Seite 1/84
AEG GRID-TIED SOLAR INVERTERS
INVERTER SERIES:
AS-IR02-2
QUICK INSTALLATION GUIDE
AS-IR02-3000-2 | AS-IR02-3600-2 | AS-IR02-4200-2 |
AS-IR02-5000-2 | AS-IR02-6000-2 | SINGLE PHASE, 2 MPPT
VERSION: PD202206 V1-22
AEG QUICK INSTALLATION GUIDE | INVERTER SERIES AS-IR02-2 VERSION: PD202206 V1-22 2
Thank you for choosing the reliability of AEG grid-tied solar inverters. This guide is intended
for distributors and installers involved in the planning, installation and commissioning of
photovoltaic systems. AEG grid-tied solar inverters are tested and approved by acknowledged
independent certification authorities and can only be installed by qualified professional
companies. Please observe the standards and regulations applying to photovoltaic systems in
the relevant countries, as well as the rules of the employers’ liability insurance associations for
accident protection. Failure to comply with these can result in major injuries and damage. Keep
this guide in a safe place for further reference as it contains important information for product
care, maintenance and disposal.
1. Safety precautions | Мерки за безопасност | Bezpečnostní opatření
| | | | Sikkerhedsforholdsregler Sicherheitshinweise Μέτρα προφύλαξης
Precauciones de seguridad Ohutusjuhised Varotoimenpiteet Consignes | | |
de sécurité Sigurnosne mjere opreza Biztonsági óvintézkedések Misure di | | |
sicurezza | Saugos reikalavimai Drības pasākumi Veiligheidsmaatregelen | | |
Środki ostrożności Precauções de segurança | | Atenționări privind siguranța |
Bezpečnostné opatrenia Varnostni ukrepi | | Säkerhetsreskrifter
Table of contents | | Obsah | Indholdsfortegnelse |Съдържание |
Inhaltsverzeichnis | Πίνακας περιεχομένων | Tabla de contenidos | Sisukord |
Sisällysluettelo | Table des matières | Sadržaj | Tartalomjegyzék | Indice dei
contenuti | Satura rādītājs | Turinys | Inhoudsopgave | Spis treści | Índice
| Cuprins | Obsah | Kazalo | Innehållsförteckning |
1. Safety precautions ...2 FR ...30 SK ...60
EN ...3 HR ...33 SL ...63
BG ...6 HU ...37 ...66SV
CZ ...9 IT ...39 2. Product introduction ...69
DA ...12 ...42 3. Inverter installation ...70LT
DE ...15 ...45 4. Electrical connection ...73LV
EL ...18 NL ...48 5. Power on / o ...80
ES ...21 PL ...51 6. Commissioning ...81
ET ...24 ...54 7. Further information ...82PT
FI ...27 ...57RO
AEG QUICK INSTALLATION GUIDE | INVERTER SERIES AS-IR02-2 VERSION: PD202206 V1-22 3
EN | 1. SAFETY PRECAUTIONS
1.1 General Disclaimer
The information in this quick installation guide is subject due to change to product updates or other reasons. This
guide cannot replace the product labels or the safety precautions in the user manual unless otherwise specified. All
descriptions here are for guidance only.
Before installations, read through the quick installation guide. For additional information, please see the user
manual.
All operations should be performed trained by and knowledgeable technicians who are
familiar with local standards and safety regulations.
Check the deliverables for correct model, complete contents, and intact appearance. Contact the manufacturer if any
damage is found or any component is missing.
Use insulating tools and wear when personal protective equipment operating the equipment to ensure personal
safety. Wear anti components to protect the inverter -static gloves, clothes, and wrist strip when touching electronic
from damage. The manufacturer shall not be liable for any damage caused by static electricity.
Strictly follow the installation, in operation, and configuration instructions this guide and user manual. The
manufacturer shall not be liable for equipment damage or personal injury if you do not follow the instructions. For
more warranty details, please visit -industrialsolar.de/service/downloads/https://www.aeg
1.2 Safety Disclaimer
Warning
DC Side:
1. Ensure the component frames and the bracket system are securely grounded.
2. Connect the DC cables using the delivered PV connectors. The manufacturer shall not be liable for equipment
damage if other connectors are used.
3. Ensure the DC are securely, cables connected tightly, and correctly. Inappropriate wiring may cause poor
contacts or high impedances, and damage the inverter.
4. Measure the DC cable using the multimeter to avoid reverse polarity connection. Also, the voltage should be under
the max DC input voltage. The not manufacturer shall be liable for the damage caused by reverse connection and
extremely high voltage.
5. The PV modules used with the inverter must have an IEC61730 class A rating.
AC Side:
1. The voltage and frequency at the connecting point should meet the on-grid requirements.
2. Additional protective devices like circuit breakers or fuses are recommended on the AC side. Specification of the
protective device should be at least 1.25 times the rated AC output rated current.
3. PE cable of the inverter must be connected firmly. The resistance between neutral wire the and the earth cable is
less than 10Ω.
4. You are recommended AC output to use copper cables as cables. If you prefer aluminum
cables, remember to use copper to aluminum adapter terminals.
