IP Mini Dome 2 MPx (1080p, 4 mm)
Art. no. IPCB42510B
• 2 MPx (Full HD 1080p) resolution: 1920 x 1.080 @ 30 fps
• 4 mm fixed lens
• Ultra low-light performance for excellent results in low-light environments
• 120 dB WDR function to compensate for image contrasts
• Vandalism and weather protected housing (IK08 & IP66)
• IR LEDs (range up to 10m)
• Supports H.264, H.265, MJPEG (incl. dynamic GOP)
• microSD card slot for internal data storage
• 12 V DC & PoE (802.3af)
Due to its compact dimensions, the IP Mini Dome is a discreet surveillance camera for outdoor and indoor use.
The dome is available in several versions with different fixed lenses from 2.8 mm (IPCB42510A) to 4 mm
(IPCB42510B) and even 6mm (IPCB42510C).Discreet Full HD 24/7 outdoor surveillanceThe IP Mini Dome provides
video streams in 2 MPx resolution with up to 30 fps. The weatherproof IP66 housing allows outdoor use. Due to
integrated IR LEDs, the camera can be also used day and night. Access to the camera is possible at any time via
app.3 lens variants for maximum flexibilityThe IP Mini Dome is available in 3 versions with different fix lenses.
Therefore, the camera offers maximum flexibility in the planning and installation of video surveillance projects.
The IP Mini Dome IPCB42510A with a 2.8 mm fixed lens and a horizontal viewing angle of 108° is ideal for
wide-angle surveillance scenes. The IP Mini Dome IPCB42510C with a 6 mm fixed lens and a horizontal viewing
angle of 53° is a popular variant for installation in corridors.Recording and compatibilityThe recording can be
done either on an ABUS recorder, 3rd party video management software or locally on a microSD card.
Furthermore, the camera is compatible with the ABUS Secvest alarm center and the ABUS access control system
wAppLoxx.Comfortable installationThe IP Mini Dome is mounted on the ceiling or optionally with a bracket on
the wall. We recommend our installation box (TVAC31460) and the wall bracket (TVAC31450). The free “ABUS IP
Installer” software is available for simple setup in the network. The software finds the camera quickly and easily
within the network and supports during the installation process.ABUS Link Station App: Live Access &
Push-NotificationsThis camera is compatible with the ABUS Link Station App. The app provides easy online access
to the camera – directly without intricate adjustments or portforwarding. It also provides a simple solution for
Page 1 of 4
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 11/2023
IP Mini Dome 2 MPx (1080p, 4 mm)
Art. no. IPCB42510B
internet connections with IPv6 adresses. The app allows live view, plays recorded videos and photos and
supports push notifications in case of an event.Note: The camera does not come with a power supply, as it can
be powered via PoE.The effective IR range will depend on the installation location. If there are surfaces that
absorb light or no objects that reflect IR light in the field of view, the IR range will be reduced and/or the video
image will be too dark. Reflective objects in the immediate vicinity of the camera (e.g. roof gutter or wall) may
also result in the reflection of IR light, which can disturb the image.
Page 2 of 4
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 11/2023
IP Mini Dome 2 MPx (1080p, 4 mm)
Art. no. IPCB42510B
Technical Data:
Protection class IK 8
ONVIF Profile G, S, T
Colour RAL9003
Image enhancement WDR, BLC, HLC, 3D DNR,
Vertical Display
Video Content Analysis
(VCA)
Tripwire Detection,
Intrusion Detection
ICR day/night function Yes
Technology IP
Design Dome
Compatible with Secvest Yes
Compatible with wAppLoxxYes
Vertical viewing angle 45 °
Other functions Auto Backup Recording,
Secvest Connectivity
Compatible with wAppLoxx
Pro
Yes
Compatible with ABUS Link
Station
Yes
Dimensions (LxWxH)97x100x53 mm
Alarming E-Mail, NAS, FTP
Connections 1 x RJ45, 1 x DC
Number of users 32
Number of IR LEDs 10
Resolution 2MPx
Resolution modes Stream 1: 1.920 x 1.080 @
25 fps, Stream 2: 640 x 480
@ 25 fps, Stream 3: 1.920 x
1.080 @ 25 fps
Motion detection 8 zones
Image sensor 1/2.8" Progressive Scan
CMOS
Pixels (effective) 1920(H) x 1080(V) pixel
Frame rate 1/16, 1/8, 1/4, 1/2, 1, 2, 4, 6,
8, 10, 12, 15, 16, 18, 20, 22,
25, 30 fps
Aperture at minimum
illumination (colour)
F1.6
Width 100 mm
Focal length 4 mm
Dynamic range (WDR) 120 dB
Electronic shutter 1/3 - 1/100000 s
Functions Scene Change Detection
Backlight compensation WDR, BLC, HLC
Simultaneous network
access
6
Height 53 mm
Horizontal viewing angle 87 °
IR LEDs Yes
IR range (up to) 10 m
Camera type Mini Dome
Compatible with NVR, Hybrid DVR, IPCam
Plus
Length 97 mm
Power consumption 9,5 W
Max. resolution @ frame
rate
1920 x 1080 @ 30 fps
Max. operating
temperature
60 °C
Max. humidity 95 %
Microphone No
Min. operating
temperature
-30 °C
Minimum illumination
(colour)
0,009 lx
Minimum illumination (IR) 0 lx
Net weight 0,4 kg
Video network bandwidth32 kBit/s - 16 MBit/s
Network access RJ45
LAN network access RJ45 10M/100M
self-adaptive
Network camera protocols IPv4/v6, HTTP, HTTPS, FTP,
SMTP, UPnP, DNS, DynDNS,
NTP, RTSP, TCP, UDP, DHCP,
ONVIF Profile S, ONVIF
Profile G, ABUS Server,
Secvest Link
Lens Fix
Lens mount M12
PoE standard IEEE 802.3af
Private zones 4
Noise reduction 3D DNR
Page 3 of 4
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 11/2023
