8Megapixel
Day&NightwithSuperiorLowLightSensitivityand
AdaptiveIRLED
SuperiorWDR
EndlessPan&Tilt,PTZAutoTracking
H.265Compression
Built-inAnalytics
Eventtrigger,responseandnotification
Z954 
8MPOutdoorSpeedDomewithD/N,
AdaptiveIR,SuperiorWDR,SLLS,25x
ZoomLens
Specifications
Device
ProductType SpeedDome
MaximumResolution 8MP
ApplicationEnvironment Outdoor
ImageSensor ProgressiveScanCMOS
SensorSize 1/1.8"
EffectivePixels 3864(H)X2180(V)(8.42MP)
Day/Night Yes
LowLightSensitivity Superior
MinimumIllumination Color:0.003luxatF1.5(AGCon);B/W:0lux(IRLEDon)
ColortoB/WSwitch ISPbasedswitch,configurable
MechanicalIRCutFilter Yes
IRSensitivityRange 700-1100nm
IRLED AdaptiveIRLEDx10(850nm)
IRWorkingDistance 200m
ElectronicShutter 1-1/100000second(manualmode);1-1/100000second(automode)
SpeedDome
  •Forproductandmountingaccessoryinformation,visit:www.acti.com/productsandwww.acti.com/mountingselector
•Allspecificationsaresubjecttochangewithoutnotice.
www.acti.com
Page1of6
HorizontalResolution(TVLines) 2800TVL
S/NRatio VideoSNR:56dBAudioSNR:70dB
Lens
FocalLength Zoom,f6.0-150mm
Aperture F1.5-F3.4
ZoomRatio 25xopticalzoom,16xdigitalzoom
Iris Autoiris
Focus Autofocus
LensMount Boardmount
HorizontalViewingAngle 60.5°-3.1°
VerticalViewingAngle 36.3°-1.8°
PTZ
ManualPanning/TiltingSpeed 0.1°-200°/second,0.1°-200°/second
PresetPanning/TiltingSpeed 300°/second,240°/second
PanningRange 360°endless
TiltingRange -15°~90°(withE-flip)
PTZControl Remotemanualcontrol,1024presetpoints,16presettours
Video
Compression H.265,H.264(Highprofile),MJPEG
MaximumFrameRatevs.
Resolution
30fpsat3840x216030fpsat3072x204830fpsat2560x144030fpsat2688x152030fpsat1920x108030
fpsat1280x72030fpsat720x57630fpsat640x360
Multi-Streaming Simultaneoustriplestreams
WideDynamicRange SuperiorWDR(120dB)
ImageEnhancement WhiteBalance,Backlightcompensation(BLC),Defogging
DigitalNoiseReduction 2D+3DDNR
PrivacyMask 24configurableregions
TextOverlay Yes
Built-inAnalytics
DeepLearning:PeopleCounting,FaceDetection,PTZAutoTracking,TamperingDetection,IntrusionDetection
(ForbiddenAreaDetection),ObjectLineCrossingDetection,ObjectEnterAreaDetection,ObjectExitAreaDetection,
PeopleLineCrossingDetection,PeopleEnterAreaDetection,PeopleExitAreaDetection
ImageOrientation Flip,Mirror
Audio
AudioType 2-way,Line-in,Line-out
AudioCompression G.711u-law,G.711A-law
SpeedDome
  •Forproductandmountingaccessoryinformation,visit:www.acti.com/productsandwww.acti.com/mountingselector
•Allspecificationsaresubjecttochangewithoutnotice.
www.acti.com
Page2of6
Network
NetworkProtocol&Service IPv4,TCP,UDP,DHCP,PPPoE,HTTP,HTTPS,DNS,DDNS,NTP,RTP,RTSP,RTCP,RTMP,SMTP,FTP,IGMP,
ICMP,ARP,UPnP,QoS,SSL/TLS,IEEE802.1X
EthernetPort 1xEthernet(10/100Base-T),RJ-45pigtailconnector
Security IPaddressfiltering,HTTPSencryption,Passwordprotecteduserlevel,IEEE802.1Xnetworkaccesscontrol
Event
EventTrigger Videomotiondetection,Intelligenteventdetection,Sounddetection,Externaldevicethroughdigitalinput
EventResponse E-mailnotificationwithsnapshots,UploadsnapshottoFTPserver,Savevideoorsnapshottolocalstorage
System
SystemLog Support
Integration
ONVIFCompliant Yes,ProfileS,ProfileG,ProfileT
WebBrowser IE11,GoogleChrome,MicrosoftEdge,Firefox
SDCardBackupandRecovery AutomaticallybackupthevideorecordingsfromthememorycardofcameratoServerviaONVIF(ProfileG)
integrationwithrecoveringlostvideosafternetworkconnectionrecovery.
Interface
SerialPort 1xRS-485
AudioInterface 1/1,3.5mmPhoneJack
AnalogVideoOutput 1xBNCconnector
LocalStorage MicroSDMemoryCardSlot(cardnotincluded,upto256GB,KingstonorSandiskonly,microSDtoSDMemoryCard
Adapterisrequired.)
DigitalInput/Output 2/1
OperatingButton ResetButton
General
PowerSource AC24V,DC24V,PoEClass5(IEEE802.3bt)
PowerConsumption 58W(PoE)
Weight 5610g(12.36lb)
Dimensions (ØxH):227mmx384mm(8.9"x15.1")
EnvironmentalCasing Weatherproof(IP66)
BundledAccessories PowerAdapter
MountType WallMount,PoleMount,Pendant,CornerMount
StartingTemperature -40°C~70°C(-40°F~158°F)
OperatingTemperature -40°C~70°C(-40°F~158°F)
Approvals CEClassA,FCCClassA,IP66
Real-timeClock(RTC) Yes
SpeedDome
  •Forproductandmountingaccessoryinformation,visit:www.acti.com/productsandwww.acti.com/mountingselector
•Allspecificationsaresubjecttochangewithoutnotice.
www.acti.com
Page3of6
