THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance,

please register your product on

www.whirlpool.eu/register

PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.

Quick guide

Before using the appliance carefully

read the Safety Instruction.

Eco Monitor

This indicator shows the energy consumption level according to

the programme and the options set. The consumption is

proportional to the lines on the display,by the ecomonitor icon.

DAILY USE

Doing this will keep your machine working at its BEST:

- remember to empty your water tank after each drying

cycle.

- remember to clean your lters after each drying cycle.

Refer to the Care & Maintenance section.

1. Plug the dryer into the power supply socket.

2. Open the door and load garments; always refer to instructions on

clothing labels and the max loads indicated in the programme

section. Empty pockets. Make sure garments do not get caught

between the door and/or the door lter. Do not load items that

are dripping wet. Do not tumble dry large, very bulky items. For

optimal drying result, garments should be loaded one by one.

3. Close the door.

4. Press the "On/O" button.

5. Select the most suitable programme

for the type of fabric in

that load.

6. Select the options, if necessary.

7. Press the "

Start/Pause"

button to begin drying.

8. At the end of the drying cycle, a buzzer will beep. An indicator on

the control panel signals the end of the cycle. Turn the machine

o by pressing the "On/O" button, open the door and pull the

clothing immediately out to prevent the formation of creases on

laundry.

If the machine is not switched o manually, after about a quarter

of an hour from the end of the cycle , the appliance turns o

automatically to save energy.

Note that some models perform a nal cool tumble phase, for this

reason the fabrics may not feel hot.

In case of power failure, it is necessary to press the "Start/Pause"

button to restart the cycle.

CARE LABEL

Always check the care labels, especially when placing garments in

the tumble dryer for the  rst time. Below are the most commonly

used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

NAVIGATION

The " " and " " buttons serve to navigate the available UP DOWN

menus.

• Press the button to conrm the selection.

• Press the option button at the symbol , where present on the

display, to return to the previous screen.

If no selection is conrmed, after about 10 seconds, the display

return to the main screen.

SETTINGS

To access the settings menu, keep the relevant button pressed for

some seconds.

• Set language shows the available languages on the display.

• Sounds allows to enable or disable the sounds (some sounds, as

warnings, will remain active anyway).

• Brightness allows to modify the display brightness.

• Factory Default allows to reset the default settings. After having

selected the setting, keep the button pressed for some

seconds.

Opening the door during the cycle

The tumble dryer door can be opened at any time during the cycle

to check progress and remove any garments already dry.

However, since opening the door can extend the drying time, the

recommendation is to keep the door closed throughout the cycle

process to save time and energy.

After closing the door, press the "Start/Pause" button within 15

minutes to resume the machine operation.

INDICATORS

Dryness level: Iron dry - Hanger dry - Cupboard dry - Extra dry

Cycle phase: Drying - Cool down - End of cycle.

Empty water tank - Clean door lter - Clean bottom lter - Eco Monitor

Refer to troubleshooting section: Failure: Call after sales service

FIRST TIME USE

When starting the appliance for the rst time, the control panel

will show the set language menu automatically. The UP and

DOWN buttons serve to show the languages available in the

machine. Press the button to conrm. The machine cannot

be used without having selected the language. Make sure that

the water tank is correctly inserted. Make sure that the drain

hose on the back of the dryer is xed correctly, either to the

dryer’s water tank, or to your domestic sewage system.

The dryer must be installed in ambient with a temperature

range between 5-35 °C to ensure its operation.

Before you use your dryer ensure that it has been in a upright

position for at least 6 hours.

CONTROL PANEL

1 On/O button

2 Start/Pause button

Options Buttons

3 FreshCare+

4 Rapid (Add Favourite if long pressed)

5 Cycle Options (Setting if long pressed)

6 Dryness Level

7 Timed Drying

8 Start Delay

Navigation buttons and Key Lock

9 UP

10 DOWN'

11 CONFIRM (Key Lock if long pressed)

SYNTHETICS

1:35

-:-- -:--

6 7 8

PROGRAMS

The duration of these programs will depend on the size of the

load, types of textiles, the spin speed used in your washer and

any extra options selected. In machines equipped with display,

the duration of the cycles is shown on the control panel. The

remaining time is constantly checked and adjusted during the

drying cycle to show the best possible estimate.

Option to use - If all your loads on Automatic Cycles are

consistently less dry or more dry than you would like, you may

increase or decrease the dryness level using the specic option.

Eco kg Max*

This is the most ecient programme in terms of energy

consumption and is suitable for drying normal wet cotton

laundry. The values on the Energy Label are based on this

programme.

NOTE: For optimal energy eciency this cycle by default is set up to

"Cupboard Dry" level. For a higher dryness level we suggest using

the Cotton cycle.

Cotton kg Max* '

Cycle suitable for drying all types of cotton, ready to be placed

in the cupboard.

Mixed kg 4

This programme is ideal for drying cotton and synthetic

fabrics together.

Bed Linen kg Max*

This programme is intended for drying cotton sheets.

Duvet

Programme intended to dry bulky garments, as single duvet.

Shirts kg 3

This is a programme for Shirts made from cotton or cotton

blend/synthetics.

Easy Ironing

This cycle allows to extend the bres of garments thus

making ironing and folding easier. Do not use in case of garments

that are still wet. Suitable for small loads of cotton textiles or

cotton blends.

Refresh

A short programme suitable for refreshing bres and

garments by means of fresh air. Do not use with garments that are

still wet. It can be used on with any load size but is more eective

with small loads. The cycle duration is about 20 minutes.

Rapid 30' kg 0.5

Ideal for drying cotton garments spun at high speed in the

washing machine.

Sport kg 4

For drying sports garments made of synthetics or cotton.

Specials

This position allows to select among the various special

programmes. The UP/DOWN buttons serve to scroll the

programmes. Press the button to conrm the selected

programme.

• Jeans kg 3

For drying cotton jeans-wear and garments made of robust

cotton, like denim, such as trousers and jackets.

• Towel kg Max*

For drying robust laundry made of cotton, such as terry

towels.

• Tecnhical Wear kg 4

For drying technical wear made of synthetics or cotton.

• Down Jacket kg 2.5

To dry down jackets, giving their natural softness back

(2 jackets).

Favourite

This position allows to select among programmes and

corresponding options previously saved. The buttons UP/DOWN

allow to scroll the list of saved favourites. Press the button to

select and save the cycle. Use the relevant option to save the

programmes.

Wool kg 1

Programme for drying wool clothing. It is advisable to turn the

garments inside out before drying. Leave to dry naturally the

heaviest edges that are still damp.

Delicates kg 2

For drying delicate laundry which needs gentle treatment.

Synthetics kg 4

For drying laundry made of synthetic bres.

*MAX LOAD 8 Kg (Dry load)

OPTIONS

These buttons allow you to personalise the selected programme

according to personal requirements. Not all options are available

for all programmes. Some options may be incompatible with

ones you have previously set; if so, you will be alerted by the

buzzer and/or blinking indicators. If the option is available, the

option indicator will stay on. The programme may retain some

options selected in previous drying cycles.

Dryness Level

Press the relevant button several times to obtain a dierent

level of residual moisture on garments. The display will signal the

level being selected. After few seconds of inactivity, the display

returns to the main menu.

Iron Dry: a very delicate ironing. Suitable for making ironing

of garments easier immediately after the end of the cycle.

Hanger Dry: a level intended for delicate garments ready to

be hanged.

Cupboard Dry: the garments are ready to be folded and put

away.

Extra Dry: used for garments to be worn at the end of the

cycle.

Timed drying

This option allows to set the drying time. Press the

corresponding button to set the required time for drying. An

indicator on the control panel signals the time being selected.

Start Delay

This option allows you to set the delay of the cycle start. Press

the corresponding button several times to obtain the required

delay. After having reached the max. settable time, the option is

reset by pressing the button again. An indicator on the control

panel signals the time being selected. After having pressed the

button Start/Pause, the machine signals the remaining time for the

cycle start. In case of door opening, after closing, it is necessary to

press the button Start/Pause.

FreshCare+

If garments are left inside the drum after the end of the

cycle, they are subject to bacterial proliferation. This option allows

to prevent this proliferation by controlling the temperature and

the rotation of the drum. This treatment has a max. duration of 6

hours after the end of the programme set. This option remains

in memory if selected in the previous drying. If this option is

used together with the Start Delay, a crease treatment (a periodic

rotation of the drum) is added in the Start Delay phase.

Rapid

Enables quicker drying.

Add Favourite

This button allows to add the most used programmes (max.

6 - by entering the seventh one, one of the already saved

programmes will be cancelled) to “Favourite”, already inclusive of

options.

• Select the programme and the options to be saved.

• Keep the button pressed for some seconds.

• Saving is conrmed with a message on the display.

• The same programme cannot be saved twice with dierent

options.

Key Lock

This option makes all machine controls inaccessible, except the

button On/O. When the machine is on:

• to activate the option, keep the button pressed until the

machines signals that the option has been enabled.

• To disable the option, keep the button pressed until the machine

signals that the option has been disabled.

This option remains in memory if selected in the previous drying.

Cycle Option

This buttons serves to access a menu of available options (see

next options). The buttons “UP” and “DOWN” serve to scroll the

options and the button allows to conrm the selection.

Quick guide

• Cycle End Signal

This option activates a prolonged buzzer at the end of the

cycle. Enable it if you are not sure to hear the normal sound at the

end of the cycle.

After having pressed the option button, it can be enabled or

disabled using the and buttons. Press the button UP DOWN to

conrm.

This option remains in memory, if selected in the previous drying.

• Gentle

Enables a more gentle treatment of the laundry by

reducing the drying temperature.

• Anti Tangle

This option has the drum movement modied to give a

tumbling action that reduces tangling and knotting of your clothes.

This option gives best results when used with smaller loads.

Heat Pump System

The heat pump contains uorinated greenhouse gases,

contained in a hermetically sealed unit. This sealed unit contains

0.43 kg of the R134a gas. GWP = 1430 (1 t CO2).

Power consumption

o-mode (Po) - Watts 0.50

left-on mode (Pl) - Watts 2.00

Programs MinutesKg kWh

Eco * 8 1.42 165

Eco 4 0.78 96

Synthetics 4 0.94 113

*This is the reference programme for the energy label and suitable to

dry normal wet cotton laundry. This is the most ecient programme

in terms of energy consumption for drying wet cotton laundry.

(Standard/Default starting conguration).

Cleaning the tumble dryer

• The external metal, plastic and rubber parts can be cleaned

with a damp cloth.

• Clean the front air intake grille regularly (every 6 months) with

a vacuum cleaner to remove any lint, u or dust deposits.

Furthermore, remove any lint deposits from the lters area,

using a vacuum cleaner every so often.

• Do not use solvents or abrasives.

CARE AND MAINTENANCE

WARNING: unplug the dryer during the cleaning and

maintenance procedures.

Emptying the water tank after each cycle (see Fig. A).

Pull the container out of the dryer and and empty it into a

sink or other suitable drain, then place it back. Do not use the dryer

without having inserted the container back in place.

Cleaning the door lter after each cycle (see Fig. B).

Pull the lter out and clean it by removing the lint from the

lter surface under running water or using a vacuum cleaner. For

optimal performance, dry up all the lters before inserting them

back in place. Do not use the dryer without having reinserted

the lter in place.

Remove the door lter as described below:

1. Open the door and pull upwards.

2. Open the lter and remove lint from all its parts. Replace it

correctly.

Ensure it is completely inserted ush with the dryer seal.

Cleaning the bottom lter when the relevant indicator

turns on (see Fig. C).

Pull the lter out and remove the lint from its surface by washing

it under runing water or by using a vacuum cleaner.

However, it is advisable to clean this lter after each cycle to

optimise drying performance.

Do not use the dryer without having reinserted the lter in place.

Remove the bottom lter as described below:

C1. Open the bottom cover; take the handle and pull the lter out.

C2. Open the rear side of the lter and remove the lint from the

inner surface of the mesh.

C3/C4. Check the bottom lter chamber every month. If you

see residual lint accumulated on the metal ns, clean it with a

vacuum cleaner, using a nozzle with a brush.

It's crucial to do vertical movements, you may destroy the

component if you try to clean it in horizontal direction. Avoid the

direct contact of the hand with the ns - risk of cut.

C5. Close the rear side of the lter and place it back by checking it

is perfectly integrated into its seat, then lower the lter handle.

C6. Close the bottom cover.

Make sure the air intake is free.

The lters are essential parts for drying. They are intended

to collect the lint formed during the drying process. In case

of clogged lters, the air ow inside the dryer would be

seriously aected: the drying times would be longer, the

energy consumption would increase and the dryer could be

damaged. If these procedures are not carried out properly,

the dryer may not start.

NOTE: After cleaning the lters the relevant indicator remains on;

this is normal, it will disappear when you start a new drying cycle.

PRODUCT DESCRIPTION

1. Water Tank

2. Air Intake

3. Bottom lter

4. Door lter

A B

C1 C2 C3

C4 C5 C6

TRANSPORT AND HANDLING

Never lift the dryer by holding it at the worktop.

1. Unplug the dryer.

2. Remove the water from the water tank completely.

3. Make sure that door and water tank are properly closed.

4. If the drain hose is connected to your drainage system,

re-connect it to the back of the dryer (see "Installation" section

in the Safety Instruction guide).

Produktspezifikationen

Marke:	Whirlpool
Kategorie:	Wäschetrockner
Modell:	FFT D 8X3B EE

Brauchst du Hilfe?

Wenn Sie Hilfe mit Whirlpool FFT D 8X3B EE benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Wäschetrockner Whirlpool

Whirlpool FFT M11 8X3BY EE Bedienungsanleitung

15 Oktober 2024

Whirlpool 3RAWZ481E Bedienungsanleitung

14 Oktober 2024

Whirlpool DDLX 80116 Bedienungsanleitung

13 Oktober 2024

Whirlpool Green 850 Bedienungsanleitung

12 Oktober 2024

Whirlpool W6 D83WB EE Bedienungsanleitung

12 Oktober 2024

Whirlpool FFT M11 9X3BY BE Bedienungsanleitung

12 Oktober 2024

Whirlpool Boston C Bedienungsanleitung

9 Oktober 2024

Whirlpool FFT M11 9X2BXY BE Bedienungsanleitung

7 Oktober 2024

Whirlpool WGD5720RW Bedienungsanleitung

2 Oktober 2024

Whirlpool WGD5720RR Bedienungsanleitung

2 Oktober 2024

Bedienungsanleitung Wäschetrockner

Neueste Bedienungsanleitung für -Kategorien-

GE Profile PFD95GSPTDS Bedienungsanleitung

16 Oktober 2024

Maytag MGD7100DC Maxima Bedienungsanleitung

16 Oktober 2024

Bosch WTA4000 Bedienungsanleitung

16 Oktober 2024

Bauknecht TRKP 7950 Bedienungsanleitung

16 Oktober 2024

Hoover DX C9DKG-80 Bedienungsanleitung

16 Oktober 2024

Teka THPD80 Bedienungsanleitung

16 Oktober 2024

BEKO B3T41242 Bedienungsanleitung

16 Oktober 2024

BEKO BM5T49243W Bedienungsanleitung

16 Oktober 2024

BEKO B3T67110 Bedienungsanleitung

16 Oktober 2024

BEKO BM3T48249W Bedienungsanleitung

16 Oktober 2024
