited to manufac-
turing defects and does not cover any damage caused by improper installation.
ASSUMPTION OF RISK: YOU ACKNOWLEDGE AND AGREE THAT YOU ARE KNOWINGLY ASSUM-
ING THE RISK OF DAMAGE TO YOUR TESLA VEHICLE AND/OR PERSONAL INJURY OR DEATH BY
INSTALLING THIS PRODUCT YOURSELF AND THAT INSTALLING THIS PRODUCT MAY AFFECT OR
RESULT IN TERMINATION OF YOUR LIMITED WARRANTY WITH TESLA.
LIMITATION OF LIABILITY: TO THE FULLEST EXTENT PERMITTED BY LAW, ALPS ALPINE NORTH
AMERICA, INC. AND ITS AFFILIATES SHALL NOT BE LIABLE FOR ANY DIRECT, INDIRECT, INCI-
DENTAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES ARISING OUT OF OR RELATED TO THE
INSTALLATION OR USE OF THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, DAMAGE TO
YOUR TESLA VEHICLE, PERSONAL INJURY, PROPERTY DAMAGE, OR RENDERING YOUR LIMITED
WARRANTY INEFFECTIVE.
We strongly recommend consulting your Tesla owner's manual or qualied professional for specic
installation instructions. We recommend reviewing all online resources and tutorials available for your
specic Tesla model before attempting installation. If you are unsure about any aspect of the installation
process, please consult a qualied professional.
Tesla Model 3 & Y
PSS-TSLA 20240220v2 2/12
Tesla Model 3/Y Power UP & Down Procedure
WARNING: Before beginning install on your tesla follow the below procedure.
1) Turn o the Screen in Settings Following Step (A,B,C)
A) Enter the Controls Menu in bottom Left Corner
B) Tap Safety & Security Menu on the Left-Hand Menu
C) Press the Power OFF Button, and Conrm OFF
2) Access the Frunk and disconnect the low voltage battery (-) Cable.
3) Remove the Rear Bench Seat Cushion by unlatching 2 lock mechanisms at
the bottom edge of the seat.
4) Un-Plug the the high voltage contactor under the Rear Seat
Battery State should be near 100% charged.
ALL WINDOWS ROLLED DOWN
Frunk & Trunk is OPEN
1) Under the Rear Bench Seat cushion plug- in and latch the high voltage
battery contactor pictured above.
2) Access the Frunk and re-connect the low voltage battery (-) Cable.
3) Power up the vehicle pressing the brake pedal.
Tesla Model 3/Y Power Down Procedure
Tesla Model 3/Y Power Up Procedure
IMPORTANT: Re-install ALL Factory Plugs To Their Original Location, FAILURE TO DO SO
CAN CREATE COMPUTER FAULTS.
Tesla Model 3
PSS-TSLA 20240220v2 3/12
Installation Instructions (Integration Harness)
2
4
1
3
Remove 2 factory trim Panels from the passenger foot
well. The under dashboard trim panel and the kick panel
cover both located under the dashboard in the passen-
ger foot well.
Inside of the passenger footwell locate the signal
distribution box. Disconnect the 2 bottom male connec-
tors and replace with plugs (A + B) from the Alpine Tesla
Harness. Transfer the disconnected connectors into the
open ends of the Alpine Harness.
A
B
Route the harness cable from inside the dash down to
the passenger kick panel and locate the matching plug,
disconnect the connector and transfer it to the harness.
(Plug C)
C
Remove the passenger side baseboard lower door trim
and locate the connector just before the base of the
B-pillar. Transfer the connections to (Plug D)
D
