Seite 1/5
1 Programme selector
2 “Start/Pause“ button
3 “Reset/Drain“ button
4 “Start delay“ button
5 Child lock combination
6 “Spin“ button
7 Time
8 Washing phase
INDICATORS
Lid open
Failure: Call Service
Failure: Water lter clogged
Failure: No water
In the event of any failure, refer to the
“TROUBLESHOOTING“ section
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register
CONTROL PANEL
PROGRAMME CHART
PRODUCT DESCRIPTION
1. Lid handle
2. Lid
3. Control panel
4. Detergent dispenser
5. Drum
6. Water lter - behind the cover
7. Mobility lever (depending on model)
8. Adjustable feet (x2)
5.
1.
6.
7.
2.
3.
4.
8.
DETERGENT DISPENSER
Main wash compartment
Detergent for the main wash, stain remover or
water softener.
Prewash compartment
Detergent for the prewash.
Softener compartment
Fabric softener. Liquid starch. Bleach.
Pour in softener, starch or bleach solution
only up to the “max” mark.
Release button
Press to remove tray for cleaning.
water pressure etc. Approximate programme duration values refer to the default setting of
the programmes, without options. The values given for programmes other than the eco 40-
60 programme are indicative only.
* After programme end and spinning with maximum selectable spin speed, in default
programme setting.
** The duration of the programme is shown on the display.
6th Sense - The sensor technology adapts water, energy and programme duration to your
wash load.
Eco cotton - Test wash cycles in compliance with regulations 1061/2010. Set “Cotton 40 °C” or
“Cotton 60°C” wash cycle together with “Energy saver” option to access this cycles.
Eco 40-60 - Test wash cycle in compliance with 2019/2014 regulation. The most ecient
programme in terms of energy and water consumption for washing normally soiled cotton
laundry. Display only: Spin speed values shown on the display can slightly diers from the
values stated in the table
For all Test Institutes
Long wash cycle for cottons: set wash cycle Cotton with a temperature of 40°C.
Synthetic program along: set wash cycle Synthetics with a temperature of 40°C.
This data may dier in your home due to changing conditions in inlet water temperature,
EN
Quick guide
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bracket is removed.
For more detailed instructions on how to remove it, see the Installation Guide.
1 2 3 4 5
6
8 7
Max load 7,0 Kg
Power consumption in o-mode 0,11 W / in left-on mode 0,11 W Detergents and additives Recommended
detergent
Residual
dampness % *
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Programme
Temperatures Max.
Spin
speed
(rpm)
Max
load
(kg)
Duration
(h : m)
Prewash Main
wash Softener
Powder Liquid
Setting Range
Mixed 40°C 40°C 1200 3,0 ** – – – – –
40°C 40°C
1151 7,0 3:25 – 62 1,23 57 45
1151 3,5 2:40 – 62 0,57 41 36
1151 2,0 1:50 – 62 0,35 32 31
20°C 20°C 1200 7,0 2:45 – – 62 0,27 48 20
Colours 40°C 40°C 1000 4,0 ** – – – – –
Wool 20°C 20°C 1000 1,0 ** – – – – – –
Spin – – 1200 7,0 ** – – – – – – – – –
Rinse + Spin – – 1200 7,0 ** – – – – – – – –
Delicates 30°C 30°C 1000 1,5 ** – – – – –
Hygiene 60°C 60°C 1200 7,0 ** – – – – –
Synthetics 40°C 1200 3,0 1:5040°C 40 0,56 50 40
Rapid 30’ 30°C 30°C 1200 3,0 0:30 – – 57 0,25 42 27
Cotton 60°C 1200 7,0 3:0040 - 95°C 64 1,33 52 55
Eco cotton 60°C 60°C 1200 7,0 4:00 – 62 0,90 48 –
3,5 2:50 – 62 0,75 34 –
40°C 1200 3,5 2:30 – 62 0,65 34 –
Dosing required Dosing optional
PROGRAMMES
For choosing the appropriate programme for your kind of
laundry, always respect the instructions on the care labels
of the laundry. The value given in the tub symbol is the
maximum temperature possible for washing the garment.
Mixed
For washing lightly to normally soiled resilient garments in cotton, linen,
synthetic fibres and mixed fibres.
Eco 40-60
For washing normally soiled cotton garments declared to be washable
at 40 °C or 60 °C, together in the same cycle. This is the standard cotton
programme and the most efficient in terms of water and energy
consumption.
20 °C
For washing lightly soiled cotton garments, at a temperature of 20 °C.
Colours
White and pastel shaded garments made of delicate fabrics.
Gentle wash programme to avoid graying or yellowing of your laundry.
Use heavy duty detergent, if necessary also stain removers or bleaches on
oxygen basis. Do not use liquid detergent.
Wool
All wool garments can be washed using programme ‚ “Wool“ even
those carrying the “hand-wash only“ label. For best results, use special
detergents and do not exceed max kg declaration of laundry.
Spin
Spins the load then empties the water. For robust laundry.
Rinse + Spin
Separate rinse and intensive spin programme. For robust
laundry.
Delicates
For washing particularly delicate garments. Preferably turn garments
inside out before washing.
Hygiene
This program removes 99 % of bacteria while washing normally to heavily
soiled bed linen, table linen and underwear, towels, shirts etc. made of
cotton and linen.
Synthetics
For washing soiled garments made from synthetic fibres (such as
polyester, polyacrylic, viscose, etc.) or cotton/synthetic blends.
Rapid 30’
Shortly worn clothing made of cotton, polyester, polyamide and blends
with cotton. Brief programme to refresh your laundry.
Cotton
Normally to heavily soiled and robust cottons.
Eco cotton
For washing normally soiled cotton garments. At 40°C and 60°C
FIRST TIME USE
To remove any manufacturing debris select the “Cotton“ programme
at a temperature of 95°C. Pour a small quantity of detergent powder into
the main wash compartment of the detergent dispenser (maximum
1/3 of the quantity the detergent manufacturer recommends for lightly
soiled laundry). Start the programme without adding any laundry.
DAILY USE
Prepare your laundry according to the recommendations in the “HINTS
AND TIPS“ section. Load the laundry, close the drum door and check that
it is closed properly. Pour in the detergent and any additives. Observe the
dosing recommendations on the detergent pack. Close the lid. Turn the
programme selector to the desired programme and select any option if
needed. The display shows the duration of the selected programme (in
hours and minutes), and the indicator for the “Start/Pause“ button
flashes. The spin speed can be changed by pressing the “Spin“ button.
The indicator of the predefined spin speed lights up. Open the tap and
press the “Start/Pause“ button to start the wash cycle. The “Start/
Pause“ indicator will lights up and the door will be locked. Due to
variations in load and temperature of inlet water, the remaining time is
newly calculated in certain programme phases. If this is the case, an
animation appears on the time display.
PAUSE OR CHANGE A RUNNING PROGRAMME
To pause the wash cycle, press the “Start/Pause“ , the indicator button
light blinks. Select any new programme, options or spin speed if you wish
to change those settings. Press the “Start/Pause“ button again to start
the wash cycle from the point at which it was interrupted. Do not add
detergent for this programme.
LID OPEN INDICATOR
Before starting and after the end of a programme, the “Lid open“
indicator lights to show that the lid can be opened. As long as a wash
programme is running, the lid remains locked and must on no account
be forced open. In case you have an urgent need to open it during a
running programme, for example to add more laundry, or to remove
laundry which was loaded by mistake, press the “Start/Pause“
button. If the temperature is not too high, the “Lid open“ indicator
light turns on. It may last a while until you can open the lid. Press “Start/
Pause“ to proceed with the programme again.
PROGRAMME END
The “Lid open“ indicator lights up and the display shows .Turn
the programme selector to the “O“ position and close the water tap.
Open the lid and drum and unload the machine. Leave the Lid open
for some time to allow the interior of the machine to dry. After about a
quarter of an hour, the washing machine will switch off completely to
save energy.
To cancel a running programme before the end of cycle, press the
“Reset/Drain“ button for at least 3 seconds. The water is drained out.
It may last a while until you can open the lid.
OPTIONS
! When the combination of programme and additional option(s) is not
possible, the indication lights switch o automatically.
! Unsuitable combinations of options are deselected automatically.
Colours 15°
Saves energy used for water heating while maintaining a good wash
result. Supports colour maintenance when washing coloured laundry.
Recommendable for lightly soiled laundry without stains. Make sure that
your detergent is suitable for cold wash temperatures.
Fresh Care
Select this option if you cannot unload the laundry soon after
programme end, or if you tend to forget the laundry in your washing
machine. It will help to keep your laundry fresh. The washing machine
will start to tumble the laundry periodically after programme end. The
light of the “Fresh Care“ button will blink while this function is active,
and the display will show an animation. The periodic tumbling will last up
to approximately 6 hours after the end of your wash programme, and you
can stop it at any time by pressing the “Fresh Care“ button. It will last
a while until you can open the door. After the “Fresh Care“ period has
run out, the display indicates .
Start delay
To set the selected programme to start at a later time, press the “Start
delay“ button to set the desired delay time. The lamp for the
“Start delay“ option button lights up, and it goes off when the
programme starts. Once having pressed the “Start/Pause“ button,
the countdown of the time delay begins. Number of hours pre-selected
can be reduced by pressing the “Start delay“ button again. Do not
use liquid detergent when activating this option. To cancel the “Start
delay“ turn the programme selector to another position.
Rapid
Enables quicker washing by shortening the programme duration.
Recommendable for small loads or only lightly soiled laundry.
Prewash
Only for heavily soiled loads (for example sand, granular dirt). Increases
the cycle time by approximately 15 min. Do not use liquid detergent for
the main wash when activating the Prewash option.
Energy saver
With a lower temperature and slightly modified washing duration, the
optimum combination of excellent washing results
and even lower energy consumption is achieved.
Intensive rinse
Helps to avoid detergent residues in the laundry by extending the rinse
phase. Particularly suitable for washing baby laundry, for people suffering
from allergies and for areas with soft water.
Spin
Every programme has a predefined spin speed. If you want to change the
spin speed, press the “Spin“ button. If spin speed “0“ is selected, the
final spinning is cancelled but intermediate spin peaks remain during the
rinse. The water is drained out only.
CHILD LOCK
You can lock the buttons of the control panel against improper use (e.g.
by children). Press both of the child lock buttons simultaneously and hold
them for at least 3 seconds. The key symbol on the display lights
up. To unlock the buttons again proceed in the same way.
BLEACHING
Wash your laundry in the desired programme, Cotton or Synthetics
, adding an appropriate amount of chlorine bleach to the Softener
chamber (close the lid carefully). Immediately after the end of
the programme, turn the “Programme selector” and start the desired
programme again to eliminate any residual bleach smell; if you want, you
can add softener. Never put both chlorine bleach and softener into the
softener chamber at the same time.
HINTS AND TIPS
Sort your laundry according to
Type of fabric/care label (cotton, mixed fibres, synthetics, wool, handwash
items). Colour (separate coloured and white items, wash new coloured
items separately). Delicates (wash small items – like nylon stockings – and
items with hooks – like bras – in a cloth bag or pillow case with zip).
Empty all pockets
Objects like coins or lighters can damage your laundry as well as the
drum.
Appliance interior
If you never or seldom wash your laundry at 95°C, we recommend to
occasionally run a 95°C programme without laundry, adding a small
amount of detergent, to keep the interior of the appliance clean.
Follow the dosage recommendation / additives
It optimizes the cleaning result, it avoids irritating residues of surplus
detergent in your laundry and it saves money by avoiding waste of
surplus detergent
Use low temperature and longer duration
The most efficient programmes in terms of energy consumption are
generally those that perform at lower temperatures and longer duration.
Observe the load sizes
Load your washing machine up to the capacity indicated in the
“PROGRAMME CHART” table to save water and energy.
Noise and remaining moisture content
They are influenced by the spinning speed: the higher the spinning
speed in the spinning phase, the higher the noise and the lower the
remaining moisture content.
CLEANING & MAINTENANCE
For any cleaning and maintenance, switch off and unplug the washing
machine. Do not use flammable fluids to clean the washing machine.
Clean and maintain your washing machine periodically (at least 4 times
per year).
Cleaning the outside of the washing machine
Use a soft damp cloth to clean the outer parts of the washing machine.
Do not use glass or general purpose cleaners, scouring powder or similar
to clean the control panel – these substances might damage the printing.
Detergent dispenser
Clean regularly, at least three or four times a year, to prevent detergent
build-up:
Press the release button to release the detergent dispenser and
remove it. A small quantity of water can remain in the dispenser, thus you
should carry it in an upright position. Wash the dispenser using running
water. You can also remove the siphon cap on the back of the
dispenser for cleaning. Replace the siphon cap in the dispenser (if
removed) Reinstall the dispenser by locating the dispenser’s bottom tabs
into the appropriate openings on the lid, and by pushing the dispenser
against the lid until it locks into place. Make sure that the detergent
dispenser is correctly reinstalled.
Checking the water supply hose
Check the inlet hose regularly for brittleness and cracks. If damaged,
replace it by a new hose available through our After-Sales Service or
your specialist dealer. Depending on the hose type: If the inlet hose has
a transparent coating, periodically check if the colour intensifies locally.
If yes, the hose may have a leak and should be replaced. For water stop
hoses (If available): check the small safety valve inspection
window (see arrow). If it is red, the water stop function was triggered, and
the hose must be replaced by a new one. For unscrewing this hose, press
the release button (if available) while unscrewing the hose.
Cleaning the mesh filters in the water supply hose
Check and clean regularly (at least two or three times a year).
Close the tap and loosen the inlet hose on the tap. Clean the internal
mesh filter and screw the water inlet hose back onto the tap. Now
unscrew the inlet hose on the rear of the washing machine. Pull off the
mesh filter from the washing machine connection with universal pliers
and clean it. Refit the mesh filter and screw the inlet hose on again. Turn
on the tap and ensure that the connections are completely water-tight.
Cleaning the water filter / draining residual water
The washing machine is provided with a self-cleaning pump. The filter
keeps objects like buttons, coins, safetypins etc. which have been left in
the laundry. If you used a hot wash programme, wait until the water has
cooled down before draining any water. Clean the water filter regularly, to
avoid that the water cannot drain after the wash due to obstruction of the
filter. If the water cannot drain, the indicator indicates that the water filter
may be clogged.
Open the filter cover with a coin. Place a broad, flat container beneath
the water filter, to collect the drain water. Slowly turn the filter
counterclockwise until water flows out. Let the water flow out, without
removing the filter. When the container is full, close the water filter by
turning it in clockwise. Empty the container. Repeat this procedure until
all the water has drained. Lay a cotton cloth beneath the water filter,
which can absorb a small amount of rest water. Then remove the water
filter by turning it out anti clockwise. Clean the water filter (remove
residues in the filter and clean it under running water) and the filter
chamber. Make sure the pump impeller (in the housing behind the filter)
is not obstructed. Insert the water filter and close the filter cover: Reinsert
the water filter again by turning it in clockwise direction. Make sure to
turn it in as far as it goes. To test water tightness of the water filter, you
can pour about 1 liter of water into the drum and check that water does
not leak from the filter. Then close the filter cover.
Lid seal
Check the condition of the lid seal periodically and clean it from time to
time with a damp cloth.
Recovering an object that falls between the drum and the tub
If an object accidentally falls between the drum and the tub, you can
recover it thanks to one of the removable drum lifters.
Unplug the washing machine. Remove the laundry from the drum. Close
the drum flaps and turn the drum a half-turn (picture ). Using a screw-a
driver press on the plastic end, while sliding the lifter from left to right
(picture , b c) by hand it will fall into the drum. Open the drum. You can
recover the object through the hole in the drum. Refit the lifter from
inside the drum: Position the plastic tip above the hole on the right side
of the drum (picture ). Then slide the plastic lifter from right to left until d
it clips. Close the drum flaps again, turn the drum through half a turn and
check the positioning of the blade at all its anchorage points. Plug the
washing machine in again.
TRANSPORT AND HANDLING
Pull out the mains plug, and close the water tap. Disconnect the inlet
hose from the water tap, and remove the drain hose from your draining
point. Remove all rest water from the hoses and washing machine and
fix hoses so that they cannot get damaged during transport. To facilitate
moving the machine, pull the mobility lever situated at the bottom
front (if available on your model) out a little by hand. Pull the washing
machine out to the stop with the foot. Afterwards push the mobility lever
back into the original stable position. Refit the transport bracket. Follow
the instructions for removing the transport bracket in the INSTALATION
GUIDE in reverse order.
abcd
EN
Quick guide
Produktspezifikationen
| Marke: | Whirlpool |
| Kategorie: | Waschmaschinen |
| Modell: | EELT 7120 EU |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Whirlpool EELT 7120 EU benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Waschmaschinen Whirlpool
16 Oktober 2024
16 Oktober 2024
15 Oktober 2024
15 Oktober 2024
14 Oktober 2024
13 Oktober 2024
13 Oktober 2024
13 Oktober 2024
12 Oktober 2024
12 Oktober 2024
Bedienungsanleitung Waschmaschinen
- Waschmaschinen Samsung
- Waschmaschinen Infiniton
- Waschmaschinen Sanyo
- Waschmaschinen Manta
- Waschmaschinen Hanseatic
- Waschmaschinen Panasonic
- Waschmaschinen LG
- Waschmaschinen Bosch
- Waschmaschinen AEG
- Waschmaschinen Asko
- Waschmaschinen Siemens
- Waschmaschinen Bauknecht
- Waschmaschinen Electrolux
- Waschmaschinen Fagor
- Waschmaschinen Gaggenau
- Waschmaschinen Gorenje
- Waschmaschinen Koenic
- Waschmaschinen Miele
- Waschmaschinen Teka
- Waschmaschinen Bomann
- Waschmaschinen OK
- Waschmaschinen Russell Hobbs
- Waschmaschinen Vox
- Waschmaschinen IKEA
- Waschmaschinen Bush
- Waschmaschinen Thomson
- Waschmaschinen Amica
- Waschmaschinen BEKO
- Waschmaschinen Campomatic
- Waschmaschinen Grundig
- Waschmaschinen Heinner
- Waschmaschinen Hotpoint
- Waschmaschinen Kenwood
- Waschmaschinen KitchenAid
- Waschmaschinen Primo
- Waschmaschinen Sharp
- Waschmaschinen Smeg
- Waschmaschinen Trebs
- Waschmaschinen AEG-Electrolux
- Waschmaschinen Ardo
- Waschmaschinen Ariston
- Waschmaschinen Balay
- Waschmaschinen Blomberg
- Waschmaschinen Brandt
- Waschmaschinen Candy
- Waschmaschinen Constructa
- Waschmaschinen Corberó
- Waschmaschinen Curtiss
- Waschmaschinen Daewoo
- Waschmaschinen Edesa
- Waschmaschinen Elektra Bregenz
- Waschmaschinen ELIN
- Waschmaschinen Eudora
- Waschmaschinen Everglades
- Waschmaschinen Exquisit
- Waschmaschinen Pyle
- Waschmaschinen Finlux
- Waschmaschinen GE
- Waschmaschinen Haier
- Waschmaschinen Hisense
- Waschmaschinen Hoover
- Waschmaschinen Hotpoint-Ariston
- Waschmaschinen Iberna
- Waschmaschinen Ignis
- Waschmaschinen Indesit
- Waschmaschinen Baumatic
- Waschmaschinen Kelvinator
- Waschmaschinen Laurus
- Waschmaschinen Maytag
- Waschmaschinen Midea
- Waschmaschinen Caple
- Waschmaschinen Neff
- Waschmaschinen Nordmende
- Waschmaschinen Otsein
- Waschmaschinen EAS Electric
- Waschmaschinen Otsein-Hoover
- Waschmaschinen Privileg
- Waschmaschinen Saivod
- Waschmaschinen Schulthess
- Waschmaschinen Frigidaire
- Waschmaschinen SIBIR
- Waschmaschinen Speed Queen
- Waschmaschinen Svan
- Waschmaschinen Thor
- Waschmaschinen V-ZUG
- Waschmaschinen Vestel
- Waschmaschinen Zanker
- Waschmaschinen Zanussi
- Waschmaschinen Zanussi-Electrolux
- Waschmaschinen Zerowatt
- Waschmaschinen Philco
- Waschmaschinen Arçelik
- Waschmaschinen Hitachi
- Waschmaschinen Hyundai
- Waschmaschinen Costway
- Waschmaschinen Atlas
- Waschmaschinen Cylinda
- Waschmaschinen Elba
- Waschmaschinen Freggia
- Waschmaschinen Marijnen
- Waschmaschinen Prima
- Waschmaschinen Stoves
- Waschmaschinen UPO
- Waschmaschinen Friac
- Waschmaschinen White Knight
- Waschmaschinen Logik
- Waschmaschinen Wasco
- Waschmaschinen Premium
- Waschmaschinen Orima
- Waschmaschinen Proline
- Waschmaschinen Amana
- Waschmaschinen Euromaid
- Waschmaschinen Whiteline
- Waschmaschinen Vivax
- Waschmaschinen Tricity Bendix
- Waschmaschinen Nordland
- Waschmaschinen Rasonic
- Waschmaschinen Edy
- Waschmaschinen Hoover-Helkama
- Waschmaschinen New Pol
- Waschmaschinen Insignia
- Waschmaschinen RCA
- Waschmaschinen Swan
- Waschmaschinen Fisher & Paykel
- Waschmaschinen Esatto
- Waschmaschinen CDA
- Waschmaschinen Defy
- Waschmaschinen Kenmore
- Waschmaschinen Lloyd
- Waschmaschinen Magic Chef
- Waschmaschinen Teco
- Waschmaschinen Avanti
- Waschmaschinen Nevir
- Waschmaschinen Creda
- Waschmaschinen Trieste
- Waschmaschinen Simpson
- Waschmaschinen Roper
- Waschmaschinen John Lewis
- Waschmaschinen Alhafidh
- Waschmaschinen Servis
- Waschmaschinen Dexter
- Waschmaschinen Fram
- Waschmaschinen Tisira
- Waschmaschinen Neufunk
Neueste Bedienungsanleitung für -Kategorien-
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
