SAFETY INSTRUCTIONS IMPORTANT TO BE READ AND OBSERVED
EN
Download the complete instruction manual on
http: // docs . whirlpool . eu
or call the phone number
shown on the warranty booklet.
Before using the appliance, read these safety
instructions. Keep them nearby for future reference.
These instructions and the appliance itself provide
important safety warnings, to be observed at all times.
The manufacturer declines any liability for failure to
observe these safety instructions, for inappropriate
use of the appliance or incorrect setting of controls.
These instructions are valid if the country symbol
appears on the appliance. If the symbol doesn’t
appear on the appliance, it is necessary to refer to
the technical instructions which will provide the
necessary instructions concerning modication of
the appliance to the conditions of use of the country.
CAUTION: The use of the gas cooking appliance
results in the production of heat, moisture and
products of combustion in the room in which it is
installed. Ensure that the kitchen is well ventilated
especially when the appliance is in use: keep natural
ventilation holes open or install a mechanical
ventilation device (mechanical extractor hood).
Prolonged intensive use of the appliance may call
for additional ventilation, for example opening of
the window, or more eective ventilation,increasing
the level of mechanical ventilation where present.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements. Children less than
8 years of age must be kept away unless continuously
supervised.
WARNING: If the hob surface is cracked, don’t use
the appliance – risk of electrical shock.
WARNING: Danger of re: Do not store items on
the cooking surfaces.
CAUTION: The cooking process has to be
supervised. A short cooking process has to be
supervised continuously.
WARNING: Unattended cooking on a hob with
fat or oil can be dangerous – risk of re. NEVER try to
extinguish a re with water, but switch o the
appliance and then cover ame e.g. with a lid or a
re blanket.
Do not use the hob as a work surface or support.
Keep clothes or other ammable materials away
from the appliance, until all the components have
cooled down completely – risk of re.
If the information in this manual is not followed
exactly, a re or explosion, may result causing
property damage or injury.
Very young children (0-3 years) should be kept
away from the appliance. Young children (3-8 years)
should be kept away from the appliance unless
continuously supervised. Children from 8 years old
and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge can use this appliance only if they
are supervised or have been given instructions on
safe use and understand the hazards involved.
Children must not play with the appliance. Cleaning
and user maintenance must not be carried out by
children without supervision.
CAUTION: In case of hotplate glass breakage:-
shut immediately oall burners and any electrical
heating element and isolate the appliance from the
power supply; - do not touch the appliance surface;
-do not use the appliance.
The glass lid can break in if it is heated up. Turn oall
the burners and the electric plates before closing
the lid. Do not shout down lid when burner alight.
PERMITTED USE
CAUTION: the appliance is not intended to be
operated by means of an external switching device,
such as a timer, or separate remote controlled system.
This appliance is intended to be used in household
and similar applications such as: stakitchen areas
in shops, oces and other working environments;
farm houses; by clients in hotels, motels, bed &
breakfast and other residential environments.
No other use is permitted (e.g. heating rooms).
This appliance is not for professional use. Do not
use the appliance outdoors.
Use pots and pans with bottoms the same width
as that of the burners or slightly larger (see specic
table). Make sure pots on the grates do not protrude
beyond the edge of the hob.
Improper use of the grids can result in damage to
the hob: do not position the grids upside down or
slide them across the hob.
Do not let the burnerame extend beyond the edge of the pan.
If the hob surface is in glass material, do not use the cast iron griddles, ollar
stones, terracotta pots and pans.
Do not use: heat diusers such as metal mesh, or any other types; two
burners simultaneously for one receptacle (e.g. Fish kettle).
Should particular local conditions of the delivered gas make the ignition of
burner dicult, it is advisable to repeat the operation with the knob turned
to small ame setting.
In case of installation of a hood above the cooktop, please refer to the hood
instructions for the correct distance.
The protective rubber feet on the grids represent a chocking hazard for
young children. After removing the grids, please ensure that all the feet are
correctly tted.
INSTALLATION
The appliance must be handled and installed by
two or more persons - risk of injury. Use protective
gloves to unpack and install - risk of cuts.
Installation, including water supply (if any) and
electrical connections, and repairs must be carried
out by a qualied technician. Do not repair or replace
any part of the appliance unless specically stated in
the user manual. Keep children away from the
installation site. After unpacking the appliance, make
sure that it has not been damaged during transport.
In the event of problems, contact the dealer or your
nearest After-sales Service. Once installed, packaging
waste (plastic, styrofoam parts etc.) must be stored
out of reach of children - risk of suocation. The
appliance must be disconnected from the power
supply before any installation operation - risk of
electrical shock. During installation, make sure the
appliance does not damage the power cable - risk of
re or electrical shock. Only activate the appliance
when the installation has been completed.
The electrical and gas connections must comply
with local regulation.
WARNING: Modication of the appliance and its
method of installation are essential in order to use
the appliance safely and correctly in all the additional
countries.
Use pressure regulators suitable for the gas
pressure indicated in the instruction.
The room must be equipped with an air extraction
system that expels any combustion fumes.
The room must also allow proper air circulation,
as air is needed for combustion to occur normally.
The ow of air must not be less than 2 m
3/h per kW
of installed power.
The air circulation system may take air directly
from the outside by means of a pipe with an inner
cross section of at least 100 cm
2; the opening must
not be vulnerable to any type of blockages.
The system can also provide the air needed for
combustion indirectly, i.e. from adjacent rooms
tted with air circulation tubes as described above.
However, these rooms must not be communal
rooms, bedrooms or rooms that may present a re
hazard.
Liquid petroleum gas sinks to the oor as it is
heavier than air. Therefore, rooms containing LPG
cylinders must also be equipped with vents to allow
gas to escape in the event of a leak. As a result LPG
cylinders, whether partially or completely full, must
not be installed or stored in rooms or storage areas
that are below ground level (cellars, etc.). It is
advisable to keep only the cylinder being used in
the room, positioned so that it is not subject to heat
produced by external sources (ovens, replaces,
stoves, etc. ) which could raise the temperature of
the cylinder above 50°C.
Carry out all cabinet cutting works before tting
the appliance in the furniture and remove all wood
chips and sawdust.
If the appliance is Not installed above an oven, a
separator panel (not included) must be installed in
the compartment under the appliance.
Should you experience diculty in turning the burners knobs, please
contact After Sales Service for replacement of the burner tap if found to be
faulty.
The openings used for the ventilation and dispersion of heat must never
be covered.
GAS CONNECTION
WARNING: Prior to installation, ensure that the local
distribution conditions (nature of gas and gas pressure)
and the adjustment of the appliance are compatible.
Check that the pressure of the gas supply is
consistent with the values indicated in Table 1
(“Burner and nozzle specications”).
WARNING: The adjustment conditions for this
appliance are stated on the label (or data plate).
WARNING: This appliance is not connected to a
combustion products evacuation device. It shall be
installed and connected in accordance with current
installation regulations. Particular attention shall be
given to the relevant requirements regarding
ventilation.
If the appliances is connected to liquid gas, the
regulation screw must be fasted as tightly as possible.
IMPORTANT: When gas cylinder is adopted, the
gas cylinder or gas container must be properly
settled (vertical orientation).
WARNING: This operation must be performed by
a qualied technician
Use only exible or rigid metal hose for gas
connection.
Connection with a rigid pipe (copper or steel)
Connection to the gas system must be carried out in
such a way as not to place any strain of any kind on
the appliance. There is an adjustable L-shaped pipe
tting on the appliance supply ramp and this is
tted with a seal in order to prevent leaks. The seal
must always be replaced after rotating the pipe
tting (the seal is provided with the appliance). The
gas supply pipe tting is a threaded 1/2 gas
cylindrical male attachment.
Connecting a exible jointless stainless steel pipe
to a threaded attachment. The gas supply pipe tting
is a threaded 1/2 gas cylindrical male attachment.
These pipes must be installed so that they are never
longer than 2000 mm when fully extended. Once
connection has been carried out, make sure that the
exible metal pipe does not touch any moving parts
and is not compressed. Only use pipes and seals that
comply with current National regulations.
IMPORTANT: If a stainless steel hose is used, it
must be installed so as not touch any mobile part of
the furniture (e.g. drawer). It must pass through an
area where there are no obstructions and where it is
possible to inspect it on all its length.
The appliance should be connected to the main
gas supply or to gas cylinder in compliance with the
current National regulations. Before carry out the
connection, make sure that the appliance is compatible
with the gas supply you wish to use. If this is not the
case, follow the instructions indicated in the paragraph
“Adapting to dierent types of gas”.
After connection to the gas supply, check for
leaks with soapy water. Light up the burners and
turn the knobs from max position 1* to minimum
position 2* to check ame stability.
ADAPTING TO DIFFERENT TYPES OF GAS
In order to adapt the appliance to a type of gas
other than the type for which it was manufactured
(indicated on the rating label), follow the dedicated
steps provided after installation drawings.
ELECTRICAL WARNINGS
IMPORTANT: The data relevant to the voltage an
power absorption are indicated on the rating plate.
The power cable must be long enough to connect
the appliance, once tted in its housing, to the main
power supply. Do not pull the power supply cable.
It must be possible to disconnect the appliance
from the power supply by unplugging it if plug is
accessible, or by a multi-pole switch installed
upstream of the socket in accordance with the
wiring rules and the appliance must be earthed in
conformity with national electrical safety standards.
Do not use extension leads, multiple sockets or
adapters. The electrical components must not be
accessible to the user after installation. Do not use
the appliance when you are wet or barefoot. Do not
operate this appliance if it has a damaged power
cable or plug, if it is not working properly, or if it has
been damaged or dropped.
If the supply cord is damaged, it must be replaced
with an identical one by the manufacturer, its service
agent or similarly qualied persons in order to avoid
a hazard - risk of electrical shock.
CLEANING AND MAINTENANCE
WARNING: Ensure that the appliance is switched
o and disconnected from the power supply before
performing any maintenance operation; never use
steam cleaning equipment - risk of electric shock.
Do not use abrasive or corrosive products,
chlorine-based cleaners or pan scourers.
DISPOSAL OF PACKAGING MATERIALS
The packaging material is 100% recyclable and is marked with the recycle
symbol .
The various parts of the packaging must therefore be disposed of responsibly
and in full compliance with local authority regulations governing waste
disposal.
DISPOSAL OF HOUSEHOLD APPLIANCES
This appliance is manufactured with recyclable or reusable materials.
Dispose of it in accordance with local waste disposal regulations. For
further information on the treatment, recovery and recycling of household
electrical appliances, contact your local authority, the collection service
for household waste or the store where you purchased the appliance. This
appliance is marked in compliance with European Directive 2012/19/EU,
Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent
negative consequences for the environment and human health.
The symbol on the product or on the accompanying documentation
indicates that it should not be treated as domestic waste but must be
taken to an appropriate collection center for the recycling of electrical and
electronic equipment.
ENERGY SAVING TIPS
Use pots and pans with bottom width equal to that of the cooking zone.
Only use at-bottomed pots and pans.
When possible, keep pot lids on during cooking.
Use a pressure cooker to save even more energy and time.
Place the pot in the middle of the cooking zone marked on the hob.
DECLARATION OF CONFORMITY
This appliance meets the Ecodesign requirements set out in European
Regulation n.66/2014, in conformity to the European standard EN 30-2-1.
INJECTORS TABLE CATEGORY I
2H
Type of gas used Type of burner Injector
marking
Rated thermal
ow rate
kW
Rated
consumption
Reduced heat
capacity
kW
Gas pressure
mbar
min. rat. max.
NATURAL GAS
(Methane) G20
Rapid
Semi-rapid
Auxiliary
125
100
72
3,00
1,90
1,00
286 l/h
181 l/h
95 l/h
1,00
0,80
0,50
17 20 25
Type of gas used Model conguration
5 BURNERS
Rated thermal ow rate
(kW)
Total rated
consumption
Air required (m3) for burning
1m
3
of gas
G20 20 mbar 1R - 2 SR - 2 AUX 838 l/h8,8 9,52
ELECTRIC SUPPLY: 220-240 V ~ 50-60 Hz - 0,6W

Produktspezifikationen

Marke: Whirlpool
Kategorie: Ofen
Modell: POW 75D2/NB

Brauchst du Hilfe?

Wenn Sie Hilfe mit Whirlpool POW 75D2/NB benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Ofen Whirlpool

Whirlpool

Whirlpool RC8300XKH Bedienungsanleitung

14 Oktober 2024
Whirlpool

Whirlpool AKZM 8421 H Bedienungsanleitung

14 Oktober 2024
Whirlpool

Whirlpool W6 OM4 4S1 P BSS Bedienungsanleitung

14 Oktober 2024
Whirlpool

Whirlpool ACM 790/NE Bedienungsanleitung

9 Oktober 2024
Whirlpool

Whirlpool RC8536XTN1 Bedienungsanleitung

8 Oktober 2024
Whirlpool

Whirlpool AKZM 753/IX Bedienungsanleitung

8 Oktober 2024
Whirlpool

Whirlpool AKP 286/IX/03 Bedienungsanleitung

7 Oktober 2024
Whirlpool

Whirlpool AKM 206/AR Bedienungsanleitung

5 Oktober 2024
Whirlpool

Whirlpool ACM 816/BA/N Bedienungsanleitung

4 Oktober 2024
Whirlpool

Whirlpool W10536162 Bedienungsanleitung

2 Oktober 2024

Bedienungsanleitung Ofen

Neueste Bedienungsanleitung für -Kategorien-

Indesit

Indesit VL 22 S Bedienungsanleitung

16 Oktober 2024
Gaggenau

Gaggenau BMP225130 Bedienungsanleitung

16 Oktober 2024
Wolf

Wolf M Series Bedienungsanleitung

16 Oktober 2024
Princess

Princess 112741 Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia HR750VGTCH Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia HR750VGTAN Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia HR640VGTCO Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia HR640VGTCH Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia HR640VGTAN Bedienungsanleitung

16 Oktober 2024
Freggia

Freggia HR640VGCH Bedienungsanleitung

16 Oktober 2024
