1
EN
DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on:
www.whirlpool.eu/register
You can download the Safety Instructions and the Use
and Care Guide, by visiting our website
http://docs.whirlpool.eu and following the Instructions
on the back of this booklet.
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
APPLIANCE
1.Upper rack
2.
Cutlery rack
3.Foldable flaps
4.Upper rack height adjuster
5.Upper spray arm
6.Lower rack
7.Space Zone
8.Lower spray arm
9.Filter Assembly
10.Salt reservoir
11.Detergent and Rinse Aid dispensers
12.Rating plate
13.Control panel
0000 000 00000
Service:
1
4
5
6
11
13
7
12
10
8
9
2
3
CONTROL PANEL
1. On-Off/Reset button with indicator light
2.
Program selection button with indicator light
3.
Multizone button with indicator light
4. Turbo button with indicator light / Key lock
5. Eco program indicator light
6. Key lock indicator light
7. Display
8.
Program number and remaining time indicator
9. Tablet (Tab) indicator light
10. Closed water tap indicator light
11. Rinse Aid refill indicator light
12. Salt refill indicator light
13. Power Clean button with indicator light
14. Tablet (Tab) button with indicator light
15. Delay button with indicator light
16. Start/Pause button with indicator light / Drain out
4
1
32
9 16
14 15
65 7 8 1112 1310
2
FIRST TIME USE
SALT, RINSE AID AND DETERGENT
ADVICE REGARDING THE FIRST TIME USE
After installation, remove the stoppers from the racks and the retaining
elastic elements from the upper rack.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and
on the machineā€™s functional components.
ā€¢ It is important that the salt reservoir be never empty.
ā€¢ It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher (see
PRODUCT DESCRIPTION) and should be filled when the SALT REFILL
indicator light in the control panel is lit.
1.Remove the lower rack and unscrew the
reservoir cap (anticlockwise).
2.Position the funnel
(see figure)
and fill the salt
reservoir right up to its edge (approximately 1 kg);
it is not unusual for a little water to leak out.
3.Remove the funnel and wipe any salt residue
away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get
into the container during the wash program (this could damage the
water softener beyond repair).
Whenever you need to add salt, we recommend carrying out the
procedure before the washing cycle is started.
SETTING THE WATER HARDNESS
To allow the water softener to work in a perfect way, it is essential that
the water hardness setting is based on the actual water hardness in
your house. This information can be obtained from your local water
supplier.
The factory setting is for average (3) water hardness.
ā€¢ Switch on the appliance by pressing the ON/OFF button.
ā€¢ Switch off the appliance by pressing the ON/OFF button.
ā€¢ Hold down button START/PAUSE for 5 seconds, until you hear a
beep.
ā€¢ Switch on the appliance by pressing the ON/OFF button.
ā€¢
The current selection level number and the salt indicator light both flash.
ā€¢ Press button P to select the desired hardness level (see WATER
HARDNESS TABLE).
ā€¢ Switch off the appliance by pressing the ON/OFF button.
Setting is complete!
As soon as this procedure is complete, run a program without loading.
Only use salt that has been specifically designed for dishwashers.
After the salt has been poured into the machine, the SALT REFILL
indicator light switches off.
If the salt container is not filled, the water softener and the heating
element may be damaged as a result .
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dispenser A should
be filled when the RINSE AID REFILL indicator light in the control
panel is lit.
1. Open the dispenser
B
by pressing and pulling up the tab on the lid.
2. Carefully introduce the rinse aid as far as the maximum (110 ml)
reference notch of the filling space - avoid spilling it. If this happens,
clean the spill immediately with a dry cloth.
3. Press the lid down until you hear a click to close it.
NEVER pour the rinse aid directly into the tub.
ADJUSTING THE DOSAGE OF RINSE AID
If you are not completely satisfied with the drying results, you can ad-
just the quantity of rinse aid used.
ā€¢ Switch the dishwasher on using the ON/OFF button.
ā€¢ Switch it off using the ON/OFF button.
ā€¢ Press button
START/PAUSE
three times - a beep will be heard.
ā€¢ Switch it on using the ON/OFF button.
ā€¢ The current selection level number and rinse aid indicator light flash.
ā€¢ Press button P to select the level of rinse aid quantity to be
supplied.
ā€¢ Switch it off using the ON/OFF button
Setting is complete!
If the rinse aid level is set to 1 (ECO), no rinse aid will be supplied. The
LOW RINSE AID indicator light will not be lit if you run out of rinse aid.
A maximum of 4 levels can be set according to the dishwasher model.
The factory setting is for a medium level.
ā€¢ If you see bluish streaks on the dishes, set a low number (2-3).
ā€¢ If there are drops of water or limescale marks on the dishes, set a
high number (4-5).
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser
use the opening device A. Introduce
the detergent into the dry dispenser
B only. Place the amount of
detergent for pre-washing directly
inside the tub.
1.When measuring out the detergent
refer to the
(see PROGRAMS TABLE)
to
add the proper quantity.
Compartment
B
comprises a level
showing the maximum quantity of liquid or powder detergent that
can be added to each cycle.
2. Remove detergent residues from the edges of the dispenser and
close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the
closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program.
If all-in-one detergents are used, we recommend using the
TABLET
button, because it adjusts the program so that the best washing and
drying results are always achieved.
Water Hardness Table
Level Ā°dH
German degrees
Ā°fH
French degrees
1 Soft 0 - 6 0 - 10
2 Medium 7 - 11 11 - 20
3 Average 12 - 17 21 - 30
4 Hard 17 - 34 31 - 60
5 Very hard 35 - 50 61 - 90
M
A
X
A
B
35
25
A
B
3
EN
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 50242.
*) Not all options can be used simultaneously.
**) The duration of the program shown on the display or in the booklet is an estimate calculated on standard conditions. The actual time may vary
depending on many factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load,
load balancing, additional selected options and sensor calibration. The sensor calibration can increase program duration up to 20 min.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
PROGRAMS DESCRIPTION
Instructions on wash cycle selection.
ECO
Normally soiled crockery. Standard program, the most efficient in terms
of its combined energy and water consumption.
6th SENSE Ā®
For normally soiled dishes with dried food residues. Senses the level of
soiling on the dishes and adjusts the program accordingly. When the
sensor is detecting the soil level an animation appears in the display
and the cycle duration is updated.
1 HOUR WASH & DRY
Light to normally soiled crockery. Everyday program suitable for non-dried
and fresh soiling, assuring clean and dried dishes in just 60 min of time.
INTENSIVE
Program recommended for heavily soiled crockery, especially suitable
for pans and saucepans (not to be used for delicate items).
DAILY
Normally soiled crockery. Everyday cycle, that ensures optimal cleaning
performance in shorter time.
SILENT
Suitable for night-time operation of the appliance. Optimum
performance ensured.
RAPID 30ā€™
Program to be used for lightly-soiled dishes with no dried food
residues. (Ideal for 2 place settings).
CRISTAL
Cycle for delicate items, which are more sensitive to high temperatures,
for example glasses and cups.
PRE-WASH
Crockery to be washed later. No detergent to be used with this
program.
SANITIZING
Normally or heavily soiled crockery, with additional antibacterial wash.
SELF-CLEAN
Program to be used to perform maintenance of the dishwasher. It
cleans the interior of the appliance using hot water.
Notes:
Optimum performance levels when using the ā€œ1 Hourā€ and ā€œRapidā€
programs can be achieved by observing the maximum amounts of
specified place settings.
To reduce consumption even further, only run the dishwasher
when it is full.
Program
Drying
phase
Available options *)
Detergent
container Duration of
wash program
(h:min)**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
Tub B
1. Eco 50Ā° 3:40 9,5 0,83
2. 6th Sense 50-60Ā° 1:25 - 3:00 7,0 - 14,0 0,9 - 1,40
3. 1h Wash&Dry 55Ā° - 1:00 10,5 1,20
4. Intensive 65Ā° - 2:50 16 1,60
5. Daily 50Ā° - 1:30 13 1,15
6. Silent 50Ā° - 3:30 15 1,15
7. Rapid 30ā€™ 50Ā° - - 0:30 9 0,55
8. Cristal 45Ā° - 1:40 11,5 1,20
9. PreWash - - - - 0:12 4,5 0,01
10. Sanitizing 65Ā° - 1:40 10 1,30
11. Self- Clean 65Ā° - - 0:50 8 0,85

Produktspezifikationen

Marke: Whirlpool
Kategorie: SpĆ¼lmaschine
Modell: WFO 3T333 DL X

Brauchst du Hilfe?

Wenn Sie Hilfe mit Whirlpool WFO 3T333 DL X benƶtigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung SpĆ¼lmaschine Whirlpool

Whirlpool

Whirlpool ADG 522 IX Bedienungsanleitung

12 Oktober 2024
Whirlpool

Whirlpool WFC 3C26 P IS Bedienungsanleitung

9 Oktober 2024
Whirlpool

Whirlpool WRIC 3C26 Bedienungsanleitung

7 Oktober 2024
Whirlpool

Whirlpool WFC 3C33 PF UK Bedienungsanleitung

7 Oktober 2024
Whirlpool

Whirlpool DU5000XL0 Bedienungsanleitung

7 Oktober 2024
Whirlpool

Whirlpool ADG 4820 Bedienungsanleitung

5 Oktober 2024
Whirlpool

Whirlpool WFO 3O32 P UK Bedienungsanleitung

23 September 2024
Whirlpool

Whirlpool WDF130PAHS Bedienungsanleitung

23 September 2024
Whirlpool

Whirlpool ADG 8516/1 Bedienungsanleitung

20 September 2024
Whirlpool

Whirlpool ADG 8732 NB Bedienungsanleitung

18 September 2024

Bedienungsanleitung SpĆ¼lmaschine

Neueste Bedienungsanleitung fĆ¼r -Kategorien-

Bauknecht

Bauknecht GSXK 5011 A+ Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia DWI4108 Bedienungsanleitung

16 Oktober 2024
Neff

Neff S155EVX04E Bedienungsanleitung

16 Oktober 2024
Neff

Neff S255EVX04E Bedienungsanleitung

16 Oktober 2024
Neff

Neff S145EVS04E Bedienungsanleitung

16 Oktober 2024
V-ZUG

V-ZUG GS60Ni3n Bedienungsanleitung

15 Oktober 2024
Grundig

Grundig GNUP4530W Bedienungsanleitung

15 Oktober 2024
Grundig

Grundig GNLP4620X Bedienungsanleitung

15 Oktober 2024
Grundig

Grundig GNUP3540W Bedienungsanleitung

15 Oktober 2024
Royal Catering

Royal Catering RCDW-06 Bedienungsanleitung

15 Oktober 2024
