Front cover INTERIOR
BACK cover
QUICK START GUIDE
Compatible with ALC AWS3377 and AWS337
Video Surveillance Systems
NOTE: Cameras are IP66 rated for indoor/outdoor use. For outdoor use it is
recommended to install camera under shelter to protect from direct exposure to
sunlight and other environmental elements. Avoid pointing a camera directly at
any bushes or tree branches or objects that may naturally move due to winds.
CAMERA INSTALLATION + SETUP
1 2 43
Tip: Plan the location of your camera for optimal viewing and proximity to AC Power outlets, (1) power extension
cable is included.
NOTE: Avoid installing in a location which requires the Wireless signal to pass through cement, concrete and metal
structures. This will reduce the transmission range.
Secure the multi-position
camera stand to a stable
surface, ceiling or wall.
Loosen the T-Bolt on the camera
stand and adjust viewing angle using
the Thumb Screw to rotate position.
Align hole on bottom of camera
with T-Bolt to install camera.
Screw antenna into rear of camera.
Attach power cable to power
extension cord AC Adapter.
Plug into electric outlet.
Outdoor camera with
multi-position stand
AC power adapter
Power extension cable
Camera Installation
Screw Pack
Quick Start Guide
IN THE BOX
REQUIRES ALC AWS3377 or AWS337 WIRELESS SURVEILLANCE SYSTEM TO WORK.
For detailed installation and setup, please refer to the Model AWSC37
extended User’s Guide available on our website:
www.atomslabs.com/support
SCAN
TO VIEW COMPLETE USER’S GUIDE
9:00 am - 6:00 pm (Central Time)
Monday - Friday
ATOMS LABS, LLC
2670 Firewheel Drive, Suite D
Flower Mound, TX 7502
CUSTOMER SUPPORT
1.844.767.8544
Power Status
LED
Passive Infrared
Sensor Mounting
Socket
Link Status
LED
Antenna
Connector
Power
Pigtail
Pairing
The Wireless Surveillance System supports up to four (4)
wireless surveillance cameras. Use the following steps to pair
each additional camera.
Tap icon to access Camera Setup.Camera Setup
3
Tap the desired camera to pair. Tap the Pairing
icon twice.
4
Press and Hold the Pairing button
on the camera for 5 seconds. If
pairing is successful “pairing is
successful” appears on the
screen. Tap on it to remove the
message. If a camera is already
assigned to the selected channel,
the monitor overwrites that
camera link with the new one.
5
ONE-YEAR LIMITED WARRANTY
IMPORTANT: Evidence of original purchase is required for warranty service.
WARRANTOR: ELEMENTS OF WARRANTY: Atoms Labs LLC (“ALC”) The ALC warranty covers the product for one (1) year
from the documented date of purchase. The purchase date must be documented with either an original sales receipt from the
first retailer selling the product or by credit card receipts or statements.
WARRANTY DURATION: This warranty to the original user shall terminate & be of no further effect 12 months after the date
of original retail sale. The warranty is invalid if the Product is (A) damaged or not maintained as reasonable or necessary, (B)
modified, altered, or used as part of any conversion kits, sub-assemblies, or any configurations not sold by ALC, (C) improperly
installed, (D) serviced or repaired by someone other than an authorized ALC service center for a defect or malfunction covered
by this warranty, (E) used in any conjunction with equipment or parts or as part of any system not manufactured by ALC, or (F)
installed or programmed by anyone other than as detailed by the owner’s manual for this product.
STATEMENT OF REMEDY: If the product is under warranty, ALC will either, at its option, repair or replace the defective unit &
return it to you without charge for parts, service, or any other cost. ALC, at its option, may replace the unit with a new or
refurbished unit.
THE LIMITED WARRANTY SET FORTH ABOVE IS THE SOLE & ENTIRE WARRANTY PERTAINING TO THE PRODUCT
& IS IN LIEU OF & EXCLUDES ALL OTHER WARRANTIES OF ANY NATURE WHATSOEVER, WHETHER EXPRESS,
IMPLIED OR ARISING BY OPERATION OF LAW, INCLUDING, BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. THIS WARRANTY DOES NOT COVER OR PROVIDE
FOR THE REIMBURSEMENT OR PAYMENT OF INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow
this exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you.
LEGAL REMEDIES: This warranty gives you specific legal rights, & you may also have other rights which vary from state to
state. This warranty is void outside the United States of America & Canada.
PROCEDURE FOR OBTAINING PERFORMANCE OF WARRANTY: If, after following the instructions in the owner’s manual you
are certain that the Product is defective, pack the Product carefully (preferably in its original packaging). The Product should
include all parts & accessories originally packaged with the Product. Include evidence of original purchase & a note describing the
defect that has caused you to return it. The Product should be shipped freight prepaid, by traceable means, to warrantor at:
Atoms Labs, LLC
2670 Firewheel Dr. Suite D Customer Support: 844-767-8544
Flower Mound, TX 75028 9:00 am to 6:00 pm (CST)–Monday through Friday
ALC appreciates your support and feedback! If you come across software bugs or ways we could improve our products,
we would love to hear about them! Please email us at and you will hear back from us within support@atomslabs.com
(2) business days.
FCC Compliance Statement: This device complies
with Part 15 of the FCC rules. Operation is subjected
to the following two conditions: (1)this device may not
cause harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired operation.
Products with CE Marking comply with EMC Directive
(2004/108/EC); Low Voltage Directive (73/23/EEC);
R&TTE (1999/5/EC); ROHS Directive (2011/65/EU) issued by the
Commission of the European Community. Compliance with these
directives implies conformity to the following European Norms:
EMC: EN 301 489 LVD: EN 60950 Radio: EN 300 328
If the camera system no longer functions or can no longer be repaired, it must be disposed of according to the valid statutory regulations.
Use of audio or video equipment for recording the image of a person without their knowledge and consent is prohibited in certain states or
jurisdictions. The end-user assumes all liability for compliance with applicable state, local and federal laws. Wireless cameras require a wired
connection to AC power outlet. Network conditions and environmental factors can adversely affect wireless signal range. Actual night vision range
and image clarity depends on installation location, viewing area and light reflection / absorption. Photography and illustration may differ slightly
from actual product.
©2017 Atoms Labs LLC, All rights reserved. iPhone, iPad, iPod Touch, and App Store are registered trademarks of Apple, Inc. Chrome and
Android are registered trademarks of Google, Inc. Certain other product names, brand names, and company names may be trademarks or
designations of their respective owners.
1
2Tap the icon to enter the System menu.Options
Tap on the ( ) icon (bottom left) to open the menu options. Open/Close >
