USER MANUAL & INSTALLATION GUIDE

ATTENTION ELECTRICIANS

available in: 43”/1092mm 50”/1270mm 60”/1524mm

LED Light Kit & Ceiling Extension Kit are oponal for all Aeratron™ models

AE2+ & AE3+ CEILING FAN

An isolaon switch per fan is highly recommended.

WARNING: If unusual oscillang movement is observed, immediately

stop using the ceiling fan and contact the naonal distributer/retailer.

Important information - Please read before attempting installation

1. Please read these instructions carefully, be mindful of all warnings and safety information

shown throughout this manual. Should you have any questions please call your local agent.

2. Please review the accompanying assembly diagrams before attempting installation.

3. This fan MUST be installed by a licensed & qualified electrician according to local authority

regulations and in accordance with current wiring rules of the country/state.

4. A copy of the purchasing receipt and proof of installation by a licensed and qualified electrician

according to local authority regulations is required for all warranty claims.

5. Where special access equipment is required to service the fan in accordance with local

authority regulations all associated costs are the responsibility of the owner.

6. Should a warranty claim be required, we reserve the right to charge a service fee for all call

outs where the fan is found not to be defective and / or where access is not provided.

7. To enable future programming, maintenance, cleaning and troubleshooting an isolation switch

per fan is highly recommended. Without an isolation switch per fan, an electrician maybe

required to assist with programming, maintenance, cleaning and troubleshooting. All

associated costs are the responsibility of the owner.

8. A Maximum of 8 fans on each RCD / circuit is recommended. The fans are a Class 5 Device

with leakage to Earth.

9. Your warranty will be void if a solid state dimmer or any other brand of wall controller is used.

10. The means for mains power disconnection must be incorporated in the fixed wiring in

accordance with national wiring rules.

11. To avoid possible electric shock during installation, be sure electricity is turned off at the main

power box before commencing work. Disconnect power by removing fuse or turning off circuit

breaker before installing the fan. Ensure all spliced connections are adequately insulated.

12. Warning! Do not allow the rotating fan blades to come into contact with any object, this can

cause serious injury or death.

13. Damage caused by incorrect installation, Force-majeure, lightning, electrical surges & spikes,

exposure to water, pests or moisture is not covered under warranty.

14. This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilies, or lack of experience and knowledge, unless they have been

given supervision or instrucon concerning use of the appliance by a person responsible for

their safety.

Australia, New Zealand: In accordance with AS/NZS60355-1 & ASNZS60355-2-80: “This

appliance is not intended for use by persons (including children) with reduced physical, sensory

or mental capabilies, or lack of experience and knowledge, unless they have been given

supervision or instrucon concerning use of the appliance by a person responsible for their

safety. Children should be supervised to ensure that they do not play with the appliance.”

This fan must be installed by a licensed and qualiﬁed

electrician according to local authority regulaons.

Contents

Important Information............................................................................................................................... 1

Contents................................................................................................................................................... 2

Unpacking your Fan ................................................................................................................................. 3

Installing your Fan .................................................................................................................................... 4

STEP1 Mounting the Hanger Bracket to Ceiling .................................................................................. 4

STEP 2 Connecting Mains Power to Terminal Block ........................................................................... 4

STEP 3 Inserting Fan Motor into Hanger Bracket ................................................................................ 5

STEP 4 Installing Receiver into Hanger Bracket................................................................................... 5

STEP 5 Connecting Receiver ............................................................................................................... 6

STEP 6 Pairing the Remote Control / Controlling the Fan.................................................................... 7

STEP 7 Attaching the Fan Motor Housing............................................................................................ 8

STEP 8 Assembling the Fan Blades .................................................................................................. 8,9

STEP 9 Attaching the Fan Blades ........................................................................................................ 9

Option A - LED Light Kit......................................................................................................................... 10

Option B - Ceiling Extension Kit............................................................................................................. 10

Option C - Raked Ceiling Kit .................................................................................................................. 11

Technical Specification .......................................................................................................................... 12

Care and Cleaning.................................................................................................................................. 13

Troubleshooting ..................................................................................................................................... 13

If the fan is noisy................................................................................................................................. 13

If the fan rotates but does not create much airflow............................................................................ 13

General Information................................................................................................................................ 14

Normal Wear and Tear........................................................................................................................ 14

Ceiling Fan Warranty .............................................................................................................................. 14

Transfer of Warranty ........................................................................................................................... 15

The following is NOT covered by warranty......................................................................................... 15

Aeratron ceiling fan warranty details ...................................................................................................... 16

For any problems found during fan installaon

please contact the naonal distributor/retailer and

ask for assistance before leaving the site.

IMPORTANT
