Product Overview
Loudspeaker
Rear Panel
10 Pin Terminals
11 Pin Terminals
Network Interface POE（ ）
Loudspeaker
Plastic wall anchors x 4 ST4x20 screw x 4 M4x30 screw x 4
M3x10.5 screw x 1 Allen Wrench x 1
Wall bracket x 110 Pin cable x 1 11 Pin cable x 1
C319X x 1
M3x6 screw x 1
Camera (Optional)
Touch Screen
MIC
Micro SD slot
Right SideFront Panel
C319X
Diode x 2
Without embedded box in the wall
According to the position
of the cable in the wall,
dig out a square
hole(height*width*depth
=66*50*50 mm) that can
accommodate all cables.
Align the square holes of
the wall bracket with the
holes previously dug,
and then mark the four
fixing holes of the wall
bracket on the wall.
Once the fixing holes
were made, insert plastic
wall anchors provided.
Take down the bracket
and drill the four marked
fixing holes on the wall
(5 mm drill bit required).
Twist M3x10.5 screw into the bottom hole of the
bracket until the tail of which align to the edge. Then
fix the wall bracket on the wall with four ST4x20
screws. If there is a ground wire to be connected,
use M3x6 screw to fix it on the wall bracket.
With embedded box in the wall
Make sure all cables in
the embedded box .
Twist M3x10.5 screw into the
bottom hole of the wall
bracket until the tail of which
align to the edge. Then fix
the wall bracket on the wall
with two/four M4x30 screws.
If there is a ground wire to be
connected , use M3x6 screw
to fix it on the wall bracket.
12
43
5
Step 1: Wall Bracket Installa
1 2
Step 2: Device Moun
Connect the cables to device. Push down to fix the device securely. Use the Allen
wrench to tighten the device with one M3x10.5 screw.
Configura
1.Access basic information: After setting up network and power, enter to Setting -> System Info
check Account, Network,Version status.
2.Access the Website: Launch a browser and type in the IP address then enter the username and
password to login.(username/password: admin /admin by default)
3.Account Registration: On web UI, go to the path: Account -> Basic page to fill in the account
information,click Submit to confirm.(Please refer to user manual for more information)
1 2
C319X
Opera
Enter the callee’ s number, then press Dial icon to make a auido call or press video
video call. Press icon to hang up.
Receive a call:
Press icon to pick up the incoming call in video mode or press to pick up the call
Unlock:
During the talk, you can press the Unlock icon on the talking screen to unlock the door.
Monitor:
Press the Monitor icon to receive the video from the door phone or from third-party devices.
Make a call:
camera icon to make a
in audio mode.
Produktspezifikationen
| Marke: | Akuvox |
| Kategorie: | Monitor |
| Modell: | C319A |
