THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

Quick guide

Before using the appliance carefully read the Safety

Instructions.

OPENING OF THE DOOR DURING THE CYCLE

Laundry can be checked while the drying cycle runs and any

garments already dry can be removed, while drying continues for

the remaining items. After closing the door, press the "Start/Pause"

button to resume machine operation.

Keep the door closed until the cycle end to save time and energy.

DAILY USE

Doing this will keep your machine working at its BEST:

- remember to empty your water tank after each drying cycle.

- remember to clean your lters after each drying cycle.

Refer to the Care & Maintenance section.

1. Plug the dryer into the power supply socket.

2. Open the door and load garments; always refer to instructions on

clothing labels and the max loads indicated in the programme

section. Empty pockets. Make sure garments do not get caught

between the door and/or the door lter. Do not load items that

are dripping wet. Do not tumble dry large, very bulky items.

3. Close the door.

4. Press the "On/O" button.

5. Select the most suitable programme

for the type of fabric in that

load.

6. Select the options, if necessary.

7. Press the "

Start/Pause"

button to begin drying.

8. At the end of the drying cycle, a buzzer will beep. An indicator on

the control panel signals the end of the cycle. Pull the load out

immediately to prevent the formation of creases on laundry.

9. Turn the machine o by pressing the "On/O" button, open the

door and pull the clothing out. If the machine is not switched o

manually, after about a quarter of an hour from the end of the

cycle , the appliance turns o automatically to save energy.

Note that some programme/option accords with "Crease Care"

system. This means that for some hours, after the end of the

drying cycle, the drum rotates at regular intervals to prevent the

formation of creases.

In case of power failure, it is necessary to press the "Start/Pause"

button to restart the cycle.

CARE LABEL

Always check the care labels, especially when placing garments in

the tumble dryer for the  rst time. Below are the most commonly

used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

FIRST TIME USE

Make sure that the water tank is correctly inserted. Make sure

that the drain hose on the back of the dryer is xed correctly,

either to the dryer’s water tank, or to your domestic drainage

system.

CONTROL PANEL

1 ON/OFF button (Reset if long pressed)

2 Programme selection Knob

3 Start/Pause

Options buttons*

4 Dryness level

5 Start delay

6 Timed drying

7 Cycle end

8 Rapid (Key lock if long pressed)

9 FreshCare+ (Mute if long pressed)

*Note: some models may have the wording in full instead of the icons.

INDICATORS

Dryness level: Iron dry - Hanger dry - Cupboard dry - Extra dry

Cycle phase: Drying - Cool down - End of cycle.

Empty water tank - Clean door lter - Clean bottom lter -

Refer to troubleshooting section: Failure: Call after sales service

DEMO

Demo mode

4 5 6

3’’

These buttons allow you to personalise the selected programme

according to personal requirements. Not all options are available

for all programmes. Some options may be incompatible with

ones you have previously set; if so, you will be alerted by the

buzzer and/or blinking indicators. If the option is available, the

option indicator will stay on. The programme may retain some

options selected in previous drying cycles.

PROGRAMS

Eco kg Max*

This is the most ecient programme in terms of energy

consumption and is suitable for drying normal wet cotton

laundry. The values on the Energy Label are based on this

programme.

NOTE: For optimal energy eciency this cycle by default is set up to

"Cupboard Dry" level. For a higher dryness level we suggest using

the Cotton cycle.

Cotton kg Max*

Cycle suitable for drying all types of cotton, ready to be

placed in the cupboard.

Mixed kg 4

This programme is ideal for drying cotton and synthetic

fabrics together.

Bed linen kg Max*

This programme is intended for drying cotton sheets.

Duvet

Programme intended to dry bulky items, such as a single duvet.

Shirts kg 3

This is a programme for Shirts made from cotton or cotton

blend/synthetics.

Jeans kg 3

For drying sturdy cotton including denim trousers and

jackets.

Easy ironing

This cycle relaxes bres, thus making ironing and folding

easier. Suitable for small load of damp or dry cotton and cotton

blend fabrics. Not for wet items.

Refresh

A short programme suitable for refreshing bres and

garments through the emission of fresh air. Do not use on wet

items. It can be used on with any load size but is more eective

with small loads. It lasts about 20 minutes.

Rapid 30' kg 0,5

Ideal for drying cotton garments spun at high speed in the

washing machine.

Sport kg 4

For drying synthetics or cotton sports garments.

Silk kg 0,5

Gentle drying of silk garments.

Wool kg 1

Programme for drying wool clothes. It is advisable to turn the

items inside out before drying. If heavy edges remain damp, leave

them to dry naturally.

Delicates kg 2

For drying delicate laundry requiring gentle treatment.

Synthetics kg 4

For drying synthetic fabrics.

OPTIONS

Dryness level

Press the related button several times to obtain a dierent

level of residual moisture on garments. An indicator signals the

level being selected.

Iron dry: very delicate drying. Items will be more easily

ironed immediately after the cycle.

Hanger dry: a level intended for delicate garments ready

to be hanged.

Cupboard dry: the laundry is ready to be folded and put

away.

Extra dry: for laundry intended to be worn at the end of the

cycle.

Timed drying

This option is to manually set the drying time. Press the

corresponding button to set the required time for drying. An

indicator on the control panel signals the time being selected.

Start delay

This option is for delaying the start of the cycle. Press the

corresponding button several times to nd the required delay. Once

the max time is reached, the option is reset by pressing the button

again. An indicator on the control panel signals the time being

selected. After pressing the "Start/Pause" button, the machine signals

the time remaining to the start of the cycle. If the door is opened,

press the "Start/Pause" button once the door has been closed.

Rapid

Enables quicker drying.

FreshCare+

If laundry is left inside of the drum once the cycle has

ended, it can be subjected to bacterial proliferation. This

option helps to prevent this from happening by controlling the

temperature and gently rotating the drum. This will continue for

up to 6 hours after the end of the cycle. This setting will remain in

the memory of the previous cycle. If this is used alongside Start

Delay, a crease treatment will be perfomed during this phase by

periodic rotations of the drum.

Key lock

This option makes all machine controls inaccesible, except

the "On/O" button. When the machine is on:

• to activate the option, keep the button pressed until the

machines signals that the option has been enabled.

• to disable the option, keep the button pressed until the machine

signals that the option has been disabled.

This option remains in memory if selected in previous drying.

Cycle end

This option activates a prolonged buzzer at the end of the

cycle. Enable it if you are not sure to hear the normal sound at the

end of the cycle. This option remains in memory if selected in the

previous drying.

Mute

This option turns o all sounds of control panel. Only

warnings remain active.

• to activate the option, keep the button pressed until the

indicator goes on.

• to disable the option, keep the button pressed until the indicator

goes o.

The duration of these programs will depend on the size of the

load, types of textiles, the spin speed used in your washer and

any extra options selected. In machines equipped with display,

the duration of the cycles is shown on the control panel. The

remaining time is constantly checked and adjusted during the

drying cycle to show the best possible estimate.

Option to use - If all your loads on Automatic Cycles are

consistently less dry or more dry than you would like, you may

increase or decrease the dryness level using the specic option.

*MAX LOAD 8 Kg (Dry load)

Quick guide

Power consumption

o-mode (Po) - Watts 0.50

left-on mode (Pl) - Watts 1.00

Programs MinutesKg kWh

Eco Cotton * 8 4.74 130

Eco Cotton 4 2.59 80

Synthetics 4 1.84 90

*This is the reference programme for the energy label and suitable to

dry normal wet cotton laundry. This is the most ecient programme

in terms of energy consumption for drying wet cotton laundry.

(Standard/Default starting conguration).

Cleaning the tumble dryer

• The external metal, plastic and rubber parts can be cleaned

with a damp cloth.

• Clean the front air intake grille regularly (every 6 months) with

a vacuum cleaner to remove any lint, u or dust deposits.

Furthermore, remove any lint deposits from the lters area,

using a vacuum cleaner every so often.

• Do not use solvents or abrasives.

CARE AND MAINTENANCE

WARNI NG: unplug the dryer during the cleaning and

maintenance procedures.

Emptying the water tank after each cycle (see Fig. A).

Pull the container out of the dryer and empty it into a sink or other

suitable drain, then place it back properly. Do not use the dryer

without having inserted the container back in place.

Cleaning the door lter after each cycle (see Fig. B).

Pull the lter out and clean it by removing the lint from the lter

surface under running water or using a vacuum cleaner. For optimal

performance, dry up the lter before inserting it back in place.

Do not use the dryer without having reinserted the lter in place.

Remove the door lter as described below:

1. Open the door and pull the lter upwards.

2. Open the lter and remove the lint from all its parts. Replace the

lter correctly making sure it is fully seated.

Cleaning the bottom lter when the relevant indicator

turns on (see Fig. C).

Pull the lter out and remove the lint from its surface by washing

it under runing water or by using a vacuum cleaner.

However, it is advisable to clean this lter after each cycle to

optimise drying performance.

Do not use the dryer without having reinserted the lter in place.

Remove the bottom lter and the condenser as described

below:

1. Open the bottom cover.

2. Take the handle and pull the lter out.

3. Open the rear side of the lter and remove the lint from the

inner surface of the mesh.

4. Clean the lter chamber (there might be residual water: this is

normal).

5. Approximately every 3 months, clean the condensing unit

(gure D) situated behind the bottom lter.

• Lower the levers situated on the sides of the condenser.

Pull the handle to remove the condenser and clean it under

running water.

• Put the the condenser back in place and lift the levers.

6. Close the rear side of the lter and place it back by checking it

is perfectly integrated in place.

7. Lower the lter handle and close the bottom cover.

8. Make sure the air intake is free.

PRODUCT DESCRIPTION

1. Water Tank

2. Air Intake

3. Bottom lter and condenser

4. Door lter

The lters are essential parts for drying. They are intended

to collect the lint formed during drying process. In case

of clogged lters, the air ow inside the dryer would be

seriously aected: the drying times would be longer, the

energy consumption would increase and the dryer could be

damaged. If these procedures are not carried out properly,

the dryer may not start.

A B

C D

TRANSPORT AND HANDLING

Never lift the dryer by holding it at the worktop.

1. Unplug the dryer.

2. Remove the water from the water tank completely.

3. Make sure that door and water tank are properly closed.

4. If the drain hose is connected to your drainage system,

re-connect it to the back of the dryer (see "Installation" section

in the Safety Instruction guide).

Produktspezifikationen

Marke:	Whirlpool
Kategorie:	Wäschetrockner
Modell:	FFT CM11 8B

Brauchst du Hilfe?

Wenn Sie Hilfe mit Whirlpool FFT CM11 8B benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Wäschetrockner Whirlpool

Whirlpool FFT M11 8X3BY EE Bedienungsanleitung

15 Oktober 2024

Whirlpool 3RAWZ481E Bedienungsanleitung

14 Oktober 2024

Whirlpool DDLX 80116 Bedienungsanleitung

13 Oktober 2024

Whirlpool Green 850 Bedienungsanleitung

12 Oktober 2024

Whirlpool W6 D83WB EE Bedienungsanleitung

12 Oktober 2024

Whirlpool FFT M11 9X3BY BE Bedienungsanleitung

12 Oktober 2024

Whirlpool Boston C Bedienungsanleitung

9 Oktober 2024

Whirlpool FFT M11 9X2BXY BE Bedienungsanleitung

7 Oktober 2024

Whirlpool WGD5720RW Bedienungsanleitung

2 Oktober 2024

Whirlpool WGD5720RR Bedienungsanleitung

2 Oktober 2024

Bedienungsanleitung Wäschetrockner

Neueste Bedienungsanleitung für -Kategorien-

GE Profile PFD95GSPTDS Bedienungsanleitung

16 Oktober 2024

Maytag MGD7100DC Maxima Bedienungsanleitung

16 Oktober 2024

Bosch WTA4000 Bedienungsanleitung

16 Oktober 2024

Bauknecht TRKP 7950 Bedienungsanleitung

16 Oktober 2024

Hoover DX C9DKG-80 Bedienungsanleitung

16 Oktober 2024

Teka THPD80 Bedienungsanleitung

16 Oktober 2024

BEKO B3T41242 Bedienungsanleitung

16 Oktober 2024

BEKO BM5T49243W Bedienungsanleitung

16 Oktober 2024

BEKO B3T67110 Bedienungsanleitung

16 Oktober 2024

BEKO BM3T48249W Bedienungsanleitung

16 Oktober 2024
